Summary of Contents for KNX Module IC-IP-S.1.0
- Page 1 KNX IP INTERFACE IC-IP-S.1.0 User Manual Application Program: ver. 1.0 User Manual: ver. 1.0 module-electronic.ru...
-
Page 2: Table Of Contents
5.3 KNX ........ -
Page 3: Basic Information
1 BASIC INFORMATION The KNX IP interface provides access to the KNX bus from the Ethernet network using the KNXnet/IP protocol. Using to configure, monitor, visualize and manage devices on the KNX network. • Protocol KNXnet/IP • Up to 4 connections simultaneously •... -
Page 4: Specification
KNXnet/IP, ARP, ICMP, IGMP, HTTP, UPnP discovery, UDP/IP, TCP/IP, DHCP и AutoIP KNX physical address by default 15.15.0 Power supply via KNX bus: 21...30В DC Consumption on the KNX bus (29V DC) < 20mA < 600mW Operation temperature -5°C ... + 45°C Operation humidity 5 ... -
Page 5: Appearance
A. Ethernet connector B. Function button C. Programming button D. KNX TP connector 1. LED IP state 2. LED bus state KNX TP 3. LED telegram traffic IP 4. LED telegram traffic KNX TP 5. Programming LED Green: IP line OK 1. -
Page 6: Installation And Connection
Removing from DIN rail WIRING DIAGRAMS Ethernet KNX bus ATTENTION! Installation and connection of the device to the mains must only be carried out by qualified personnel! Be sure to turn off the power before installing or removing the device! Even when the device is turned off, the output terminals can be live! Do not connect to the outputs a load that exceeds the recommended values! The design of the device meets the requirements of electrical safety according to GOST 12.2.007.0-75. -
Page 7: Knxnet/Ip
As documented in the KNXnet/IP protocol specifications, KNX telegrams can be transmitted encapsulated in IP packets. Ethernet networks as well as Internet can be used to route or tunnel KNX telegrams. In this way, IP interfaces and IP routers are an alternative to USB data interfaces and TP line/area/backbone couplers, respectively. -
Page 8: Operational Description
IC-IP-S.1.0 sends telegrams from/to the TP network to/from the IP network in accordance with the KNXnet/IP protocol specification. Important notes: All KNX IP devices that are intended to communicate with each other via IP must have the same IP џ... -
Page 9: Programming
Programming Mode and Programming LED. 3.3.2 INDIVIDUAL ADDRESS ASSIGNMENT To configure the device an interface connection (IP, USB) to the KNX bus system is required. The device is supplied with the Individual Address 15.15.0. The KNX product database entry (available for ETS4 and higher) can be downloaded from the website and from the KNX Online Catalog. -
Page 10: Function Button
3.4 FUNCTION BUTTON The Function Button activates IC-IP-S.1.0´s special function. Factory Reset can be activated. Device settings of IC-IP-S.1.0 can be reset to manufacturer default values with the Factory Reset function. During the firmware update procedure the Function Button has to be pressed for Boot Mode activation. 3.4.1 FACTORY RESET A long press (≈... -
Page 11: Led Status Display
3.4.3 LED STATUS DISPLAY Number Colour Comment State IP orange Lights red if not connected Bus state KNX TP orange Table 1. LED status display for factory reset a er first button press Number Colour Comment State IP green Bus state KNX TP blinking green Telegram traffic IP... -
Page 12: Ets Database Parameters
Field to enter the device name providing an easy <30 characters allowed> Host name search of the devices by ETS, by Windows Network {KNX IP Interface} and by KNXnet/IP visualisation systems. Table 3. General tab parameter settings 4.2 IP CONFIGURATION Here, HTTP port and IP address assignment can be configured. - Page 13 Setting ETS Parameter Comment {Factory Default} HTTP port 8080 Select one of the two official system ports. {8080} do not use If DHCP is used, no further IP parameters have to DHCP be set. {use} Table 4. IP configuration tab parameter settings, DHCP on Figure 5.
-
Page 14: Web Front-End
MAC address, …), to update its firmware and to adjust the (additional) tunneling addresses. To identify a particular IC-IP-S.1.0 of a KNX network the Programming LED/Programming Mode can be remotely switched on and off without pressing the on-device Programming Button. -
Page 15: Via Windows Network Upnp
5.1.1 VIA WINDOWS NETWORK UPnP Figure 6. IC-IP-S.1.0 as UPnP network device («KNX TP IP») When the UPnP network function is enabled, IC-IP-S.1.0 appears in the Windows Network. A click on the IC-IP-S.1.0 network device opens the web front-end with the standard web browser. If IC-IP-S.1.0 is not visible as an UPnP network device a manual restart is recommended. -
Page 16: Via Ip Address
5.1.2 VIA IP ADDRESS When IP address and HTTP port (80 or 8080) are known, this information is sufficient to access the IC-IP- S.1.0 web front-end by a web browser. The actual IP address is shown in the ETS list of Discovered Interfaces. -
Page 17: Via Mac Address
URL bar as described here (without brackets): http://knx-ipif-{XXYYZZ}:{HTTP port}/ Example1: On the housing side UIMip is labelled with MAC address D0-76-50-11-22-33 and the pre-set HTTP port is 8080. Then, in the web browser´s URL bar has to be entered «http://knx-ipif- 112233:8080/». 5.2 DEVICE INFO A er accessing the web front-end the Device Info tab is shown. -
Page 18: Knx
5.3 KNX Here, all KNX specific addresses are shown. Setting changes can easily be checked. With a simple click on «On» or «Off» Programming Mode can be switched on/off. This function is equivalent to a Programming Button press. Together with the Device Info tab it is easy to distinguish the regarded device (with a certain IP address or MAC address or serial number) from other similar devices in the same IP network. -
Page 19: Firmware Update / Boot Mode
«Abort» button. A er that IC-IP-S.1.0 restarts and continues with normal operation. Step 1: Open the update tab of the web front-end. Figure 10. Update tab Step 2: Activate programming mode (KNX tab or programming button). Figure 11. Update tab and activated programming button module-electronic.ru page 19... - Page 20 Step 3: A er Programming Mode activation give a short press to the Function Button. Then click on the «refresh» button (alternatively, refresh the browser). Figure 12. Update authorized Step 4: When the «request update» button appears it has to be pressed to select the update file and enter «Boot Mode».
-
Page 21: Ip Tunneling Address Assignment
5.5 IP TUNNELING ADDRESS ASSIGNMENT According to the host's Individual Address assignment the first tunneling address (additional Individual Address) of the IC-IP-S.1.0 can only be set by ETS. Please make sure: The additional Individual Addresses for tunneling and the host´s Individual Address have to be different. -
Page 22: State Of Delivery
Step 3: Now open the KNX tab of the web front-end. Click on the «Set» button to set the remaining three tunneling addresses basing on the first tunneling address as follows. Figure 15. First additional individual address (First Tunneling Address) assignment 6 STATE OF DELIVERY 6.1 DEFAULT FACTORY SETTING... -
Page 23: Legal Notice
7 LEGAL NOTICE Lw IP is used in developing the IC-IP-S.1.0. Lw IP is licenced under the BSD license. Copyright (c) 2001-2004 Swedish Institute of Computer Science. All rights reserved. Providing that the following conditions are met redistribution and use in source and binary forms, with or without modification, are permitted: Redistributions of the source code must retain the above copyright notice, this list of conditions џ...
