- Page 1 ROTARY TILLER BE-TSXXX OPERATIONS & PARTS MANUAL FOR MODELS: • BE-TS120 • BE-TS140 • BE-TS160 • BE-TS180 • BE-TS200 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
- Page 2 TABLE OF CONTENTS INTRODUCTION & SAFETY OPERATION MAINTENANCE EXPLODED VIEW & PARTS LIST...
- Page 3 INTRODUCTION & SAFETY Thank you for purchasing your Tiller. Your Rotary Tiller is designed to be used on 540 RPM tractors. It is important to properly maintain and keep in place all safety guards and shields that came with your tiller. SAFETY Read and understand this manual and all safety signs before operating and maintaining.
- Page 4 SAFETY DECAL CARE • Keep safety signs clean and legible at all times. • Replace safety signs that are missing or have become illegible. • Replaced parts that displayed a safety sign should also display the current sign. • Safety signs are available from your Local Dealer.
- Page 5 • Do not clean, lubricate or adjust your equipment while it is moving. • When halting operation, even periodically, set the tractor or towing vehicle brakes, disengage the PTO, shut off the engine and remove the ignition key. • Be especially observant of the operating area and terrain. Watch for holes, rocks or other hidden hazards. • Always inspect the area prior to operation.
- Page 6 Before beginning operation, check oil and grease points. OPERATION Oil Level: Top gear box 1-1/2” from the end of the dip stick. When sitting slightly tilted forward, oil should be at the bottom of the drain plug on the side gearbox cover. Grease: Right Rotor bearing, PTO shaft Cross &...
- Page 7 Slip Clutch Adjustments: Slip Clutch must be adjusted before first use or after a storage period. 6. Using a marker, scribe a line across the exposed edges of the clutch plate and friction discs. 7. Back off compression nuts to free friction discs by turning each nut 2 revolutions. 8.
- Page 8 • Use extreme caution when making adjustments. • Never replace hex bolts with than grade 5 bolts unless otherwise specified. • After servicing, be sure all tools, parts and service equipment are removed. • Where replacement parts are necessary for periodic maintenance and servicing, genuine factory replacement parts must be used to restore your equipment to original specifications.
- Page 9 EXPLODED VIEW & PARTS LIST PARTS DIAGRAM BE-TSxx BE-TSXXX USER MANUAL...
- Page 10 PART NO DESCRIPTION PART NO DESCRIPTION GB/T5783-2000 Bolt M10x25 Side Panel Bracket Lock Nut - Idler Gear Support Shaft TS58-01-01-00 Frame Weldment 58 GB/T3452.1-2005 O-Ring - Idler Gear Support Shaft TS66-01-01-00 Frame Weldment 66 GB/T297-1994 Bearing (Idler Gear) TS72-01-01-00 Frame Weldment 74 GB/T893.1-1986 Snap Ring (Idler Gear) TS82-01-01-00...
- Page 11 PTO SHAFT PART NO DESCRIPTION PART NO DESCRIPTION Complete Female End PTO DP1075-40 PTO Yoke Series 40 DP1074M-40 Shielding Series 20-40 DP1075-60 PTO Yoke Series 60 (Implement End) Complete Female End PTO Female Yoke & Tube - Series 40 DP1079-40 DP1074M-60 Shielding Series 60 (Implement (Tractor End)
- Page 12 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-TSXXX USER MANUAL...
