- Page 1 REAR MOUNT ROUND ROTARY CUTTERS BE-RCRXXXG OPERATIONS & PARTS MANUAL FOR MODELS: • BE-RCR350G • BE-RCR400G • BE-RCR500G • BE-RCR600G PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER...
-
Page 2: Table Of Contents
TABLE OF CONTENTS GENERAL INORMATION & SAFETY PREPARATION OPERATION MAINTENANCE TROUBLESHOOTING EXPLODED VIEW & PARTS LIST... - Page 3 TO THE CUSTOMER This manual contains valuable information about your new mower. It has been carefully prepared to give you helpful suggestions for operating, adjusting, and servicing. Keep this manual in a convenient place for quick and easy reference. Study it carefully, only by proper care and operation can you expect to receive the service and long life designed and built into this mower.
- Page 4 EQUIPMENT SAFETY GUIDELINES Safety of the operator and bystanders is one of the main concerns in designing and developing a mower. However, every year accidents occur which could have been avoided by a few moments of thought and a more careful approach to handling equipment. You, the operator, can avoid many accidents by observing the following precautions and insist those working with or for you adhere to them.
-
Page 5: Preparation
STEP 5 Grease the following zerks: *Both U-Joints on the PTO shaft STEP 6 Inspect all guards to insure they are in good working order. If not replace before using. STEP 7 Check all bolts and nuts to insure they are tight and secure. CAUTION: DO NOT overfill gearbox. - Page 6 Most accidents occur because of neglect or carelessness. Keep all assistants and bystanders several hundred feet from the operating Rough Cutting Mower. When machine is operated in populated areas where thrown objects could injure persons or property, operation must be stopped if anyone comes within a few hundred feet. The majority of the accidents involve entanglement on the driveline, injury of bystanders by the objects thrown by the rotating blades, and operators being knocked are most likely to occur with machines that are then being run over by the mower.
- Page 7 TRANSPORT SAFETY Always observe state and local laws governing highway safety and the travel of farm machinery on public roads. The use of flashing amber lights is acceptable in most locations. However, some locations prohibit use. Local laws should be checked for all lighting and marking requirements. When driving the tractor and equipment on roads or highways use flashing amber warning lights and a slow- moving vehicle (SMV) identification emblem.
-
Page 8: Operation
OPERATION CUTTING HEIGHT ADJUSTMENT To prevent blades from striking the ground, your rough cut mower should be set to the highest position that will give you the desired cutting height. By setting your mower up this way, you reduce blade wear and stress on the mower. -
Page 9: Maintenance
MAINTENANCE 1. Periodically check and maintain proper gear oil level. 2. Approximately every 8 hours, grease spindles, roller axle, wheel forks, wheel axles, PTO shaft universal joints, and PTO telescoping surface. NOTE: Use a high-temp / multi-purpose grease. 3. Before each use check to make sure all safety features are installed and working properly. 4. - Page 10 STORAGE SAFETY Following use, or when unhooking the mower, disengage the PTO, shop the tractor, set the brakes, shut off the engine and remove the ignition keys. Store the unit in an area away from human activity. Do not park equipment where it can be exposed to direct contact with livestock for long periods of time. Damage to mower and/or livestock injury could result.
-
Page 11: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY 1. Mower not lever side to side 2. Blades dull or bent Level 3pt Hitch linkage on Tractor. 3. Carrier ROM too low Sharpen or replace blades. 4. Field conditions are so wet that the Use correct PTO speed too wet to mow. - Page 12 PROBLEM POSSIBLE CAUSE POSSIBLE REMEDY 1. Check gearbox bolts 2. Check for loose nuts on 3. Check if output shafts is bent, oil will Tighten if loose normally leak from bottom seal Tighten if loose 4. Check if blades are free-swinging Replace shaft is bent 5.
-
Page 13: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST BE-RCRxxxG USER MANUAL... - Page 14 REF PART NO DESCRIPTION REF PART NO DESCRIPTION 360001 Main deck 360017 A frame 360002 Rear rubber guard 360018 Height adjustment bar M10 x 30 Round head carridge 363503 360019 bolt 360403 M10x25 Round head carridge 20 360020 Gear box bolt 360503 360021...
- Page 15 BE-RCRxxxG USER MANUAL...
- Page 16 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 BE-RCRxxxG USER MANUAL...
