Bedienungsanleitung instrucciones de manejo mode d'emploi gebruiksaanwijzing 12806050 Inno A 1000 PO black 12806051 Inno A1000 PO white 12806052 Inno A1000 PO silver 12806060 Inno S1000 PO black 12806061 Inno S1000 PO white 12806062 Inno S1000 PO silver Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo mn Italy. tel +39 0376 771 777 ‐ fax +39 0376 772 140 ‐ email info@ldr.it...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 ENGLISH Thanks for having chosen Luci della Ribalta srl. We hope our products and services meet your requirements, but should this not be the case, we kindly ask you to contact us directly to help us supply you and all our customers with better and better quality. The product you purchased has been manufactured with maximum care and selected components, but should you, for reasons beyond our control, have received it damaged, we kindly ask you to contact the dealer who ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 * fixing and replacement of any component of this product must be carried out exclusively by professional personnel in conformity with the relevant safety and health standards and only with original manufacturer’s components. * replacement of any part of the wiring system must be carried out exclusively by professional personnel in compliance with the original wiring diagrams and with components identical or ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 3. IMPORTANT NOTICE BEFORE THE INSTALLATION 1. Make sure the clamp is correctly fixed and strongly tightened to the spigot at the top of the stirrup 2. Make sure the unit and any accessory (colour scroller, barndoor) are securely fixed to the structure by an individual safety cable 3. Make sure none of the safety cables installed hinders in any way the free movement of the unit 4. CHOOSING THE LAMP Should the fixture you have purchased have been delivered without lamp, please refer to the “Compatible Lamps” section on the LDR product’s specification sheet or choose from one of the below‐listed lamps: 625W P2/10 R7s 230/240V 3200K 150 hrs 1000W P2/7 R7s 230/240V 3200k 200 hrs 1250W P2/12 R7s 230/240V 3200K 200 hrs LDR recommends Philips lamps 5. INSTALLATION OR REPLACEMENT OF THE LAMP ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 Before installing this product make sure the structure you are fixing the product to can withstand its load and the total load of any other unit installed. 1. Hang the unit to the structure and firmly tighten the clamp. 2. Make sure there is enough distance between each unit to allow free movement 3. Make sure there are no obstructions to the free movement of the yoke 4. Fix the safety bond 7. CONNECT TO THE POWER SUPPLY • Make sure the plug you are fitting withstands the lamp power load. • This fixture must be grounded • To perform a correct wiring, please note that the cores in this mains lead are colour‐coded as follows: Ground: green+yellow – Neutral: blue ‐ Live: brown In case the colours of the cores do not correspond to the colour of the connection points on your plug, please proceed as follows: • The green or green and yellow core must be connected to the connection point marked with the letter E or with the symbol or coloured in green or in green‐yellow • The blue core must be connected to the connection point marked with the letter N or with the symbol or coloured in black • The brown core must be connected to the connection point marked with the letter L or with the symbol or coloured in red ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 9. SPARE PARTS All components are available as spare parts. We strongly recommend you always use original LDR components as spare parts. Please refer to our technical assistance should you need to order and/or replace any part of the unit. 10. WARRANTY Our warranty covers all structural and manufacture defects for one year from the date you purchased this product. In case of complaints we strongly recommend you contact the local dealer who supplied the product to you. In any case please report the serial number of the product. Luci della Ribalta srl reserves the right to modify the present document without prior notice. Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 ITALIANO Grazie per aver scelto Luci della Ribalta srl. Speriamo che i nostri prodotti e servizi soddisfino le vostre esigenze, ma se così non fosse vi preghiamo di contattarci direttamente per aiutarci ad offrire a voi ed a tutti i nostri clienti un servizio sempre migliore. Il prodotto che avete acquistato è stato fabbricato con il massimo della cura e con componenti di elevata qualità. Nel caso in cui, per ragioni indipendenti dalla nostra volontà, l’aveste ricevuto danneggiato, vi preghiamo di contattare il rivenditore che ve l’ha fornito. Per aiutarvi in questa evenienza, abbiamo inserito un modulo di reclamo alla fine di questo manuale. Leggete attentamente questo manuale prima di utilizzare questa apparecchiatura elettrica ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 * sostituite la lampada, lo specchio e le lenti se danneggiate o deformate dal calore. Assicuratevi che la lampada sia fredda prima di iniziarne la sostituzione. Per eseguire una corretta installazione della lampada vi preghiamo di attenervi alle istruzioni del fabbricante riportate all’interno della confezione della lampada stessa ed al relativo capitolo di istruzioni di questo manuale. * assicuratevi che il prodotto sia scollegato dall’alimentazione e che sia freddo prima di effettuare la sostituzione del fusibile o di qualsiasi altro componente. * la riparazione e/o sostituzione di qualsiasi componente di questo prodotto deve essere effettuata esclusivamente da personale qualificato in conformità con le specifiche norme di ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 3. IMPORTANTE ‐ PRIMA DELL’INSTALLAZIONE • Assicuratevi che il gancio di sospensione sia correttamente montato e ben fissato allo spinotto sulla sommità della forcella • Assicuratevi che il prodotto ed ogni suo accessorio (colour scroller, paraluce) vengano saldamente fissati alla struttura di supporto con un cavo di sicurezza individuale. • Assicuratevi che nessuno dei cavi di sicurezza impedisca in ogni modo il libero movimento del prodotto. 4. LAMPADE COMPATIBILI Nel caso in cui il prodotto vi fosse stato fornito senza lampada, vi preghiamo di consultare la ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 La forcella è dotata si uno spinotto DIN 16mm per il montaggio dell'apparecchiatura. Prima di installare questo prodotto assicuratevi che la struttura a cui lo state per fissare ne sopporti il peso. 1. Appendete il prodotto alla struttura e chiudete fermamente il gancio 2. Assicuratevi che fra ogni prodotto e quello adiacente ci sia una distanza sufficiente a garantire il libero movimento di ognuno. 3. Assicuratevi che non vi siano ostacoli nel raggio di azione del prodotto. ...
• controllate lo stato dei cablaggi interni ed esterni, e sostituite qualsiasi cavo fosse danneggiato o deformato dal calore o da agenti meccanici. 9. PARTI DI RICAMBIO Tutti i componenti sono disponibili come parti di ricambio. Raccomandiamo l’uso di componenti originali LDR. Nel caso in cui doveste identificare ed ordinare un componente quale parte di ricambio, vi preghiamo di rivolgervi al nostro servizio di assistenza tecnica. 10. GARANZIA La nostra garanzia copre tutti i difetti strutturali e di assemblaggio per un periodo di 12 mesi dalla ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 DEUTSCH Herzlichen Dank, daß Sie sich für Luci della Ribalta entschieden haben. Wir hoffen, daß unser Produkt und unser Service Ihren Ansprüchen gerecht. Sollte dies einmal nicht der Fall sein, so bitten wir Sie, uns direkt anzusprechen, und somit uns zu helfen, Ihnen und unseren weiteren ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 1. INHALT DER VERPACKUNG Prüfen Sie bitte den Ihalt der Verpackung entsprechend dem von Ihnen gekauften Gerät: a. Gerät mit stangbedienbaren Aufhängebügel versehen b. Metallfarbfilterrahmen, 290x270mm, montiert c. Schutzglas, 251x222x5mm, montiert Bei nicht vollständiger Lieferung, setzen Sie sich bitte mit unserem Verkäufer in Verbindung 2. GEWICHT UND ABMESSUNGEN Nettogewicht: 7,0 kg, ohne zusätzliches Zubehör Bruttogewicht: 10,5 kg Abmessungen der Einpackung: 42x68x30h cm VORSICHT Stellen Sie sicher, daß der Aufhängehaken auf dem Montagezapfen des Aufhängebügel gut ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 Stellen Sie sicher, daß das Sicherheitsseil am Gerät sowie an den nicht verschraubten Teilen (z.B. Farbwechsler oder Torblende) montiert ist und dieses die Bewegung des Scheinwerfers nicht einschränkt. 