Summary of Contents for Disc DISC1000
- Page 1 Quick Installations Guide DISC1000 DISC3000 DISC4000 DISC7000...
- Page 2 __________________________________________________________ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D...
-
Page 3: Table Of Contents
Table of Contents Copyrights and Trademarks Safety Instructions Setup Checking the Delivery Removing the Transportation Fixtures Mounting the Stands Placing a DISC Library Connecting a DISC Library Operation Modes RS232 mode SCSI mode SCSI Cable Requirements SCSI cable length Connecting the Robotic to a Host Computer... - Page 4 Auto Start Event Logging Event Logging Functions Technical Data DISC1-7000 Slot Upgrade Agency Approvals FCC Declaration Declaration of Conformity DISC1000 Declaration of Conformity DISC3000 Declaration of Conformity DISC4000 Declaration of Conformity DISC7000 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D...
-
Page 5: Copyrights And Trademarks
_________________________________________________________ CHAPTER 1: COPYRIGHTS and TRADEMARKS Notice of Copyright ■ Disclaimer ■ Trademarks ■ Contacting DISC ■ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D... - Page 6 _________________________________________________________ NOTICE OF COPYRIGHT All rights reserved. Copyright © 2010 by DISC Archiving Systems B.V.. No part of this publication may be reproduced, stored in a retrieval system, or traDISCitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of: DISC Archiving Systems B.V.
- Page 7 Additional Information may be obtained from: DISC Archiving Systems B.V. Waarderweg 52G 2031 BP Haarlem The Netherlands TRADEMARKS USED IN THIS MANUAL DISC, and the DISC logo are registered trademarks of DISC Archiving Systems B.V. 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D...
-
Page 8: Safety Instructions
_________________________________________________________ CHAPTER 2: SAFETY INSTRUCTIONS Intended Use ■ Residual Risks ■ Safety ■ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D... - Page 9 The Optical Library must not be altered or changed in any way that does not comply with applicable safety regulations. REPAIRS Repairs must be carried out only by DISC staff, or DISC authorized service providers. DISC will not be liable for any damage caused from repair by unauthorized individuals.
- Page 10 SAFETY This product is in the used way a Laser Class 1 device. Disc access is accomplished via a laser beam. The laser beam does not represent any risk for the user.
- Page 11 DISC has qualified only writing and reading of media within the DISC libraries. Externally recorded media have to get tested for functionality. Same is valid for media that are recorded within the DISC libraries and shall get read externally utilizing different systems and drives.
- Page 12 _________________________________________________________ Air Filter and Temperature Control All DISCx000 Optical Libraryes are equipped with a fan and an air filter for the cooling air flow and prevention of incoming dust. Do not cover the air intake grill! The air filter shall be checked for dust pollution at least once all half year! If ’Temperature’...
-
Page 13: Setup
Checking the Delivery Removing the Transportation Fixtures Mounting the Stands Placing the Optical Library Operation Modes Connecting the Robotic to a Host Computer Connecting a DISC Library to SAS SAS HBA Settings 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D... -
Page 14: Checking The Delivery
USB to LVD converter * User Manual CD Allen type screw driver Allen type screws 4-6 (missig screws to fully fix the right side cover) Stands 4 (only by NSM/DISC 3-7000) Optical Library * Optional 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D... -
Page 15: Removing The Transportation Fixtures
Library. 2. Remove the right cabinet cover. 3. Remove the transportation fixtures inside the Optical Library. ▼Removing the Transportation Fixtures DISC1000 1. Remove the 14 screws that affix the right cabinet cover of the Optical Library. 2. Remove the right cabinet cover. -
Page 16: Mounting The Stands
_________________________________________________________ MOUNTING THE STANDS For safety reasons, the DISC 3-7000 Optical Libraries must not be operated without the stands. To mount the stands of the NSM/DISC 3-7000 Optical Libraries two persons are needed. •Tilt the Optical Library a little bit to the left and push the two stands for the right side into the holes at the bottom of the Optical Library until the stands „click“... -
Page 17: Placing A Disc Library
_________________________________________________________ PLACING THE OPTICAL LIBRARY The DISCx000 Optical Libraries are intended for use in office and computer networks. After delivery the temperature of the Optical Library should be adapted slowly to the temperature of the room before powering up the Optical Library. Avoid places with •extreme temperatures or excessive sun exposure •high humidity... -
Page 18: Connecting A Disc Library
