HRV1 Mechanical Ventilation with Heat Recovery
Installation Instructions and User Manual
Commissioning Data: to be completed by installer
Date of installation:
Configuration
Normal running speed %
Boost running speed %
FUSION
Left Hand
Factory set to 44%
Factory set to 66%
Right hand
Factory Setting
Installed to
Installed to
05.10.709
Advertisement
Table of Contents
Related Manuals for Greenwood Air Management FUSION HRV1
Summary of Contents for Greenwood Air Management FUSION HRV1
- Page 1 FUSION HRV1 Mechanical Ventilation with Heat Recovery Installation Instructions and User Manual Commissioning Data: to be completed by installer Date of installation: Right hand Configuration Left Hand Factory Setting Normal running speed % Factory set to 44% Installed to Boost running speed % Factory set to 66% Installed to 05.10.709...
-
Page 2: Table Of Contents
Contents 1. MVHR General Description/Physical Specifications . Installation Instructions General Preparation Positioning/Application Condensate Drain Mounting Ducting Guidelines Electrical On Site Commissioning 6 – 9 3. User/Homeowner Information LCD Display 9 Normal/Boost Operation 9 – 10 Timer and Humidity Controls Indicators & Warnings Maintenance (Filters/Heat Exchanger) 1.0 General Description/Physical Specifications The HRV1 is a ventilation system designed to provide an improved indoor air quality in dwellings. As a whole house system, the unit continuously extracts air from the non-habitable rooms and supplies fresh, filtered air to habitable rooms. -
Page 3: Installation Instructions
H R V 1 Installation Instructions and User Manual .0 Installation Instructions .1 General Preparation The HRV1 unit is supplied with 4 x 125mm spigots and template for positioning on ducts to unit for installation. 2.1.1 15mm OR 100mm ducting with connectors can be used (see ancillary section pg 1) to provide performance levels required for compliance with Building Regulations. Please contact Greenwood Airvac Technical Services with any questions. 2.1.2 Installation of the HRV1 should be in accordance with the current editions of Building Regulations and BS7671: IEE Wiring Regulations. 2.1.3 The design, material specification and installation must only be carried out by ‘competent persons’. -
Page 4: Condensate Drain
.3 Condensate It is important that any condensate MUST be drained away. The unit is provided with separate drain and blanking plugs (installed depending on right/left hand configuration). The drain plug allows a condensate drain hose (mm diameter) to be push connected and mechanically secured (See Fig. 1 & 2). 2.3.1 The drain must have a continuous minimum fall of 6mm per 1m run and can either be chased into the wall or run downwards from the unit into the nearest waste water network. 2.3.2 In some instances, a condensate connecting point will already be provided as part of the building design. The position of this point, relative to where the HRV1 unit is to be installed should be checked for any connection misalignment and any necessary adjustment made before proceeding any further. Heat Recovery Unit Condensate drain wall mounted installation Fig . -
Page 5: Electrical
H R V 1 Installation Instructions and User Manual 2.5.2 Flexible or rigid ducting must be used and must fit over the spigots. Flexible ducts must be kept to a minimum. 2.5.3 Where ducts are exposed in unheated areas, such as roof spaces, they must be insulated with at least 25mm of insulation. 2.5.4 If applicable, Fire Dampers MUST BE FITTED in accordance with Part B of the Building Regulations. 2.5.5 Rigid Ducting Install using the least number of fittings to minimise resistance to air flow. Where possible, final connection to grilles and unit should be made with a flexible connection. 2.5.6 Flexible Ducting Ensure ducting lengths are kept to minimum and ducting is pulled taut so that it is smooth and straight. Where bends are necessary and where ducting is run in restricted areas, ensure the ducting is not crushed. 2.5.7 The inlet fresh air supply should be directly from the outside. If supplied through a wall, an external grille should be supplied. If supplied through a roof, a recognised roof terminal should be supplied. -
Page 6: On Site Commissioning
.8 On Site Commissioning This section covers set-up, configuration of the unit on installation and altering pre-set factory settings. For instructions on how to operate the LCD display including initiating the boost mode, maintenance options and indicator warning information, please refer to the user manual section on page 9. When in the configuration mode press [Boost/Exit] to go back to previous setting or screen and [OK] to go forward. To exit configuration mode at any time press [OK] repeatedly until normal running screen appears. 2.8.1 LCD Display OVERRUN TIMER HUMIDITY SENSOR MAINTENANCE FILTER WARNING DELAY TIMER SWITCHED LIVE MODE INTAKE FAN MAINTENANCE MODE ENABLE/DISABLE FILTER FAN WARNING MAINTENANCE BAR INDICATOR FAN WARNING INTAKE FAN STATUS INDICATOR (animated display) EXHAUST FAN STATUS... - Page 7 H R V 1 Installation Instructions and User Manual 2.8.4 Setting ‘Normal Running’ Speed The normal running speed is FACTORY SET AT 44% for intake and exhaust fans. These can be altered in steps of 1% thus you can adjust the fan speed whilst measuring the airflow at the ducting. Please note that the normal running speeds cannot be set higher than the boost speeds or vice versa (boost speeds lower than normal speed). To change the configuration to normal speed: i. Initially, the left hand readout will be flashing ii. Alter the intake running speed by using the [+] or [–] buttons accordingly...
