- Page 1 __________________________________________________________ Quick Installations Guide NSM3000 NSM4000 NSM7000 DISC1000 DISC3000 DISC4000 DISC7000 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C...
- Page 2 __________________________________________________________ 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C...
-
Page 3: Table Of Contents
__________________________________________________________ Table of Contents Table of Contents Copyrights and Trademarks Safety Instructions Setup Checking the Delivery Removing the Transportation Fixtures Mounting the Stands Placing the Optical Library Operation Modes RS232 mode SCSI mode SCSI Cable Requirements SCSI cable length Setting the SCSI ID´s for the Drives Connecting to a Host Computer Connecting the serial robotic interface Connecting the SCSI Interface... - Page 4 Technical Data NSM3-7000 DISC1-7000 Slot Upgrade Agency Approvals FCC Declaration Declaration of Conformity NSM3000 Declaration of Conformity NSM4000 Declaration of Conformity NSM7000 Declaration of Conformity DISC1000 Declaration of Conformity DISC3000 Declaration of Conformity DISC4000 Declaration of Conformity DISC7000 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide...
-
Page 5: Copyrights And Trademarks
_________________________________________________________ COPYRIGHTS and TRADEMARKS Notice of Copyright ■ Disclaimer ■ Trademarks ■ Contacting DISC ■ 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C... - Page 6 In no event shall DISC GmbH, its employees, its contractors or the authors of this documentation be liable for...
- Page 7 _________________________________________________________ Additional Information may be obtained from: DISC GmbH Schultheiss-Kollei-Straße 5 55411 Bingen Germany TRADEMARKS USED IN THIS MANUAL DISC, and the DISC logo are registered trademarks of DISC Group 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C...
-
Page 8: Safety Instructions
_________________________________________________________ CHAPTER 2: SAFETY INSTRUCTIONS Intended Use ■ Residual Risks ■ Safety ■ 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C... - Page 9 The Optical Library must not be altered or changed in any way that does not comply with applicable safety regulations. REPAIRS Repairs must be carried out only by DISC staff, or DISC authorized service providers. DISC will not be liable for any damage caused from repair by unauthorized individuals.
- Page 10 SAFETY This product is in the used way a Laser Class 1 device. Disc access is accomplished via a laser beam. The laser beam does not represent any risk for the user.
- Page 11 DISC has qualified only writing and reading of media within the DISC libraries. Externally recorded media have to get tested for functionality. Same is valid for media that are recorded within the DISC libraries and shall get read externally utilizing different systems and drives.
- Page 12 _________________________________________________________ Air Filter and Temperature Control All DISCx000 Optical Libraryes are equipped with a fan and an air filter for the cooling air flow and prevention of incoming dust. Do not cover the air intake grill! The air filter shall be checked for dust pollution at least once all half year! If ’Temperature’...
-
Page 13: Setup
_________________________________________________________ CHAPTER 4: SETUP Checking the Delivery Removing the Transportation Fixtures Mounting the Stands Placing the Optical Library Operation Modes SCSI CABLE REQUIREMENTS Setting the Drive SCSI IDs Connecting to a Host Computer Connecting Line Voltage 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. -
Page 14: Checking The Delivery
Allen type screws 4-6 (missig screws to fully fix the right side cover) Stands 4 (only by NSM/DISC 3-7000) Optical Library * Units that are equipped with LVD SCSI bus technology are internally terminated and therefore shipped without SCSI terminators. 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide... -
Page 15: Removing The Transportation Fixtures
_________________________________________________________ REMOVING THE TRANSPORTATION FIXTURES ▼ Removing the Transportation Fixtures NSM/DISC3-7000 1. Remove the two screws that affix the right cabinet cover of the Optical Library. 2. Remove the right cabinet cover. 3. Remove the transportation fixtures inside the Optical Library. ▼Removing the Transportation Fixtures DISC1000 1. -
Page 16: Mounting The Stands
_________________________________________________________ MOUNTING THE STANDS For safety reasons, the NSM/DISC 3-7000 Optical Libraryes must not be operated without the stands. To mount the stands of the NSM/DISC 3-7000 Optical Libraryes two persons are needed. •Tilt the Optical Library a little bit to the left and push the two stands for the right side into the holes at the bottom of the Optical Library until the stands „click“... -
Page 17: Placing The Optical Library
_________________________________________________________ PLACING THE OPTICAL LIBRARY The NSMx000 and DISCx000 Optical Libraryes are intended for use in office and computer networks. After delivery the temperature of the Optical Library should be adapted slowly to the temperature of the room before powering up the Optical Library. Avoid places with •extreme temperatures or excessive sun exposure •high humidity... -
Page 18: Operation Modes
Function of ID Switch 0 RS232 mode RS232 ID (robotik) SCSI mode SCSI ID (robotik) DISC internal ------------- use only RS232 MODE The RS 232 mode has to be selected if the robotic of the Optical Library should be controlled via the serial interface (RS 232). The factory default for the RS 232 ID is 00. -
Page 19: Scsi Mode
The max. cable lengh of the external library – host interconnecting LVD SCSI cable may be 9 meters. The DISC libraries do have for every internal LVD SCSI bus 1 screw able female 68pin HD connector at the back panel of the machine. - Page 20 SETTING DRIVE SCSI IDS The ID switches on the rear of the Optical Library are used to set drive SCSI Ids (only NSM/DISC 3-7000). Use a small screw driver to change the ID setting. The ID range for each drive is 00 to 07.