_________________________________________________________ Connecting a DISC Library Type Plate Robotic Mode and ID Switch RS232 Connections Power Connector SCSI Connector SAS Connectors Power Connector Robotic Mode and ID Switch RS232 Connections Type Plate SCSI Connector SAS Connector 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide... -
Page 19: Operation Modes
Function of ID Switch 0 RS232 mode RS232 ID (robotik) SCSI mode SCSI ID (robotik) DISC internal ------------- use only RS232 MODE The RS 232 mode has to be selected if the robotic of the Optical Library should be controlled via the serial interface (RS 232). The factory default for the RS 232 ID is 00. -
Page 20: Scsi Mode
The ID range for the robotic SCSI ID is 0 to 7, default setting is 0. The SCSI mode must be selected if the DISC Optical Library is controlled via the SCSI bus. The ID switch is used to select the robotics SCSI ID. The range for SCSI IDs is 00 to 07. -
Page 21: Connecting The Robotic To A Host Computer
_________________________________________________________ CONNECTING THE ROBOTIC TO A HOST COMPUTER CONNECTING THE SERIAL Robotic INTERFACE Turn off the Optical Library and the host computer when connecting the cables. Depending on the software which is used to control the robotic of the Optical Library, the serial interface (RS 232) of the Optical Library needs to be connected to the host computer. -
Page 22: Connecting The Scsi Robotic Interface
_________________________________________________________ CONNECTING THE SCSI Robotic INTERFACE to a SCSI Turn off the Optical Library and the host computer when connecting the SCSI cables. Make sure that all connectors are fixed correctly and tight! Loose contacts will cause serious problems! After every disconnection of the SCSI cable(s) Optical Library and host computer have to be rebooted! It is not possible to daisychain the SCSI buses or to connect further external SCSI devices! The LVD bus at the DISCx000 is internally... -
Page 23: Connecting Via Lvd To Usb Converter
CONNECTING THE Robotic via the LVD SCSI to USB CONVERTER With a SAS-based DISC library, the external LVD connector on the back of the DISC library will internally only be connected to the robotics controller. If a SAS-based DISC library was purchased with an LVD SCSI to USB converter, the robotics controller can be connected to a USB port and in that case an LVD HBA is not needed. -
Page 24: Connecting The Drives To A Host Computer
SCSI technologies (like LVD SCSI). This may cause the configuration of a system like a DISC optical library to be confusing. The main difference with SAS is that each target device will have its own link to the HBA, instead of multiple devices sharing a parallel bus like LVD SCSI. - Page 25 _________________________________________________________ SAS Host Bus Adapter (HBA) The DISC libraries have been qualified to work with the following LSI Logic Host Bus Adapters (HBAs) • The LSISAS380IE (PCI-Express) or LSISAS380IX (PCI-X) • The LSISAS3442E-R (PCI-Express) or LSISAS3422X-R (PCI-X) The LSISAS380IE and the LSISAS380IX HBAs have two SFF-8088 type mini SAS connectors.
-
Page 26: Sas Host Bus Adapter (Hba)
LSI Logic HBA used and which external SAS connector is used. Please not that drive 1 is always the lowest drive in a DISC library. When using an LSISAS3442E/X or the lower connector of the LSISAS3801e/X HBA, the target IDs will be assigned to the drives as shown in Table 1. - Page 27 SCSI Target ID DISC Library with 4 to 8 Drives When Connecting a DISC library with 4 to 8 drives, it is recommended to use a LSISAS3801E/X HBA. The external SAS cable should be connected as shown in Figure 1: •...
- Page 28 _________________________________________________________ DISC Library with more than 8 Drives When connecting a DISC Library with more than 8 drives at least two HBAs are needed. As an example we will be configure a DISC7000 with 10 drives. It is recommended to use two LSISAS3801E/X HBAs. It is important to connect the external SAS cables to the correct SAS connectors.
-
Page 29: Sas Hba Settings
The current version is LSI Util 1.62. Use this utility to set the Physical Mapping to ‘1’ (DirectAttached) via the menu option 13: Do this for all LSI Logic SAS HBAs which will be used to connect the DISC library. -
Page 30: The User Interface
_________________________________________________________ CHAPTER 5: THE USER INTERFACE User Interface Diagram User Interface Modes Activating the User Interface PIN Codes Alarm (FAN) Settings Event Logging 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D... - Page 31 _________________________________________________________ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D...
