- Page 1 Owner's Manual Residential Factory Built Fireplace Operation • Maintenance • Installation FOCUS 3600i Insert Keep these instructions for future use. Industrial Chimney Company Inc. 400 J.-F. Kennedy, St-Jerome, QC, Canada, J7Y 4B7 Telephone: (450) 565-6336 www.icc-rsf.com RSF-IIF3600i _ 2023-05...
- Page 2 Study your manual to be sure that the installation is correct, then follow the guidelines for operation and maintenance. We at RSF Woodburning Fireplaces congratulate you on your choice of the FOCUS 3600i, and are confident that you have purchased a fireplace insert that is simply, the best.
-
Page 3: Safety First
The chimney should be inspected periodically during the heating season to see if a creosote build-up has occurred. The presence in a chimney of soot or creosote in excess of 1/8" (3mm) thick will indicate the need for immediate cleaning, possible modification of burning procedures, and more frequent inspections. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 4: General Specifications
The internal blower plugs into a nearby outlet and does not require an electrician for setup. Backing Plate (FO-F3600INBP): If the original fireplace has an opening larger than the standard trim provided with the Focus 3600i Insert, an optional Backing Plate can be added to fill in the space. Without Backing Plate... -
Page 5: Unit Dimensions And Clearances
UNIT DIMENSIONS AND CLEARANCES FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... - Page 6 Figure 1 Unit Dimensions 8" 8" Figure 2 Minimum Fireplace Dimensions Combustible Mantel FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces...
-
Page 7: Ceiling Clearance
Type 1 hearth pad is sufficient Floor protection Requires ember protection and heat protection Minimum R-value = 1.5 Type 2 hearth pad is required Floor level installation Raised installation Raised installation with non-combustible step in front FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 8: General Installation
We recommend that you take the time to plan your entire installation before beginning the actual installation. Your FOCUS 3600i Insert is designed to be installed into a masonry wood burning fireplace. Dimensions and clearances are shown in Figure 1 and Table 1. -
Page 9: Installation Into A Masonry Fireplace
Standard of Chimneys, Fireplaces, Vents and Solid Fuel Burning appliances, N.F.P.A. 211 (Latest Edition) or applicable National, Provincial, State or local codes. The installation shall conform to CAN/CSAB365, Installation Code for Solid-Fuel-Burning Appliances and Equipment. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 10: Chimney Liner
9. Bolt the appliance flue collar in place from the inside of the firebox with Figure 7 Appliance Flue the four bolts provided (Figure 9). Collar 10. Remove the detachable pull-handle. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... - Page 11 With the trim in the recessed position, the appliance can fit in a shallower masonry fireplace (Figure 11). Figure 10 Trim Installation / Adjustment Flush Recessed Figure 11 Trim Positions Figure 12 Bottom Louver Installation FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces...
-
Page 12: Refractory Brick Installation
Top of the Glass from Bottom of Unit 0" to 8" 24" 42 1/2" 9” 27 7/8" 46 3/8" 10” 31 3/4" 50 1/4" 11” 35 3/4" 54 1/4" 12" 39 1/2" 58" FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 13: Operation
The amount of time to keep the door slightly ajar at startup is dependant on the height of your chimney and the outside temperature: the higher and the colder, FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 14: First Fires
The door should be opened slowly to keep smoke from spilling into your room. If you have a problem with smoke spillage, check to see that all kitchen and bathroom fans have been shut off. They can cause negative pressure in the house which pulls smoke out of the insert. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 15: Importance Of Draft
Fast burning fires (lots of air) go through much more wood than slow burning fires. To get the most out of your FOCUS 3600i insert, adjust the combustion air control lever at the appropriate time. -
Page 16: Maintenance
GENERAL CLEANING The high heat paint can be cleaned with a soft damp cloth. Use a mild detergent and water. Do not use abrasive cleaners. See the "Paint" section below for touch-ups. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 17: Glass Cleaning
If needed, the door hinges can be adjusted to improve the alignment of the door latch with respect to the latch pin on the fireplace in the fireplace facing, and for easy installation/removal of the door. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 18: Removal Of The Fireplace Insert
3- Remove the facing of the unit by unscrewing the 5 screws (3 on top, and 2 at the bottom, 1 on each side). 4- See section Chimney Liner on page 10 and proceed with the reverse liner installation procedure.. 5- Safely remove the fireplace insert from the masonry fireplace opening. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 19: Listing Label
LISTING LABEL To access the listing label, remove the bottom louver (Figure 12). The listing label is glued to a steel plate which is attached to a small steel wire. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 20: Complete Options List
Internal Blower Kit REPLACEMENT PARTS Use only genuine RSF parts. The use of any substitutes will void the warranty and may put your safety at risk. Will be available soon. Contact your RSF dealer. FOCUS 3600i Owner's Manual RSF Woodburning Fireplaces... -
Page 21: Limited Warranty
This warranty does not apply if the installation does not conform to the installation requirements in the owner’s manual. RSF Woodburning Fireplaces is free of liability for any damages caused by the appliance, as well as material and labor charges incurred in the removal or re-installation of any RSF Woodburning Fireplaces fireplace under this warranty.