-
Page 21: Connecting To A Host Computer
_________________________________________________________ CONNECTING TO A HOST COMPUTER CONNECTING THE SERIAL Robotic INTERFACE Turn off the Optical Library and the host computer when connecting the cables. Depending on the software which is used to control the robotic of the Optical Library, the serial interface (RS 232) of the Optical Library needs to be connected to the host computer. -
Page 22: Connecting The Scsi Interface
SCSI bus), the robotic interface is connected to the top SCSI bus (SCSI The NSM3000 and NSM4000 can be equipped with 1 or 2, the NSM6000 and the NSM7000 with up to 3 SCSI busses, depending on the quantity and type of the drives used in the Optical Library. - Page 23 _________________________________________________________ SCSI 2 (SE) connector layout at NSM6000 and NSM7000 Layout 3 SCSI SCSI connector Layout 2 SCSI bus busses bus 1 bus 1 not used bus 1 bus 1 bus 2 bus 2 bus 2 not used bus 3 bus 2 bus 3 1.
- Page 24 Ultra 320 SCSI adaptors have to be checked for support of optical devices. Bridges to FibreChannel or iSCSI are usable. DISC recommends the ATTO FC bridges 2390 or 2400 and the ATTO iSCSI bridge 1550. For more information please ask your reseller or the DISC support under support@disc-gmbh.com...
-
Page 25: The User Interface
_________________________________________________________ THE USER INTERFACE User Interface Diagram User Interface Modes Activating the User Interface PIN Codes Alarm (FAN) Settings Event Logging 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C... - Page 26 _________________________________________________________ 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C...
-
Page 27: The User Interface
Lice nse Driv e Status Pack Status Service Unload Database Test Enable Elements Upgrade Mag. Auto Pac k Disc S ensors T est 4332 4334 4335 4331 4333 Mag. Storage Initializ e Media Tray Side A / B Status Mag. -
Page 28: User Interface Modes
_________________________________________________________ USER INTERFACE MODES This chapter contains a very basic description of the Optical Library User Interface. For more detailed information see the julebox User Manual. The User Interface of the NSM/DISCx000 can be used to configure and operate the Optical Library without using a host application. The User Interface has 3 different modes: USER-MODE NSM/DISCx000... -
Page 29: Activating The User Interface
_________________________________________________________ ACTIVATING THE USER INTERFACE The Optical Library User Interface Function Menu is activated by pressing the F key. To navigate through the User Interface, use the ← and → buttons for horizontal movement. Use ENTER and ESCfor vertical movement. To leave the User Interface, go to the menu root (1) and press the ´ESC´... -
Page 30: Alarm
_________________________________________________________ Alarm The DISCx000 Optical Libraryes are equipped with several sensors that cause an alarm signal and / or alarm message to the host application in case of a certain failure. Following failures may cause an acoustic alarm signal: •Stopped cabinet cooling fan •stop of cooling airflow (covered or blocked airfilter) •overheated drives •failure of a redundant power supply... -
Page 31: Mute Alarm Signal
_________________________________________________________ For check and cleaning of the air filter element, please open the filter grill at the right cabinet side and removethe filter frame. The fan and the cooling air flow stops if the air filter element is removed. Do not leave the filter element unmounted for longer time (max. 30 minutes)! Mute Alarm Signal To stop the acoustic alarm signal you can use function F14 at the front panel... -
Page 32: Settings
21 Auto Disc The Auto Disc function (F36) can be set for one of the media inside the DISCx000. If the Auto Disc function is set, the medium will be moved and loaded to a drive automatically when the Optical Library is powered up. The Auto Disc function can be used to start the complete system from a bootable medium. -
Page 33: Event Logging
(movement) is not finished as expected the event counter of this operation is increased. If you have trouble with the robotic of a Optical Library please note the event codes before you contact the DISC hotline. To activate the Event Logging press the ´S´ key, the display shows: Event Logging Function? The keys ´1´... -