4. AUSWAHL DER LAMPE Sollte der von Ihnen gekaufte Scheinwerfer ohne Lampe geliefert worden sein, so benutzen Sie zur Auswahl der Lampe bitte den Hinweis "Kompatible Lampen" in den Technischen Daten des jeweiligen Produktes von LDR, oder wählen Sie aus folgender Liste: 625W P2/10 R7s 230/240V 3200K 150 Std 1000W P2/7 R7s 230/240V 3200k 200 Std 1250W P2/12 R7s 230/240V 3200K 200 Std LDR empfehlt Philips ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 1. Montieren Sie das Gerät auf die dafür vorgesehenen Beleuchtungszüge oder Montagerohre und ziehen den Aufhängehaken fest 2. Sorgen Sie für genügend Abstand zwischen dem Scheinwerfer‐Verstellbereich und baulichen Hindernissen. 3. Stellen Sie sicher, daß dem Gerät die volle Bewegungsfreiheit gewähleistet wird 4. Befestigen Sie das Sicherheitsseil 7. VERBINDUNG MIT DEM STROHMNETZ • Stellen Sie sicher, daß der Netzstecker, den Sie am Gerät anbringen, für die Lampenleistung ausgelegt ist. • Beziehen Sie sich zur korrekten Verkabelung auf das am Ende des Netzkabels angebrachte Etikett. • Der folgende Farbcode ist für die elektrischen Leiter zu beachten: Gelbgrün: Erdleiter ‐ Blau:Neutralleiter ‐ Braun oder schwarz: Phase • Bevor Sie den Scheinwerfer endgültig einsetzen, überprüfen Sie die korrekte Funktion der Lampe durch Verbinden mit einem durch eine Sicherung geschützten Netanschluß. • Schützen Sie das Gerät durch eine der Lampenleistung entsprechenden Sicherung. Wird das ...
LDR Inno A1000 PO & Inno S1000 PO User’s Manual – 1.0 10. GARANTIE Unsere Garantie auf Struktur‐ und Konstruktionsmängel besteht ein Jahr ab Kaufsdatum des Produktes. Luci della Ribalta srl behält sich das Recht vor, jegliche Veränderung dieser Publikation ohne vorherige Ankündigung vorzunehmen. Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo (MN) Italy Tel. +39 0376 771 777 – fax +39 0376 772 140 – email info@ldr.it – web www.ldr.it ...
Page 18
P .iva 01815640204 c.iso IT01815640204 Luci della Ribalta srl, Via Berna 14, 46042 Castel Goffredo MN Italy - tel +39 0376 771777 - web www.ldr.it - email info@ldr.it IT/015/MN/11 VAT registration # It01815640204 - REA MN 198438 - Authorized Exporter #...
Page 19
modulo di reclamo ‐ complaint form Reklamationsformular ‐ formulaire de réclamation ‐ hoja de reclamaciones fax: +39 0376 772140 Azienda ed Indirizzo ‐ Company's name and address ‐ Firmenname und Addresse ‐ Nom et adresse ‐ Nombre y direcciòn _____________________________________________________________________________________________ __________ _____________________________________________________________________________________________ __________ Nome del rivenditore da cui il prodotto è stato acquistato ‐ Name of the dealer where you have purchased the product ‐ Namen der Firma, die Ihnen das Produkt verkauft hat ‐ Nom de la société qui vous a vendu ce 12806050 Inno A 1000 PO black Prodotto difettoso 12806051 Inno A1000 PO white Faulty product 12806052 Inno A1000 PO silver Defekte s Produkt 12806060 Inno S1000 PO black Produit défectueux Producto defectuoso 12806061 Inno S1000 PO white 12806062 Inno S1000 PO silver Descrizione del problema /Problem found/Beschreibung des Defekts/Description du défaut/Descripciòn del problema ______________________________________________________________________________________________________ ______________________________________________________________________________________________________ ______________________________________________________________________________________________________ ______________________________________________________________________________________________________ Data d'acquisto ‐ Date of purchase ‐ Kaufdatum ‐ Date de l'achat ‐ Fecha de compra ________________________ Si prega di allegare prova d'acquisto ‐ Please attach copy of purchase invoice ‐ Bitte Kaufnachweis beilegen ‐ Veuillez joindre une quittance d'achat ‐ Les rogamos incluyan lcopia de la factura de compra.
Page 20
local de escoamento de residuos, ou a loja na qual efectuou a compra. Richtlinie 2002/96/EU (Elektro- und Elektronik- Altgeräte - WEEE): Benutzerinformationen. Dieses Produkt entspricht Richtlinie WEEE-symbolet (Waste Electrical 2002/96/EU. Das Symbol des auf dem Gerät Electronic Equipment). dargestellten, durchgestrichenen Korbes gibt an, dass Bruken av WEEE-symbolet indikerer at dette Produkt Ende...
