- Page 1 KNX LINE COUPLER LC-S.1 User Manual Application Program: ver. 1.0 User Manual: ver. 1.0 module-electronic.ru...
-
Page 2: Table Of Contents
2.3 KNX network installation........ -
Page 3: Basic Information
1 BASIC INFORMATION The KNX line coupler provides a bi-directional data connection between two KNX TP lines or areas and works as a KNX network. KNX TP main line and KNX TP subline are coupled having a galvanic isolation in between. -
Page 4: Specification
4-wire EIB connector (PUSH WIRE spring clips) for standard cable TP1 0,8мм Ø KNX physical address by default 15.15.0 Power supply via KNX bus: 21...30В DC Consumption on the KNX bus (29V DC) < 10mA < 300mW Operation temperature -5°C ... + 45°C Operation humidity 5 ... -
Page 5: Appearance
B. Programming button C. KNX TP main line connector D. KNX TP subline connector 1. LED bus state KNX TP (main line) 2. LED bus state KNX TP (subline) 3. LED telegram traffic KNX TP (main line) 4. LED telegram traffic KNX TP (subline) 5. -
Page 6: Installation And Connection
Removing from DIN rail WIRING DIAGRAMS MAIN KNX bus (Main) KNX bus (Sub) ATTENTION! Installation and connection of the device to the mains must only be carried out by qualified personnel! Be sure to turn off the power before installing or removing the device! Even when the device is turned off, the output terminals can be live! Do not... -
Page 7: Operational Description
2 OPERATIONAL DESCRIPTION In network installations LC-S.1 can be used as KNX TP area/line coupler or KNX TP line repeater. A er connecting the main line, LC-S.1 operates with its default settings. Setting the correct Individual Address is necessary. Only Individual Addresses x.y.0 are allowed. -
Page 8: Tp Repeater Application
2.2 TP REPEATER APPLICATION Any received telegram is routed to all lines irrespective of in which line it is processed. Line repeaters make no use of a filter table. It is therefore not important whether the telegram is generated within a line or whether it is sent from an upper line to a lower line via a coupler. -
Page 9: Knx Network Installation
(x.0.0, 1≤ x ≤15). In ETS up to 15 areas can be defined. If LC-S.1 is used in a KNX system for both purposes, it is only necessary to ensure that the LC-S.1 used as a line coupler has a line coupler address assigned from a free addressing area. Following figure illustrates the LC-S.1 router topology for KNX lines and KNX areas. -
Page 10: Knx Topology
64 bus devices on one line. With use of line repeaters a line can theoretically be extended to 255 bus devices. This means up to four line segments form a single KNX TP line. But it is common practice on exceeding 64 bus devices to insert a new line instead of extending the originating one. -
Page 11: Programming
Individual Address. 2.4.2 INDIVIDUAL ADDRESS ASSIGNMENT To configure the device an interface connection (IP, USB) to the KNX bus system is required. The device is supplied with the Individual Address 15.15.0. The KNX product database entry can be downloaded from the website and from the KNX Online Catalog. -
Page 12: Special Function
2.5 SPECIAL FUNCTION The Function Button activates LC-S.1´s special functions. Manual Function and Factory Reset can be activated. It depends on time the Function Button is being pressed. 2.5.1 MANUAL FUNCTION During normal operation a rather short press (≈ 3 sec) activates and deactivates the Manual Function. When the Manual Function is active, either all Physical Telegrams or all Group Telegrams or both pass the LC-S.1 without filtering. -
Page 13: Led Status Display
2.5.3 LED STATUS DISPLAY Number Colour Comment Bus state KNX TP orange (main line) Bus state KNX TP green LED is <off> if not connected (subline) Group address routing green: filter orange: route all Individual address red: block all routing Table 1. -
Page 14: Ets Database Parameters Coupler
3 ETS DATABASE PARAMETERS COUPLER All screen shots are related to the LC-S.1 database V3.1 in ETS5. 3.1 GENERAL Figure 6. General tab parameters Setting ETS Parameter Comment {Factory Default} disabled pass all telegrams Configuration setting for telegram routing when Manual function pass all physical telegrams the Manual Function is active. -
Page 15: Main Line
3.2 MAIN LINE For Group Telegrams and Physical Telegrams the setting «transmit all» is intended only for testing purposes. Please do not use for normal operation. If the parameter «Send confirmation on own telegrams» is set to «yes», the LC-S.1 systematically sends an ACK on any own routed telegram. - Page 16 Setting ETS Parameter Comment {Factory Default} block: no telegrams are routed Group: filter, Physical: block telegrams entered in the filter Group and Physical: filter filter: table are routed Group: route, Physical: filter Telegram routing Group and Physical: route route: all telegrams are routed configure {Group and Physical: filter} the following parameters must...
-
Page 17: Subline
3.3 SUBLINE For Group Telegrams and Physical Telegrams the setting «transmit all» is intended only for testing purposes. Please do not use for normal operation. Figure 8. Subline tab parameters module-electronic.ru page 17... - Page 18 Setting ETS Parameter Comment {Factory Default} block: no telegrams are routed Group: filter, Physical: block telegrams entered in the filter Group and Physical: filter filter: table are routed Group: route, Physical: filter Telegram routing Group and Physical: route route: all telegrams are routed configure {Group and Physical: filter} the following parameters must...
-
Page 19: Ets Database Parameters Repeater
4 ETS DATABASE PARAMETERS REPEATER All screen shots are related to the LC-S.1 database file R3-0f in ETS5. 4.1 GENERAL Figure 9. General tab parameters Setting ETS Parameter Comment {Factory Default} disabled pass all telegrams Configuration setting for telegram routing when Manual function pass all physical telegrams the Manual Function is active. -
Page 20: Main Line
4.2 MAIN LINE For Group Telegrams and Physical Telegrams the setting «transmit all» is intended only for testing purposes. Please do not use for normal operation. If the parameter «Send confirmation on own telegrams» is set to «yes», the LC-S.1 systematically sends an ACK on any own routed telegram. - Page 21 Setting ETS Parameter Comment {Factory Default} route: all telegrams are routed. Group and Physical: route Telegram routing configure {Group and Physical: route} the following parameters must configure: be set manually. transmit all Physical telegrams are all routed. џ Physical telegrams block Physical telegrams are all blocked.
-
Page 22: Subline
4.3 SUBLINE For Group Telegrams and Physical Telegrams the setting «transmit all» is intended only for testing purposes. Please do not use for normal operation. Figure 11. Subline tab parameters module-electronic.ru page 22... - Page 23 Each telegram on the subline is confirmed by џ {always} an ACK. Telegrams sent out to the subline are џ Send confirmation confirmed by added ACK. on own telegrams {yes} No ACK confirmation. џ Table 8. Subline (KNX TP) tab parameter settings module-electronic.ru page 23...
-
Page 24: State Of Delivery
5 STATE OF DELIVERY 5.1 DEFAULT FACTORY SETTING General Individual Address 15.15.0 Main line Group telegrams (main group 0…13) filter (filter table is empty) Group telegrams (main group 14…31) route all Physical telegrams filter Physical: Repetition if errors on main line up to 3 repetitions Group: Repetition if errors on main line up to 3 repetitions...