Page 34: Technical Data
_________________________________________________________ TECHNICAL DATA Technical Data ■ Slot Upgrades ■ 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C... -
Page 35: Nsm3-7000
_________________________________________________________ TECHNICAL Data NSM3-7000 NSM3000 NSM4000 NSM7000 Interfaces RS232 ID Baud rate 9600 Baud 9600 Baud 9600 Baud Number of start bits Number of data bits Number of stop bits Parity check No parity No parity No parity SCSI Robotic ID... -
Page 36: Disc1-7000
_________________________________________________________ TECHNICAL Data DISC1-7000 DISC1000 DISC3000 DISC4000 DISC7000 Interfaces RS232 ID Baud rate 9600 Baud 9600 Baud 9600 Baud 9600 Baud Number of start bits Number of data bits Number of stop bits Parity check No parity No parity No parity No parity SCSI Robotic ID Operating... - Page 37 _________________________________________________________ Thermal Emission in DISC1000 DISC3000 DISC4000 DISC7000 Average Dimensions and DISC1000 DISC3000 DISC4000 DISC7000 Weight Width JB / JB 300 mm 365/620,5 mm 365/620,5 mm 365/835 mm incl. Stands Height 410 mm 780 mm 980 mm 1500 mm Depth 680 mm 730 mm 730 mm...
-
Page 38: Slot Upgrade
Slot upgrades must be completed in the factory or on site by specially trained service staff. The slot upgrade is not available as a standard field upgrade kit. For more information about slot upgrades, contact your DISC sales office. 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide... -
Page 39: Agency Approvals
_________________________________________________________ AGENCY APPROVALS FCC Declaration ■ Declaration of Conformity ■ 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C... -
Page 40: Fcc Declaration
_________________________________________________________ AGENCY APPROVALS FCC DECLARATION This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 41: Declaration Of Conformity Nsm3000
Sicherheit von Einrichtungen der Safety of information technology Sécurité des matériels de traitement de Informationstechnik. equipment. l´information. DISC quality assurance system assures Das Qualitätssicherungssystem von La système d´assurance de la qualité DISC garantiert die Konformität. compliance. de DISC garantit la conformité. - Page 42 _________________________________________________________ DECLARATION OF CONFORMITY - NSM4000(U) EC-Declaration of CE-Déclaration de EG-Konformitätserklärung Conformity Conformité mit den Richtlinien 89 / 336 / EWG und per 89 / 336 / EEC and 73 / 23 / EWG. avec 89 / 336 / CEE et 73 / 23 / EWG.
- Page 43 Sicherheit von Einrichtungen der Safety of information technology Sécurité des matériels de traitement de Informationstechnik. equipment. l´information. DISC quality assurance system assures Das Qualitätssicherungssystem von La système d´assurance de la qualité DISC garantiert die Konformität. compliance. de DISC garantit la conformité.
- Page 44 Informationstechnik. equipment. l´information. Das Qualitätssicherungssystem von DISC quality assurance system La système d´assurance de la qualité DISC garantiert die Konformität. assures compliance. de DISC garantit la conformité. Hersteller: Manufacturer: Fabricant: DISC GmbH DISC GmbH DISC GmbH Im Tiergarten 24 Im Tiergarten 24...
- Page 45 Informationstechnik. equipment. l´information. Das Qualitätssicherungssystem von DISC quality assurance system La système d´assurance de la qualité DISC garantiert die Konformität. assures compliance. de DISC garantit la conformité. Hersteller: Manufacturer: Fabricant: DISC GmbH DISC GmbH DISC GmbH Im Tiergarten 24 Im Tiergarten 24...
- Page 46 Informationstechnik. equipment. l´information. Das Qualitätssicherungssystem von DISC quality assurance system La système d´assurance de la qualité DISC garantiert die Konformität. assures compliance. de DISC garantit la conformité. Hersteller: Manufacturer: Fabricant: DISC GmbH DISC GmbH DISC GmbH Im Tiergarten 24 Im Tiergarten 24...
- Page 47 Sécurité des matériels de traitement de l´information. Das Qualitätssicherungssystem von DISC quality assurance system DISC garantiert die Konformität. assures compliance. La système d´assurance de la qualité de DISC garantit la conformité. Hersteller: Manufacturer: Fabricant: DISC GmbH DISC GmbH DISC GmbH...
-
Page 48: Rev. C
_________________________________________________________ 143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide Rev. C...