- Page 8 2.8.7 Altering Factory Settings Symbols (from left to right) Intake fan enable/disable Overrun Timer Set Humidity Threshold Set Delay Timer Set Maintenance Factory Settings Altering Factory Setting Options Delay Timer mins 1 – 5 mins (in steps of 1 minute) Overrun Timer 10mins 10 – 30 mins (in steps of 5 minutes) Humidity Activation Level 65% 50 – 99% ( in steps of 5%) i. To adjust the user settings, press [–] or [+] buttons accordingly ii. The display will illuminate and change to show the following (where the left most icon will be flashing) iii. To select an icon use the [–] and [+] buttons to move left & right...
-
Page 9: User/Homeowner Information
H R V 1 Installation Instructions and User Manual 2.8.8 Intake Fan Enable/Disable The Intake fan, supplying replacement air to habitable rooms can be disabled in summer months to reduce the amount of tempered air into the dwelling. It can then be enabled during winter months as required. Select the intake fan enable/disable icon. The display will change to show the ICON ONLY. i. Press the [–] button to disable the intake fan ii. A cross will appear next to the icon as displayed opposite to show the intake fan is disabled The display will revert to normal operation without any further operator intervention, and the icon with the cross will remain on display. In addition, the fan blades of the intake fan icon will stop moving and appear as opposite. To enable the fan again, repeat the operation but press [+] at step 1 above Note: All settings are stored in the memory and will NOT be lost in the event of a power failure. When power is restored, the unit will revert to normal running with all settings unchanged. -
Page 10: Timer And Humidity Controls
3.1.3 Boost Mode (included switch icon next to boost mode) Press [boost/exit] or trigger the ‘switched live’ input, via the installed boost switch (wall mounted switch or light switch). ii. The switch icon appears in the display as indicated iii. The fan will then accelerate to the preset ‘boost’ speed which also activates the DELAY TIMER see below. 3.1.4 Delay Timer & Overrun Timer Delay Timer: Factory set to 2 mins If the boost mode is cancelled BEFORE 2 mins, the fans will return to normal speed immediately ii. If the delay timer expires, the icon will appear in the display as opposite. Overrun Timer: Factory set to 10 mins If the boost is cancelled when the delay timer icon is displayed, the fan will run at ‘boost’ speed until the pre-set overrun timer expires. ii. During this time, the overrun timer icon will appear on the display as indicated. 3.1.5 Humidity Sensor Humidity Sensor: Factory set to 65% The humidity sensor monitors the humidity of the extracted air at all times. -
Page 11: Maintenance (Filters/Heat Exchanger)
H R V 1 Installation Instructions and User Manual If a fan fails, a warning symbol against the faulty fan will appear on the display as opposite. NOTE: Warning symbols will sometimes show momentarily whilst fans are attaining speed. This is normal. 3.1.7 Maintenance WARNING The HRV1 unit must be disconnected from the mains electrical supply before carrying out any maintenance work. Filters should be cleaned at 6 monthly intervals to ensure the unit works to MAINTENANCE FILTER WARNING maximum performance. When a six month period has expired, the Filter warning indicator will flash on the LCD display. Heat Exchanger should be maintained every 2 years, the heat exchanger warning indicator will flash on the LCD display. Filters Pull both of the filters out of the unit using the handles. Remove the filter covers, wash and dry and then replace in unit. - Page 12 The Guarantee Period This Greenwood product (Fusion HRV1) is guaranteed for a period of 2 years from the date of purchase of the Product against fault in manufacture. In case of such fault in manufacture apparent during the Guarantee Period, Greenwood may, at its absolute discretion, repair the product, replace the product free of charge or refund the cost of the product AS LONG AS AND ONLY IF: 1. The Product is returned to Greenwood within the Guarantee Period with evidence of purchase date; 2. The Product has not been misused or handled carelessly or used on an inappropriate voltage supply; 3. Repairs have not been attempted other than by Greenwood’s service staff or authorised dealers; and 4. In Greenwood’s sole discretion, the Product is found to be faulty. If it were not found to be faulty, the Product would be available for collection from the relevant Greenwood’s premises within one calendar month and if it was not collected, it would be subsequently delivered by Greenwood and a delivery charge will be made. (the guarantee) This guarantee does not confer any rights other than those expressly set out above and does not cover any claims for consequential loss, damage or any costs incurred in the replacement of the faulty Product. This Guarantee is offered as an extra benefit and does not affect your statutory right as a consumer. All information believed correct at time of going to press. All goods are sold according to Greenwood Air Management Ltd’s Standard Conditions of Sale which are avail- able on request. All dimensions in millimetres unless otherwise shown. Greenwood Air Management Ltd reserves the right to change specifications and prices without prior notice. © Copyright Greenwood Air Management Ltd 2006. Greenwood Air Management Ltd Greenwood House, Brookside Avenue, Rustington, West Sussex, BN16 3LF. Tel: +44 (0) 1903 771021 Fax: +44 (0) 1903 777122 Email: info@greenwood.co.uk Web: www.greenwood.co.uk or www.partf.com...
