- Page 1 User Guide Kasa Smart Wi-Fi Light Switch, Single Pole KS200 © 2023 TP-Link 1910013422 REV1.0.0...
-
Page 2: Table Of Contents
Contents About This Guide ····················································································································································1 Introduction ·······························································································································································2 Appearance ·······························································································································································3 Wire Your Switch······················································································································································5 Set Up Your Switch ················································································································································8 Add Your Switch to Home ··································································································································9 Third Party Services ···········································································································································11 Authentication ·······················································································································································15... -
Page 3: About This Guide
Hyperlinks are in teal and underlined. You can click to redirect to a website. More Info • Specifications can be found on the product page at https://www.tp-link.com. • Our Technical Support contact information can be found at the Help center of the Kasa Smart app and the Contact Technical Support page... -
Page 4: Introduction
Introduction TP-Link Smart Wi-Fi Light Switch is a standard, single-pole, wall light switch that can be controlled via your iOS or Android devices. Control your home lighting or ceiling fans on your phone from anywhere, anytime with the Kasa Smart app. Turn fixtures on and off, set schedules, even group them with other Kasa Smart devices. -
Page 5: Appearance
Appearance The Smart Switch is compatible with incandescent, LED, Halogen, and compact fluorescent light bulbs. The switch also includes a white backlight LED indicator to easily locate the switch at night. See the explanation below: Button Explanations Press and hold for about 5s to reset Wi-Fi while keeping other settings. - Page 6 Detach the Wallplate Carefully insert a flat-bladed screw driver the opening at the bottom of the wallplate and pull forward to remove the wallplate. MAC Label Homekit Numeric Code • For Homekit setup. *Images may differ from your actual product. Note: Your can find another Homekit setup code label in the package and stick it anywhere you like as needed for Homekit setup.
-
Page 7: Wire Your Switch
Wire Your Switch Follow the steps below to wire your Smart Wi-Fi Light Switch. If you are not familiar with basic electronical wiring, please consult an electrician. Before You Start 1. Prepare Baisc knowledge of Wiring • Ground: Usually green or copper. •... - Page 8 Wire Your Switch Step 1. Turn Off Power and Remove the Wallplate Step 3. Label and Connect the Wires Turn off the circuit breaker. Then remove the old wallplate of the wall Use the labels and wire nuts to Connect the wires to the smart switch as switch and label the wires.
- Page 9 Step 5. Attach the Wallplate and Turn on Power Step 4. Install Your Smart Switch Attach the wallplate and turn on the circuit breaker. Then the wiring is Gently fold all of the wires back into the wall box. Line up the switch finished.
-
Page 10: Set Up Your Switch
3. Add Device Go to Google Play or the App Store or Open the app. Use your TP-Link ID to log in. Tap the + button in the Kasa Smart app, select scan the QR code below to download the Smart Switches >... -
Page 11: Add Your Switch To Home
Add Your Switch to Home This is a HomeKit-enabled device. You can also add it to the Home app for easy control from your iPhone or iPad. Follow the steps below to add your smart switch via the Home app. Before you start: 1. - Page 12 6. If you still cannot add the smart switch to Home, tap set it up with Tapo manually. Then follow the app instructions to add your smart switch. 7. If the problem persists, refer to the FAQ for detailed instructions: https://www.tp-link.com/support/faq/3390/...
-
Page 13: Third Party Services
Third Party Services Use the Kasa Smart app to pair your Smart devices with Amazon Alexa or Google Home Assistant, and enjoy a full hands-free experience. Kasa helps manage the rest of your smart home too, working with Samsung SmartThings to trigger changes when you arrive home or leave for the day. Launch the Kasa Smart app. - Page 14 1. Set up Amazon Alexa 1. Tap Amazon Alexa. 2. Tap Connect. 3. Sign in with your amazon account.
- Page 15 3. After sign-in, tap LINK. 4. Your TP-Link ID has been successfully linked with your amazon account. You can use Alexa voice commands to control your Smart Wi-Fi Power Strip.
- Page 16 2. Set up Google Assistant 1. Tap Google Assistant. 2. Follow instructions to connect your device to your Google Home. Or find the FAQ at https://www.tp-link.com/en/support/faq/1534/.
-
Page 17: Authentication
Authentication FCC compliance information statement Product Name: Kasa Smart Wi-Fi Light Switch,Single Pole Model Number: KS200 Responsible party: TP-Link USA Corporation Address: 10 Mauchly, Irvine, CA 92618 Website: http://www.tp-link.com/us/ Tel: +1 626 333 0234 Fax: +1 909 527 6804 E-mail: sales.usa@tp-link.com... - Page 18 We, TP-Link USA Corporation, has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
- Page 19 Canadian Compliance Statement This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence- exempt RSS(s). Operation is subject to the following two conditions: (1) This device may not cause interference. (2) This device must accept any interference, including interference that may cause undesired operation of the device. L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement économique Canada applicables aux appareils radio exempts de licence.
- Page 20 BSMI Notice 安全諮詢及注意事項 • 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。 • 清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。 • 注意防潮，請勿將水或其他液體潑灑到本產品上。 • 插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。 • 請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。 • 不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。 限用物質含有情況標示聲明書 設備名稱： 型號（型式）：KS200 Equipment name Type designation (Type) Kasa Smart Wi-Fi Light Switch,Single Pole 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 六價鉻 多溴聯苯 多溴二苯醚 鉛...
- Page 21 備考 1.〝超出 0.1 wt %〞及〝超出 0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值 Note 1：“Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted substance exceeds the reference percentage value of presence condition. 備考 2.〝○〞係指該項限用物質之百分比含量未超出百分比含量基準值。 Note 2：“ ○ ” indicates that the percentage content of the restricted substance does not exceed the percentage of reference value of presence.
- Page 22 CAUTION Electrical switch integrated in this product is only intended for functional purposes. De-energized the product at the circuit breaker before servicing. Explanation of the symbols on the product label Symbol Explanation Alternating current Indoor use only RECYCLING This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE). This means that this product must be handled pursuant to European directive 2012/19/EU in order to be recycled or dismantled to minimize its impact on the environment.
