- Page 1 IPM-21 21.5" Fanless IP Monitor Quick Reference Guide Ed – 24 October, 2018 Copyright Notice Copyright © 2018 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No. E2017IP21A1R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
- Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
-
Page 4: Table Of Contents
IPM-21 Content Getting Started ......................5 Safety Precautions ....................5 Packing List ......................5 System Specifications ................... 6 System Overview ....................9 1.4.1 Rear View ........................9 1.4.2 Membrane ........................9 System Dimensions ..................... 10 4 IPM-21 Quick Reference Guide... -
Page 5: Getting Started
Place all electronic components in a static-dissipative surface or static-shielded bag when they are not in the chassis. 1.2 Packing List 1 x IPM-21 Fanless IP Monitor 1 x packing set includes the followings ... -
Page 6: System Specifications
303.3 mm x 505 mm x 41.7mm Weight 5 kg Color Metal housing black Fanless Reliability EMI Test CE/FCC Class A Safety UL/CB design compatible Dust and Rain IP-65(Front Panel) design compatible Test Vibration Test Sine Vibration test (Non-operation) 6 IPM-21 Quick Reference Guide... - Page 7 Packing Drop Drop Test 1. One corner , three edges, six faces 2. ISTA 2A, IEC-60068-2-32 Test:Ed Operating 0°C ~ 50°C (32°F ~ 122°F), ambient w/ air flow Temperature Operating 5 ~ 90% Relative Humidity, Non-condensing Humidity IPM-21 Quick Reference Guide...
- Page 8 Specifications are subject to change without notice. Remark: When HDMI monitor is connected to HDMI-out connector, the content from Display Over Ethernet (DoE) is switched to HDMI monitor and the content from HDMI-In remains on IP monitor screen. 8 IPM-21 Quick Reference Guide...
-
Page 9: System Overview
Rear View 1.4.2 Membrane Connectors Label Function Note HDMI-IN HDMI-IN connector HDMI-OUT HDMI-OUT connector DC IN DC Power-in connector RJ45 Gigabit Ethernet(with Powered LAN) connector Audio connector Audio 3 x USB 2.0 connector Reset Reset button IPM-21 Quick Reference Guide... -
Page 10: System Dimensions
IPM-21 1.5 System Dimensions (Unit: mm) 10 IPM-21 Quick Reference Guide...
