Kyongbo Electric K-PAM 10 Series User Manual

Digital integrated protection relay
Hide thumbs Also See for K-PAM 10 Series:

Advertisement

Quick Links

Download this manual
Digital Integrated Protection Relay
User Manual
K-PAM 10 Series

Advertisement

loading
Need help?

Need help?

Do you have a question about the K-PAM 10 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kyongbo Electric K-PAM 10 Series

Summary of Contents for Kyongbo Electric K-PAM 10 Series

  • Page 1 Digital Integrated Protection Relay User Manual K-PAM 10 Series...
  • Page 2 Digital Integrated Protection Relay K-PAM 10 Series K-PAM 10 Series is a multi-functional digital Integrated protection relay that provides high-precision measurement and reliable protection relay function for power supply and distribution facilities. Various protection elements and measuring elements can be used to protect not only distribution feeders, but also motors, busses, generators, solar power, ESS, and wind power generators.
  • Page 3 C o n t e n t s K-PAM 10Series Menu Front Exterior Rear Exterior CB Control Method Power System Setting Method Protection relay Element Setting Method Contact Output Test Method How to check when a fault occurs How to check measurement after field installation Frequently Asked Questions K-PAM 10Series Control Circuit Diagram K-PAM 10Series External Wiring...
  • Page 4 Kyongbo Electric Co., Ltd. K-PAM 10Series Menu Configuration ■ DG10 MENU RELAY SETTING OCR1 OCR2 OCR3 OCGR1 MEASUREMENT VOLTAGE OCGR2 CURRENT DOCR1 POWER DOCR2 ENERGY DOCGR1 FREQUENCY DOCGR2 ENERGY CLEAR OVR1 OVR2 OVR3 RECORDS EVENT LIST UVR1 FAULT LIST UVR2...
  • Page 5 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series ■ S10 MENU RELAY SETTING OCR1 OCR2 OCR3 OCGR1 MEASUREMENT VOLTAGE OCGR2 CURRENT OCGR3 POWER DOCGR ENERGY FREQUENCY OVR1 ENERGY CLEAR OVR2 RECORDS OVR3 EVENT LIST...
  • Page 6 Kyongbo Electric Co., Ltd. ■ F10 MENU RELAY SETTING OCR1 OCR2 OCR3 VOLTAGE MEASUREMENT OCGR1 CURRENT OCGR2 DOCGR1 EVENT LIST DOCGR2 FAULT LIST RECORDS OVGR1 EVENT CLEAR OVGR2 FAULT CLEAR PROT STATUS UBOCR CB STATUS STATUS D/I STATUS D/O STATUS...
  • Page 7 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series ■ M10 MENU RELAY SETTING OCR1 OCR2 OCR3 OVR1 VOLTAGE OVR2 CURRENT MEASUREMENT UVR1 POWER UVR2 ENERGY OVGR1 MOTOR OVGR2 FREQUENCY ENERGY CLEAR NSOVR RESET THERMAL...
  • Page 8 Kyongbo Electric Co., Ltd. Front exterior ① ① ② ③ ④ ⑤ ⑦ ⑥ ① Status LED ④ Custom LED ⑥ CB Close/Open Control Button ② 4x20 Character LCD ⑤ Local/Remote Control Button ⑦ USB-A Type Port ③ Button...

  • Page 9: Reset Key

    Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series Category Description •RUN (GREEN) - Lights up when the relay is running •ERROR (RED) - Lights up when an error occurs as a result of the relay system self-diagnosis •COMM (YELLOW)
  • Page 10 Kyongbo Electric Co., Ltd. Rear exterior ④ ① ④ ② ③ ① Input/Output contact terminal, RS-485 Communication Terminal ③ Frame Ground ② Aux Power Input Terminal ④ CT / ZCT / VT Terminal...
  • Page 11 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series Category Pin Number Description 1a_NO •For Close CB •Contact Capacity : AC 250V 16A / DC 125V 30A 1_COM 2a_NO •For Open CB •Contact Capacity : AC 250V 16A / DC 125V 30A...
  • Page 12 Kyongbo Electric Co., Ltd. CB Control Method ① When controlling in the field, set the control authority to LOCAL. L / R S T A T U S C H A N G E ? E N T E R - Y E S...
  • Page 13 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series Power System Setting Method ① ①Press MENU( ) KEY on the initial screen MENU ② Move the ‘5.POWER SYSTEM’ using the UP( ) and DOWN( ) KEY and input the RIGHT ( )Key.
  • Page 14 Kyongbo Electric Co., Ltd. Protection Relay Element Setting Method ① Press the MENU( ) key on the initial screen MENU ② Use the UP ( ) and DOWN ( ) keys to select ‘1. RELAY SETTING’ category, then input RIGHT ( ) Key.
  • Page 15 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series ▶ OCGR Setting Method ① After selecting ‘OCGR (50N/51N)’ in Protection Relay Element Setting Method ③, press the RIGHT ( ) Key to enter the setting screen.
  • Page 16 Kyongbo Electric Co., Ltd. ▶ DOCR Setting Method ① After selecting ‘DOCR (67)’ in Protection Relay Element Setting Method ③, press the RIGHT ( ) Key to enter the setting screen. ② Use the UP ( ), DOWN ( ) KEY to move the category you want to set, and then enter the ENTER ( ENTER KEY to pop up the password input screen.
  • Page 17 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series ▶ DOCGR Setting Method ① After selecting ‘DOCGR (67N)’ in Protection Relay Element Setting Method ③, press the RIGHT ( ) Key to enter the setting screen.
  • Page 18 Kyongbo Electric Co., Ltd. ▶ UVR Setting Method ① After selecting ‘UVR (27)’ in Protection Relay Element Setting Method ③, press the RIGHT ( ) Key to enter the setting screen. ② Use the UP ( ), DOWN ( ) KEY to move the category you want to set, and then enter the ENTER ( ENTER KEY to pop up the password input screen.
  • Page 19 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series ▶ DPR Setting Method ① After selecting ‘DPR (32P/Q)’ in Protection Relay Element Setting Method ③, press the RIGHT ( ) Key to enter the setting screen.

