Videofied IDC 210 Product Installation Sheet

Product Summary
The Indoor Door Contact IDC 200/601/701 is a wireless
door/window contact designed for use with Videofied
security systems. The contact includes the following
features:
> Uses 1 Duracell CR123A Lithium battery for long life.
> Dual tamper function provides detection for both wall
and cover tamper.
> Transmits check-in/status signal every 8 minutes.
Installation Guidelines
For easier installation, programming and RF testing should be done
to check for good communication between the control panel and all
system devices before mounting system devices. Install the detector
and other system devices in the following order:
Programming/RF Testing - program detector and all other devices
>
into the control panel and test RFcommunication from each intended
device location to the control panel.
Mounting - Mount detector at the tested location.
>
Door
Mounting
Holes
Magnet
P R O D U C T I N S T A L L A T I O N
Wall
Mounting
Holes
Base
www.videofied.com
IDC200/601/702 (white) / IDC 210 (brown)
Mounting Rules
>
Use proper tools and hardware.
>
Mount indoors in a temperature controlled environment.
>
Mount detector on frame and magnet assembly on movable
opening (door, window).
>
Do not exceed 20 mm (6/8") gap between detector and magnet.
>
Magnet spacer must be used to match magnet height with detector
to ensure correct alignment and functionality.
>
Do not install product on ferromagnetic surfaces.
Indoor Door Contact
S H E E T
Doc. - Ref. 219-IDC
Version : April 2014
