Mobility Sound BTD-3K1-5 Quick Start Manual

BTD-3K1-5 Dongle Specification

• Bluetooth Dongle Adapter for Radio

• It is a small form factor intended for a broad

range of Original Equipment Manufacturer (OEM)

products

• The quality is good, and sensitivity allows

continuous operation in nearly all Bluetooth

application environments

• It is optimized for applications requiring high

performance, low power, and low cost

• Just one-time pairing with wireless

headset/accessory

• Optional PTT-Z wireless PTT

• No extra power is needed

Type: Bluetooth Dongle Adapter for Portable Radio

Temp: -20℃±2℃ ~ 50℃±2℃

Approx. Weight: 30g

• Fully Qualified Bluetooth v5.0

• Echo cancellation, noise reduction, also

extended features

• High-Quality DAC, Qualcomm CVC built-in

• 80MHz RISC MCU and 80MIPS Kalimba DSP

• RoHS compliant

• HSP / HFP / BLE profile support

PTT-Z

• PTT function: built-in

• Talking Range: Bluetooth class 2, 10 meters

• Display LED: Blue

• TX Current: 16 mA (Average)

• Battery capacity: 300mAH

• Talk Time: 18 hours

Table of Contents

Do you have a question about the BTD-3K1-5 and is the answer not in the manual?

Page 1 BTD-3K1-5 Dongle Specification <Product Descriptions> • Bluetooth Dongle Adapter for Radio • It is a small form factor intended for a broad range of Original Equipment Manufacturer (OEM) products • The quality is good, and sensitivity allows continuous operation in nearly all Bluetooth application environments •...
Page 2 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 3 BTD-3K1-5 Blue LED Power Switch PTT Button Micro USB Charging Slide the switch from 0 to 1...
Page 4 BT Dongle User Manual <Procedure for Pairing Bluetooth headset device to dongle> (Note: The Bluetooth-PTT needs to switch off before performing the following steps if it has been connected to the dongle) 1. Switch the power on while pressing and holding the PTT button at the same time for about 3 seconds.
