Product Description

The Delta P Plus Controller monitors the differential pressure between the clean-air and dirty-air plenums, providing a visual
display of the filter condition. When combined with a pulse timer, it manages the pressure drop by turning the cleaning mechanism
On and Off at the chosen limits. There are three (3) set points: High Pressure On, Low Pressure Off, and Alarm. The first two,
High Pressure On and Low Pressure Off, control the filter cleaning system. The third, Alarm, provides a relay output to activate an
external alarm supplied by others.
The user can program the Delta P Plus Controller to pulse while the collector is running, to maintain a relatively constant pressure
drop across the filters, pulse only after the collector is shut down (after-shift cleaning), or a combination of both, cleaning while
running as well as end of the shift.
3

Operation

Three cleaning modes, Differential Pressure Cleaning (DFF), Downtime Cleaning (DTC), and Combined Differential and Downtime
Cleaning (ALL) are available with this controller and can be individually chosen by the user.
• Differential Pressure Cleaning (DFF) - When the differential pressure drop reaches the controller's HIGH setpoint, the
controller closes an output relay initiating the cleaning cycle. When the differential pressure decreases to the LOW
setpoint, the relay opens and the cleaning cycle stops. This sequence continues as long as the collector is running,
maintaining the differential pressure drop within a specified range.
• Downtime Cleaning (DTC) – The Delta P Plus controller monitors for the differential pressure drop to exceed the LOW
setpoint. (Indicates the blower has been started). When the differential pressure drop later approaches zero (indicating
the blower has been shut down), the Delta P Plus engages the cleaning cycle for a pre-selected time. A delay timer
allows the blower to come to a stop before the cleaning cycle starts.
The delay timer and cleaning cycle durations are both user adjustable but password protected.
• Combined Differential and Downtime Cleaning (ALL) –The ALL mode combines the two functions described above,
maintaining the differential pressure drop in a specified range, then initiating a down-time cleaning cycle when the
differential pressure drop approaches zero. The downtime cleaning function can be toggled on or off from the keyboard.
Note: The DTC and ALL cleaning modes incorporate compressed air cleaning of the filters when the main collector fan is not
running. This may result in collected material "drifting" out the inlet duct of the collector. An isolation valve in the inlet duct of the
collector can reduce or eliminate that drifting.
Consideration should be made on the use of the DTC or ALL cleaning mode on small collectors where the relatively low volume
of the collector may produce pressure spikes with each pulse of the cleaning cycle. Such pressure spikes may accelerate the
fatigue, or damage of ancillary items such as pressure sensors or explosion relief panels.
Alarm
The Alarm setpoint is set to a higher setting than the High Pressure On used to start the filter cleaning cycle. It indicates situations
when the cleaning system cannot reduce the pressure drop due to cleaning system failure, lack of compressed air, or the end of
the filter's useful life. There is a time delay prior to setting the Alarm to prevent nuisance trips. The Delta P Plus Controller also
provides an input connection for a remote Alarm reset.
