- Page 1 CROMA KITCHEN HOOD Model Name Model Number AG247701 CRLG60CCHA247701 AG247702 CRLG60CCHA247702 AG247703 CRLG60CCHA247703 AG247704 CRLG90CCHA247704 AG247705 CRLG90CCHA247705 Thank you for choosing Croma Kitchen Hood...
- Page 2 WELCOME Dear Customer, Congratulations on your purchase and welcome to the Croma Family. At Croma, we take pride in our reputation for high-quality products and industry-proven performance. Our products are designed around you so that you can connect with the product quickly. We hope you have a truly rewarding experience with Croma.
-
Page 3: Know Your Product
KNOW YOUR PRODUCT Kitchen Hood: CRLG60CCHA247701, CRLG60CCHA247702, CRLG60CCHA247703, CRLG90CCHA247704, CRLG90CCHA247705 Packaging Contents This package contains the items listed below. In case any of the listed items are missing, immediately contact Croma Customer Care at 1800-572-7662. Items Kitchen Hood Main Unit User Manual Fixture Material Duct Material... -
Page 4: Technical Speci Cations
Features CRLG60CCHA CRLG60CCHA CRLG60CCHA CRLG90CCHA CRLG90CCHA Features 247701 247702 247703 247704 247705 Aesthetic Fusion of √ √ √ √ √ Design and Performance Size (cm) Aluminium Cassette Filter √ Advance Baffle Filter with √ √ PTFE Coating Filter-less Auto Clean √... -
Page 5: Installation Instruction
Installation Instruction Choose the type of drill bit according to the material of the wall. (All dimensions mentioned below are in millimeter) Preparation for Installation a) If you have an outlet to the outside, your kitchen hood can be connected as in the below picture by means of an extraction duct (enamel, aluminium, exible pipe, or in ammable material with an interior... - Page 6 b) Before Installation, turn the unit off and unplug it from the outlet. b) The kitchen hood should be placed at a distance of 65-75 cm above the cooking plane for the best effect. Installation (Outside Vent) • Observe the warning in the instruction sheet concerning the operation of the appliance when air is discharged from the room.
- Page 7 • For the inclined panel Model, need to drill 4 x 8 mm extra holes & xing screws & screw plugs before installation. • Leave up the kitchen hood and hang it onto the wall bracket hook. • Fix the one-way valve to the air outlet of the kitchen hood.
- Page 8 • Drill 2 x 8 mm holes to accommodate plate II. Screw and tighten plate II onto the wall with 2 screws provided. Assemble the kitchen hood onto the unit and x it with 2 screws. For Tower Mode By putting the inner kitchen hood •...
- Page 9 • Drill 2 x 8 mm holes to accommodate plate II. Screw and tighten plate II onto the wall with 2 screws are provided. Assemble the kitchen hood onto the unit and x it with 2 screws. Installation (Inside Vent) If you do not have an outlet to the outside, the exhaust pipe is not required and the installation is similar to the one shown in the...
- Page 10 Usage Instructions Operating Functions Control Panel...
- Page 11 Touch Symbol Function Touch the symbol to switch ON/OFF the kitchen Power ON/OFF hood Touch the symbol to start the fan at a low speed Low Fan Speed & decrease the fan speed when set at a higher speed. Touch the symbol to increase the fan speed to Increase Fan Speed medium or high.
- Page 12 However, over time, some traces of stubborn grease and oil can get stuck inside the kitchen hood. In order to eliminate this stubborn grease and clean the kitchen hood from the inside, we have designed this unique feature. This new generation auto-clean function works with the help of a specially designed heating element xed within the hood.
-
Page 13: Maintenance
MAINTENANCE Keeping Your Kitchen Hood Clean Introducing Croma Kitchen Hood with Easy Clean Technology. Now get rid of the sticky stubborn greases of your kitchen hood with a just wipe of your hand. With its micro-tine ceramic non-stick coating it doesn't let the oil and food particle stick to the surface. -
Page 14: Troubleshooting
If not cleaned the grease residue will saturate the lter. Clean it with a household cleaning agent. Annual Cleaning for activated carbon lter: Apply SOLELY to the kitchen hood (not vented to the outside). This lter traps odours and must be replaced once a year depending on how frequently the appliance is used. -
Page 15: General Safety Instructions
SAFETY INSTRUCTIONS General Safety Instructions • Before using the appliance, check for any damage. If there is any damage, do not use the appliance and immediately contact Croma Customer Care at 1800-572-7662. • Do not operate the appliance with a damaged power cord/plug or if it has been dropped and damaged in any manner. -
Page 16: Electrical Shock Hazard
Product Usage Instructions • Never let the children operate the machine. • The kitchen hood is for home use only and not suitable for other commercial purposes. • The kitchen hood and its lter should be cleaned regularly in order to keep them in good working condition. -
Page 17: Product Packaging
REGULATIONS E-Waste Management Policy This symbol on the product and/or accompanying documents means that the used electrical and electronic products should not be mixed with general household waste. For proper treatment, recoveries, recycling, etc., this product needs to be taken to the designated collection points, where it will be accepted on a free-of-charge basis. -
Page 18: Warranty Terms And Conditions
WARRANTY TERMS & CONDITIONS Your appliance is under warranty for a period of 12 months & the electric Motor and Metallic blower carries an additional warranty of 9 years from the date of purchase. However, the warranty does not cover consumables like bulbs, switches/knobs, charcoal lters, outer body, metal/Glass/Plastic parts, Filter locks, etc. - Page 19 The appliance is used for commercial purposes or at hotels, restaurants, hostels or other similar places. In case the warranty is void due to any of the reasons listed above: the customer shall be liable to pay the cost of all spares and service charges.
- Page 20 LIFETIME WARRANTY TERMS & CONDITIONS 1. Croma de nes the life of the product as 10 years. A lifetime warranty (here in after referred to as LTW) is applicable on selected models and applicable on motors. 2. LTW extends only to the rst customer purchaser and is not transferable.
- Page 21 conditions e. Attacks of pests/rodents/birds making nests in the duct pipe or other acts which are not the fault of Croma. f. Using of duct pipe not matching with outlet diameter. g. Use of non-Croma branded products, recommended accessories, spare parts or other peripheral equipment are excluded from coverage.
-
Page 22: Warranty Card
WARRANTY CARD Product Name : Croma Kitchen Hood Model Name Model Number AG247701 CRLG60CCHA247701 AG247702 CRLG60CCHA247702 AG247703 CRLG60CCHA247703 AG247704 CRLG90CCHA247704 AG247705 CRLG90CCHA247705 • This warranty is applicable on this product for a period of Twelve (12) months from the date of purchase. •...
