■ Outdoor Unit
15
Indoor Unit
■
1. Air outlet
2. Air outlet grille: (Field supply)
• Appearance of the Air outlet grille and Air inlet
grille may differ with some models.
3. Display, Control panel
4. Suction grille: (Option)
• Appearance of the suction grille and Air inlet
grille may differ with some models.
5. Air inlet
6. Room temperature sensor:
• It senses the air temperature around the unit.
7. Operation lamp (green)
8. TIMER lamp (yellow): (page 16.)
9. HOME LEAVE lamp (red):
• Lights up when you use HOME LEAVE
operation. (page 14.)
■ Outdoor Unit
11. Air inlet: (Back and side)
12. Refrigerant piping and inter-unit cable
13. Drain hose
Appearance of the outdoor unit may differ from some models.
11
10. Indoor Unit ON/OFF switch:
• Push this switch once to start operation.
Push once again to stop it.
• This switch is useful when the remote controller
is missing.
• The operation mode refers to the following table.
Mode
CDKS COOL
C(F)DXS AUTO
14. Earth terminal:
• It is inside of this cover.
15. Air outlet
12
13
14
Temperature
Air flow rate
setting
22°C AUTO
25°C
AUTO
5
