BTD-3M1-5 Dongle Specification
v
<Product Descriptions>
• Bluetooth Dongle Adapter for Radio
• It is a small form factor intended for a broad
range of Original Equipment Manufacturer
(OEM) products
• The quality is good, and sensitivity allows
continuous operation in nearly all Bluetooth
application environments
• It is optimized for applications requiring high
performance, low power, and low cost
• Just one-time pairing with wireless
headset/accessory
• Optional PTT-Z wireless PTT
• No extra power is needed
<Specification>
Type: Bluetooth Dongle Adapter for Portable Radio
Temp: -20℃±2℃ ~ 50℃±2℃
Approx. Weight: 30g
• Fully Qualified Bluetooth v5.0
• Echo cancellation, noise reduction, also
extended features
• High-Quality DAC, Qualcomm CVC built-in
• 80MHz RISC MCU and 80MIPS Kalimba DSP
• RoHS compliant
• HSP / HFP / BLE profile support
PTT-Z
• PTT function: built-in
• Talking Range: Bluetooth class 2, 10 meters
• Display LED: Blue
• TX Current: 16 mA (Average)
• Battery capacity: 300mAH
• Talk Time: 18 hours
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BTD-3M1-5 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mobility Sound BTD-3M1-5

  • Page 1 BTD-3M1-5 Dongle Specification <Product Descriptions> • Bluetooth Dongle Adapter for Radio • It is a small form factor intended for a broad range of Original Equipment Manufacturer (OEM) products • The quality is good, and sensitivity allows continuous operation in nearly all Bluetooth application environments •...
  • Page 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 3 BTD-3M1-5 Blue LED Power Switch PTT Button Micro USB Charging Slide the switch from 0 to 1...
  • Page 4 BT Dongle User Manual <Steps to pair the Bluetooth headset/earpiece> 1. Make sure that the Bluetooth headset/earpiece and PTT button near the Bluetooth dongle are off. 2. Press and hold the PTT button on the Bluetooth dongle while switching on for approximately 3 seconds, it will enter the pairing mode.