  • Page 20: Time Delay

    Kyongbo Electric Co., Ltd. ▶ UFR Setting Method ① After selecting ‘UFR (81U)’ in Protection Relay Element Setting Method ③, press the RIGHT ( ) Key to enter the setting screen. ② Use the UP ( ), DOWN ( ) KEY to move the category you want to set, and then enter the ENTER ( KEY to pop up the password input screen.

  • Page 21: Lcd Screen

    Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series LCD SCREEN D / O T E S T 1 / 2 ⇒ 1 . D / O O f f 2 . D / O O f f 3 .
  • Page 22 Kyongbo Electric Co., Ltd. LCD Screen Screen Description P R O T S T A T U S P K P 1 . O C R 1 Protection element not operating 2 . O C G R 1 3 . D O C G R...
  • Page 23 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series How to check measurement after field intallation ① After installing the product in the field, check the measured value when receiving power to check the normal state.
  • Page 24 Kyongbo Electric Co., Ltd. ⑴ Although the circuit breaker is open, UVR contact output is not operating. - If you go to the UVR setting item, there is a BLOCK VOLT setting. This category sets the minimum operating voltage at which UVR operates. For example, if the BLOCK VOLT setting is 0.20pu and the PICKUP setting is 0.8pu, it does not operate when the voltage is below 0.2pu and only operate at a...
  • Page 25 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series K-PAM 10Series Control Circuit Diagram  K-PAM DG10 AC Sequence (example drawing)  K-PAM DG10 VCB DC Sequence (example drawing) MCCB 2P 30/20AT 110V T2-1 T1-3...
  • Page 26 Kyongbo Electric Co., Ltd. DG10 K-PAM 10Series External Wiring (L1) (L2) (L3)  DG10 Terminal : T3 Terminal : T1 D/O1_NO D/O1_COM D/O2_NO D/O2_COM D/O3_NO D/O4_NO D/O3~4_COM D/O5_NC D/O5_COM Terminal : T3 Terminal : T1 D/I1_NO D/I2_NO D/I3_NO D/I1~3_COM Terminal : T1 Terminal : T2 Aux.
  • Page 27 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series  V10 (L1) (L2) (L3) Terminal : T3 Terminal : T1 D/O1_NO D/O1_COM D/O2_NO D/O2_COM D/O3_NO D/O4_NO D/O3~4_COM D/O5_NC D/O5_COM Terminal : T1 D/I1_NO D/I2_NO D/I3_NO...
  • Page 28 Kyongbo Electric Co., Ltd.  M11 (L1) (L2) (L3) Terminal : T1 Terminal : T3 D/O1_NO D/O1_COM D/O2_NO D/O2_COM D/O3_NO D/O4_NO D/O3~4_COM D/O5_NC D/O5_COM Terminal : T3 Terminal : T1 D/I1_NO D/I2_NO D/I3_NO D/I1~3_COM Terminal : T1 Terminal : T2 Aux.
  • Page 29 Digital Integrated Protection Relay K-PAM 10 Series 다기능 디지털 복합 보호계전기 K-PAM 5500 Series K-PAM 10Series Dimensions  Front  Side  Rear  Panel Dimensions •Can replace GD Series, GDR Series, Induction Relay, K-PAM F300 without separate panel processing.
  • Page 30 K-PAM 10Series Install/withdraw Method •Install/withdraw Method ① Attach the enclosure to the panel cut to fit the product. ② Assemble by tightening the enclosed nuts to the four bolts on the corners of the enclosure mounted on the panel. ③ Remove the handle cover of the product, loosen the screw, raise the handle vertically as shown in ④, and attach it to the enclosure.
  • Page 31 Kyongbo Electric Co., Ltd. 04792 Tel : 02)465-1133~7 Fax : 02)465-1333 02)465-1133 5, Seongsuil-ro 12ga-gil, Seongdong-gu, E-mail : webmaster@kyongbo.co.kr (extension 102) Seoul, Republic of Korea Website : http://www.kyongbo.co.kr...
  • Page 32 Digital Integrated Protection Relay User Manual K-PAM 10 Series...
