Montage nach abZ (in Deutschland zu beachten)
Z-14.9-688
Installation according to abZ (Observe in Germany)
150 – 600
mm
a
min.
100
mm
b
min.
120
mm
a
OPTIONAL
3
max.
mm
b
min.
22
mm
OSB 3
b
a
a
b
ABS-Lock® X-H-16
|
LX-H-XXX-16
Montage ab Seite 6
3