-
Page 32: The User Interface Diagram
Database Reset Lice nse Drive Status Pack Status Service Unload Database Test Enable Elements Upgrade Mag. Auto Pack Disc S ensors Test 4332 4334 4335 4331 4333 Mag. Storage Initialize Media Tray Side A / B Status M ag. Control... -
Page 33: User Interface Modes
_________________________________________________________ USER INTERFACE MODES This chapter contains a very basic description of the Optical Library User Interface. For more detailed information see the jukebox User Manual. The User Interface of the NSM/DISCx000 can be used to configure and operate the Optical Library without using a host application. The User Interface has 3 different modes: USER-MODE NSM/DISCx000... -
Page 34: Activating The User Interface
_________________________________________________________ ACTIVATING THE USER INTERFACE The Optical Library User Interface Function Menu is activated by pressing the F key. To navigate through the User Interface, use the ← and → buttons for horizontal movement. Use ENTER and ESCfor vertical movement. To leave the User Interface, go to the menu root (1) and press the ´ESC´... -
Page 35: Alarm
_________________________________________________________ Alarm The DISCx000 Optical Libraryes are equipped with several sensors that cause an alarm signal and / or alarm message to the host application in case of a certain failure. Following failures may cause an acoustic alarm signal: •Stopped cabinet cooling fan •stop of cooling airflow (covered or blocked air filter) •overheated drives •failure of a redundant power supply... -
Page 36: Mute Alarm Signal
_________________________________________________________ For check and cleaning of the air filter element, please open the filter grill at the right cabinet side and removethe filter frame. The fan and the cooling air flow stops if the air filter element is removed. Do not leave the filter element unmounted for longer time (max. 30 minutes)! Mute Alarm Signal To stop the acoustic alarm signal you can use function F14 at the front panel... -
Page 37: Settings
21 Auto Disc The Auto Disc function (F36) can be set for one of the media inside the DISCx000. If the Auto Disc function is set, the medium will be moved and loaded to a drive automatically when the Optical Library is powered up. The Auto Disc function can be used to start the complete system from a bootable medium. -
Page 38: Event Logging
(movement) is not finished as expected the event counter of this operation is increased. If you have trouble with the robotic of a Optical Library please note the event codes before you contact the DISC hotline. To activate the Event Logging press the ´S´ key, the display shows: Event Logging Function? The keys ´1´... -
Page 39: Technical Data
_________________________________________________________ CHAPTER 6: TECHNICAL DATA Technical Data ■ Slot Upgrades ■ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D... -
Page 40: Disc1-7000
_________________________________________________________ TECHNICAL Data DISC1-7000 DISC1000 DISC3000 DISC4000 DISC7000 Interfaces RS232 RS232 ID Baud rate 9600 Baud 9600 Baud 9600 Baud 9600 Baud Number of start bits Number of data bits Number of stop bits Parity check No parity No parity... - Page 41 Power consumption, 120 W 140 W 180 W 240 W max. 220 W 345 W 450 W 920 W Thermal Emission in DISC1000 DISC3000 DISC4000 DISC7000 Average Dimensions and DISC1000 DISC3000 DISC4000 DISC7000 Weight Width JB / JB 300 mm...
-
Page 42: Slot Upgrade
_________________________________________________________ SLOT UPGRADES DISC DISC1000 , DISC3000 , DISC4000 and DISC7000 Optical Libraryes are available in following capacities: DISC1000U - 45 media slots DISC1000 - up to 105 media slots DISC3000 - up to 270 media slots DISC4000 - up to 400 media slots... -
Page 43: Agency Approvals
_________________________________________________________ CHAPTER 7: AGENCY APPROVALS FCC Declaration ■ Declaration of Conformity ■ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D... -
Page 44: Fcc Declaration
_________________________________________________________ AGENCY APPROVALS FCC DECLARATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 45: Declaration Of Conformity Disc1000
_________________________________________________________ DECLARATION OF CONFORMITY - DISC1000(U) EC-Declaration of CE-Déclaration de EG-Konformitätserklärung Conformity Conformité mit den Richtlinien 89 / 336 / EWG und per 89 / 336 / EEC and 73 / 23 / EWG. avec 89 / 336 / CEE et 73 / 23 / EWG. -
Page 46: Declaration Of Conformity Disc3000
Das Qualitätssicherungssystem von DISC quality assurance system La système d´assurance de la qualité DISC garantiert die Konformität. assures compliance. de DISC garantit la conformité. Hersteller: Manufacturer: Fabricant: DISC Archiving Systems B.V. DISC Archiving Systems B.V. DISC Archiving Systems B.V. -
Page 47: Declaration Of Conformity Disc4000
Das Qualitätssicherungssystem von DISC quality assurance system La système d´assurance de la qualité DISC garantiert die Konformität. assures compliance. de DISC garantit la conformité. Hersteller: Manufacturer: Fabricant: DISC Archiving Systems B.V. DISC Archiving Systems B.V. DISC Archiving Systems B.V. -
Page 48: Declaration Of Conformity Disc7000
Das Qualitätssicherungssystem von DISC quality assurance system La système d´assurance de la qualité DISC garantiert die Konformität. assures compliance. de DISC garantit la conformité. Hersteller: Manufacturer: Fabricant: DISC Archiving Systems B.V. DISC Archiving Systems B.V. DISC Archiving Systems B.V. - Page 49 _________________________________________________________ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D...
- Page 50 _________________________________________________________ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D...
- Page 51 _________________________________________________________ 143715-F DISCx000 SAS Version 3.0 QuickInstallationsGuide Rev. D...
