DELUXE BBQ
RANGEHOOD
Model No. GR1200, GR1500
Stainless steel finish
2 different widths, suits most 4 and 6 burner BBQ's
GR1200 - maximum 2000m 3 air flow
GR1500 - maximum 3000m 3 air flow
LED lights at front of the rangehood
Stainless steel baffle filters
For outdoor use only
04174 05/21
Important: Retain these instructions for future use.
Advertisement
Table of Contents
Related Manuals for Gasmate GR1200
Summary of Contents for Gasmate GR1200
- Page 1 Model No. GR1200, GR1500 Stainless steel finish 2 different widths, suits most 4 and 6 burner BBQ’s GR1200 - maximum 2000m 3 air flow GR1500 - maximum 3000m 3 air flow LED lights at front of the rangehood Stainless steel baffle filters For outdoor use only Important: Retain these instructions for future use.
- Page 2 WARRANTY TERMS & CONDITIONS This warranty is not transferable to a subsequent This warranty does not apply to any defect, purchaser if the product is sold by the original deterioration, loss, injury or damage occasioned by or purchaser during the warranty period. as a result of misuse or abuse, negligent handling or storage, normal wear and tear or if the product has not If a warranty fault appears within the warranty period,...
-
Page 3: Important Safety Rules
INSTALLATION - OUTDOOR USE ONLY Read all instructions before installing and operating this The following situations are considered to provide the Rangehood. natural ventilation required for an outdoor domestic barbecue or patio heater to be used: This Rangehood is designed for use above an outdoor domestic gas (propane/natural) barbecue. - Page 4 INSTALLATION - OUTDOOR USE ONLY BALCONIES & VERANDAS An outdoor barbecue or rangehood may be installed and used on a balcony or veranda if, by location and use, it will not cause a hazard and the manufacturer’s instructions allow for such use. It may also be necessary to consult local building laws before installing or using a gas barbecue on a balcony or veranda.
-
Page 5: Important Safety Notice
IMPORTANT SAFETY NOTICE • Disconnect the power supply when changing • Always operate the product from a power source light bulbs. of the same Voltage, Frequency and Rating as indicated on the Product Identification Plate. • This appliance is not intended for use by persons (including children) with reduced •... - Page 6 Rangehood. CONTENTS REQUIRED FOR USE Accessible power pointed fitted within 1m of Medium - GR1200 Rangehood mounting position. The power point must 1 x Rangehood with 2 x 150mm duct adaptors fitted be supplied through a residual current device (RCD) 2 x Chimney covers each 250mm high having a tripping current not exceeding 30mA.
-
Page 7: Rangehood Installation
RANGEHOOD INSTALLATION BEFORE INSTALLING Please consider the following before commencing to install your rangehood. Your rangehood will need to be ducted to ensure it operates and complies with local and national regulations. DUCT MOUNTING OPTIONS You will need some additional parts to complete these installations. - Page 8 RANGEHOOD INSTALLATION - GR1200 The ideal position of the Rangehood is as follows: 1. Height above cooking surface – 1200mm 2. Distance from cooking surface to Rangehood mounting bracket bottom screw hole: • Top mounting holes – 1598mm 1598mm 1200mm...
- Page 9 RANGEHOOD INSTALLATION - GR1500 The ideal position of the Rangehood is as follows: 1. Height above cooking surface – 1200mm 2. Distance from cooking surface to Rangehood mounting bracket bottom screw hole: • Top mounting holes – 1598mm 1598mm 1200mm minimum...
-
Page 10: General Assembly
All motors need to be ducted individually to ensure air flow and suction is adequate and meets all regulations. NEVER Exhaust air or terminate duct work into GR1200 Medium – 2 Ducts 150mm Ø spaces between walls, crawl spaces, ceilings, attics or garages. All exhaust must be ducted to GR1500 Large –... - Page 11 Item 1 & 2. rangehood is level. 4. Mark the top mounting holes on the line discussed in Item 1. These marks should be either side of the centre mark discussed in Item 3, refer below. 12mm GR1200 GR1500...
- Page 12 INSTALLING - MEDIUM & LARGE WALL MOUNT RANGEHOOD DUCTING FLUE SURROUND 1. Remove all tape from the ducts butterfly flaps and Provided are 2 x flue surrounds both 400mm high. ensure they move up and down freely. These are used to finish and cover the motor box and installed ducting.
-
Page 13: Operation
Read all instructions before installing and operating this appliance. IMPORTANT SAFETY NOTICE Read all instructions in this manual before operating the appliance. Save these instructions for future reference. Always leave safety grills and filter in place. Without these components, operating blowers could catch on to hair, fingers and loose clothing. - Page 14 CHANGING REMOTE BATTERY WARNING- KEEP BATTERIES OUT OF REACH OF CHILDREN • Swallowing may lead to serious injury in as little as 2 hours or death, due to chemical burns and potential perforation of the oesophagus. • If you suspect your child has swallowed or inserted a button battery immediately call the 24-hour Poisons Information Centre on 13 11 26 for fast, expert advice.
-
Page 15: Specifications
SPECIFICATIONS MEDIUM - GR1200 SPECIFICATIONS MEDIUM - GR1500... - Page 16 Medium - GR1200 Large - GR1500 Description Finish Marine grade stainless steel #316 Size (mm) 1200 W x 800 D 1500 W x 800 D Total Height 378mm - Not including flue covers Height Above Cooking Surface 1200mm - Minimum...
