Nittan CPC-4A Operating Instructions Manual

Smoke detector control panel
Hide thumbs

Advertisement

Quick Links

Download this manual
Smoke Detector Control Panel (CPC-4A)
AC 100V - 240V Specification
Operating Instruction Manual
January, 2020
54-5, 1-CHOME, SASAZUKA SHIBUYA-KU, TOKYO 151-8535 JAPAN
TEL 03-5333-7021 (Overseas Business Department)
We highly appreciate your purchasing of NITTAN product.
Before operation, please read this "Operating Instruction Manual" and use the equipment in proper manner.

Advertisement

loading
Need help?

Need help?

Do you have a question about the CPC-4A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nittan CPC-4A

Summary of Contents for Nittan CPC-4A

  • Page 1 Operating Instruction Manual January, 2020 54-5, 1-CHOME, SASAZUKA SHIBUYA-KU, TOKYO 151-8535 JAPAN TEL 03-5333-7021 (Overseas Business Department) We highly appreciate your purchasing of NITTAN product. Before operation, please read this “Operating Instruction Manual” and use the equipment in proper manner.
  • Page 2 1. Product The Smoke Detector Control Panel is a fire detection system to be used by connecting with a designated smoke detector (0KB3). When fire breaks out, the panel receives fire signal from smoke detector and indicates operating smoke detector address and starts to sound buzzer alarm.
  • Page 3 WARNING ● Do not touch the equipment with wet hands or dip into water or splash water over the equipment. It may cause electrification or trouble. ● Do not overhaul or modify equipment. It may cause electrification and trouble. ● Do not use the equipment in location where operating temperature exceeds its range (0-60°C) and where explosive gas or corrosive gas is generated.
  • Page 4 3. Name of each section (Indication /Operation） ① Mode SW (mode switch) At normal monitoring time: set to [Normal] (assigned) side. ⑤ ① ② ③ ④ At address setting time: set to [AD Set] (address setting) side. ② Up (increment switch) ③...
  • Page 5 4. Digital indication list ● Digital indication at operation time/trouble time Content of digital Digital indication Details indication ● To indicate smoke detector address when [Fire Alarm] (fire light) or [Detector Operated] (1 detector operation light) turns on. When 2 or more detectors operate, maximum 5 detector(*) addresses are indicated in order of operation.
  • Page 6 6. Operation specification Indication Light 7 Seg Indication Terminal Indication Detector Detector Sensor Power Operated Fire Buzzer Sound Operated Fire Address/ Condition Fault Indication Fault 1 detector Alarm (*1) 1 detector Alarm Err Code (green) (yellow) operation Operation (red) Detector (red) address/code 9-11...
  • Page 7 Control Panel External reset switch input line *2 Fault Operated Fire Alarm (CPC-4A) 11 10 2 3 1 5 6 4 No-voltage c contact: indication of device board shows condition at monitoring time (at power supply time). * 1 It is recommended to use either AE cable or CPEV cable with conductor diameter over 0.65mm.
  • Page 8 8. Setting of the number of detectors connected To register smoke detector number to be connected to the Smoke Detector Control Panel. CAUTION ● The number of connected detectors registered to the Smoke Detector Control Panel is 2 at the time of factory shipment.
  • Page 9 ⑤ [01] is indicated digitally. Indicate detector number to be connected to the Smoke Detector Control Panel by pressing [up] (increment switch) or [down] (decrement switch). (Connecting detector number can be registered up to [01~20].) ・・・ ⑥ Register connecting detector number by pressing [Silence] (audible sound stop switch). When [ ] (ok: setting succeed) is indicated, registration is completed.
  • Page 10 Ｌ Ｃ Smoke Detector Control Panel Smoke Detector （CPC-4A） （0KB3） ② Switch on [Power SW] (power supply) by setting [Mode SW] (mode switch) to [AD Set] (address setting) side. Power SW ③ When [SO] is indicated digitally, set to [Address Setting Mode]. Push [Reset] (reset switch) and indicate [AO] and push [silence] (audible sound stop switch).
  • Page 11 ③ condition. (ok) *Please enter the registered address into the available space of the product label attached to the back of the smoke detector, in order to identify the address. NITTAN CO.,LTD. Detector Back Smoke Example: When the address is detector set at [02].
  • Page 12 ⑦ When you wish to continue registration of address to other smoke detector, replace registering smoke detector body only, and register address to all smoke detectors one by one in line with the above ③~⑥. ⑧ When registration is completed, release setting mode. Switch off [Power SW] (power supply) and set [Mode SW] (mode switch) to [Normal] (assigned) side.

  • Page 13: Troubleshooting

    10. Troubleshooting If the condition is not rectified after applying the following procedures, please contact the distributor from which you purchased or NITTAN Co., Ltd. Condition Cause Corrective Measures Power is not supplied to Supply power to [Power-Line] (power supply input [Power-Line] (power terminal).
  • Page 14 11. Product specification Model Name CPC-4A Rated Voltage AC 100-240V (±10V), 50/60 Hz Supervisory condition: 1.6VA (AC 100V)/2.8VA (AC 240V) Rated Power Alarm condition: 3.2VA (AC 100V)/4.7VA (AC 240V) Detector Power Voltage Rated DC 19V Max. No. of Detector 20 Max...
