- Page 1 PC4820 v1.4 PC4820 v1.4 • Installation Manual Installation Manual PC4820 v1.4 PC4820 v1.4 Installation Manual Installation Manual WARNING: This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer. The entire...
- Page 2 Limited Warranty WARNING Please Read Carefully Note to Installers Digital Security Controls Ltd. warrants the original purchaser that for a period of twelve months This warning contains vital information. As the only individual in contact with system users, it is your from the date of purchase, the product shall be free of defects in materials and workmanship responsibility to bring each item in this warning to the attention of the users of this system.
-
Page 3: Table Of Contents
Table of Contents Section 1: Introduction ............1 1.1 PC4820 Access Control Module Specifications..................1 Section 2: Installation and Wiring . - Page 4 PC4820 Access Control Module W i r i n g D i a g r a m Tighten nut to break paint DO NOT connect and make a good connection transformer to receptacle to the cabinet controlled by a switch. SECONDARY 16.5V , 40VA...
-
Page 5: Section 1: Introduction
Section 1: Intro duction The PC4820 is a versatile Dual Card Reader Access Control • Wiegand - standard 26 bit formats module which will enable you to meet the most demanding NOTE: UL has only verified compatibility with the Motor- access control requirements of an installation. -
Page 6: Section 2: Installation And Wiring
Section 2: Installation and Wiring 2.1 Plan Your Installation CAUTION: Local regulations may prohibit “Lock on Power Failure” if the door is used as a fire escape When designing a security system with access control it is route. best to first lay out the system on paper. This will help determine the total number of zones, additional expanders, C. -
Page 7: Outputs - Led, Buz And Out Terminals
The PC4010/4020 will send an Auto-arm Abort reporting tions concerning the installation of magnetic locking code to the monitoring station if the reporting code is pro- devices. grammed. The Auto-arm will restart at the end of the Post- The locking device outputs are controlled according to the pone Arm time (ref # [00020305]) unless the partition has installer-programmed parameters for allowing access to a been manually rearmed. -
Page 8: Pc4820 Connection Chart
Reader LED Flash Rates LED State Access Condition Most access card readers will have an LED output to pro- vide visual feedback when the access card is presented to Access denied/Time Fast flash (state changes 4 the reader. The light will flash in different ways to indicate expired waiting for a privi- times/second the following conditions:... -
Page 9: Pc4820 Access Control Module Reader Connections
PC4820 Access Control Module Reader Connections Polaris Readers (POL-1, POL-2, POL-2KP) ShadowProx Readers NOTE: Only use the +5V power supply when NOTE: Only use the +12V power supply when using using Polaris Readers. ShadowProx Readers. HID Readers Connecting External Power Supplies Cabling Specifications Component Maximum Wire Length... -
Page 10: Section 3: Programming The Pc4820
Section 3: Programming the PC4820 Programming of the PC4820 is performed at the PC4010/ • Unlock on REX: If enabled, tripping a Request To Exit 4020 control panel in Installer’s Programming mode. device will cause the door to unlock for the programmed Refer to Section 4 “How to Program”... -
Page 11: Arming And Disarming With Access Cards
NOTE*: The Door Shunt and Unlock Safety features are 3.5 Zone Assignment for Access Doors only available when the PC4820 is connected to a PC4020 Ref # [0011XX01YY03] where XX = module #; YY = door # v3.2 or higher. Assign each “door”... - Page 12 However, if the partition is disarmed while the door unlock tion(s) the door is assigned to are disarmed. When the par- schedule is active, the door will unlock, and will remain titions are armed, an access code will also be required. unlocked until the scheduled end time.
-
Page 13: Access Level
3.7 Access Level Ref # [0011XX01YY10] where XX = module #, YY = door # Access levels allow specific users to have access to areas of the system at various times of the day. Each door can have multiple access levels assigned to it. Each access level will follow one date schedule. -
Page 14: Section 4: Diagnostics
Section 4: Diagnostics 4.1 Hardware Reset The PC4820 will now indicate to the PC4010/4020 that a hardware default has been performed and the PC4010/ On occasion, it may be necessary to perform a reset of the 4020 will retransmit all programming information back to PC4820 to factory default programming. -
Page 15: Section 5: Pc4820 Programming Worksheet
Section 5: PC4820 Programming Worksheet Record your PC4820 module programming information here. Make one copy of this sheet for each PC4820 you will install. PC4820 Options (XX = module #; YY = door#) [0011] PC4820 Module Number: [0011XX] | _ _____| _ _____| Reader Type Default: [0011XX00] | _ _____| _ _____|... - Page 16 FCC COMPLIANCE STATEMENT CAUTION: Changes or modifications not expressly approved by Digital • Re-orient the receiving antenna Security Controls Ltd. could void your authority to use this equipment. • Relocate the alarm control with respect to the receiver This equipment generates and uses radio frequency energy and if not •...
