- Page 1 DAIKIN ROOM AIR CONDITIONER OPERATION MANUAL Enjoy year-round comfort. Enjoy year-round comfort. Enjoy year-round comfort. Enjoy year-round comfort. Enjoy year-round comfort. MODELS CDXP25RVMA CDXP35RVMA CDXM25RVMA CDXM35RVMA CDXM50RVMA CDXM60RVMA CDXM71RVMA...
-
Page 2: Table Of Contents
Read Before Operation Contents „ „ Read Before Operation Care Safety Precautions ........Care and Cleaning ........Names of Parts ..........„ When the Need Arises „ Multi Connection Troubleshooting ........... Note for Multi System ........Safety Precautions Read the precautions in this manual carefully This appliance is filled with R32. -
Page 3: Safety Precautions
Read Before Operation Safety Precautions WARNING • Beware of fire in case of refrigerant leakage. If the air conditioner is not operating correctly, i.e. not generating cool or warm air, refrigerant leakage could be the cause. Consult your dealer for assistance. The refrigerant within the air conditioner is safe and normally does not leak. However, in the event of a leakage, contact with a naked burner, heater or cooker may result in generation of noxious gas. Do not use the air conditioner until a qualified service person confirms that the leakage has been repaired. • Do not attempt to install or repair the air conditioner yourself. Improper workmanship may result in water leakage, electric shock or fire hazards. Please contact your local dealer or qualified personnel for installation and maintenance work. • If the air conditioner is malfunctioning (giving off a burning odour, etc.), turn off power to the unit and contact your local dealer. Continued operation under such circumstances may result in a failure, electric shock or fire hazards. • Be sure to install an earth leakage circuit breaker. Failure to install an earth leakage circuit breaker may result in electric shock or fire. • Be sure to earth the unit. Do not earth the unit to a utility pipe, lightning conductor or telephone earth lead. Imperfect earthing may result in electric shock. CAUTION • Do not use the air conditioner for purposes other than those for which it is intended. Do not use the air conditioner for cooling precision instruments, food, plants, animals or works of art as this may adversely affect the performance, quality and/or longevity of the object concerned. -
Page 4: Names Of Parts
Read Before Operation Names of Parts Indoor Unit Air outlet Air outlet grille (field supply) Air inlet Suction grille (sold separately) • The suction grille is not included. • The appearance of the suction grille may differ between different models. Receiver Indoor temperature sensor • Detects the air temperature around... - Page 5 Read Before Operation Remote controller Wired remote controller Wireless remote controller • For details on remote controller operation, refer to the operation manual included with the remote controller. Outdoor Unit • The appearance of the outdoor unit may differ between different models. Air inlet (back and side) Earth terminal (inside) Model name...
-
Page 6: Multi Connection
Multi Connection Note for Multi System A multi system has one outdoor unit connected to multiple indoor units. Selecting the operation mode When the priority room setting is active Room A Room B but the set unit is not operating or when the priority room setting is inactive When more than one indoor unit is operating, priority is given to Room C... - Page 7 Multi Connection COOL/HEAT mode lock The COOL/HEAT mode lock requires initial programming during installation. Please consult your authorized dealer for assistance. The COOL/HEAT mode lock sets the unit forcibly to either COOL or HEAT operation. This function is convenient when you wish to set all indoor units connected to the multi system to the same operation mode. NOTE • The COOL/HEAT mode lock cannot be activated together with the priority room setting. Priority room setting The priority room setting requires initial programming during installation. Please consult your authorized dealer for assistance. The room designated as the priority room takes priority in the following situations. Operation mode priority • As the operation mode of the priority room takes precedence, you can select a different operation mode from other rooms. [Example] • Room A is the priority room in this example. When COOL operation is selected in room A while operating the following modes in room B, C and D: Operation mode in room B, C and D Status of room B, C and D when the unit in room A is in COOL operation The current operation mode is maintained.
-
Page 8: Care
Care Care and Cleaning CAUTION • Only a qualifi ed service person is allowed to perform maintenance. • Before cleaning, be sure to stop the operation and turn off the circuit breaker. • Do not touch the aluminium fi ns of the indoor unit. If you touch those parts, this may cause an injury. „ Air fi lter Removing the air fi lter. • Rear suction Pull the bottom side of the air fi lter backwards, over the bends. • Bottom suction Pull the fi lter over the bends situated at the backside of the unit. Cleaning the air fi lter. Remove dust from the air fi lter using a vacuum cleaner and gently rinse them in cool water. Do not use detergent or hot water to avoid fi lter shrinking or deformation. After cleaning dry them in the shade. -
Page 9: Air Conditioner
Care CAUTION • Do not operate the air conditioner without filters, this to avoid dust accumulation inside the unit. • Do not remove the air filter except when cleaning. Unnecessary handling may damage the filter. • Do not use petrol, benzine, thinner, polishing compounds, or liquid insecticide. It may cause discolouring or warping. • Do not let the indoor unit get wet. It may cause an electric shock or a fire. • Operation with dusty air filters lowers the cooling and heating capacity and wastes energy. • The suction grille is option. • Do not use water or air of 50°C or higher for cleaning air filters and outside panels. „ Drain pan • Clean the drain pan periodically, or the drain piping may become clogged with dust and may result in water leakage. Ask your dealer to clean them. • Prepare a cover locally to prevent any dust in the air around the indoor unit from getting in the drain pan, if there is a great deal of dust present. -
Page 10: Troubleshooting
When the Need Arises Troubleshooting Before making an inquiry or a request for repair, please check the following. If the problem persists, consult your dealer. Not a problem Check This case is not a problem. Please check again before requesting repairs. Case Description / what to check Operation does not start soon. • This is to protect the air conditioner. You should wait for about 3 minutes. • When ON/OFF button was pressed soon after operation was stopped. - Page 11 When the Need Arises Case Description / what to check An abnormal functioning • The air conditioner may malfunction with lightning or radio waves. Turn the breaker OFF, turn happens during operation. it ON again and try operating the air conditioner with the remote controller. Notes on the operating conditions Mode Operating conditions • If operation continues under any conditions other than those listed in the table, Outdoor temperature: − A safety device may activate to stop the operation. [HEAT PUMP model]: –10.0-46.0°C − D ew may form on the indoor unit and drip from it when COOL or DRY COOL / DRY [COOLING ONLY model]: 10.0-46.0°C operation is selected.
- Page 12 The two-dimensional bar code is a manufacturing code. 3P472684-5A M16B252A (1707) HT...
- Page 13 WIRELESS REMOTE CONTROLLER KIT OPERATION MANUAL MODELS BRC086A11 BRC086A12...
- Page 14 Read before Operation PRIOR TO USE This operation manual is exclusively for instructions on how to use the wireless remote controller. Read also the operation manual attached to the indoor unit and to the outdoor unit for safe usage of the system and maintenance.
-
Page 15: Read Before Operation
Read before Operation WARNING • Do not use a refrigerant other than the one indicated on the outdoor unit when installing, moving or repairing. Using other refrigerants may cause trouble or damage to the unit, and personal injury. • To avoid electric shock, do not operate with wet hands. •... -
Page 16: Names Of Parts
Read before Operation Names of Parts Remote Controller Explained by the HEAT PUMP model Signal transmitter Receiver Display (LCD) • Displays the current settings. (In this illustration, each section is • To use the remote controller, aim shown with all its displays on for the the transmitter at the indoor unit. -
Page 17: Quiet Button
Read before Operation „ Open the front cover ECONO button • ECONO operation. Page 11 MODE selector button • Selects the operation mode. (AUTO/DRY/COOL/HEAT/FAN) Page 7 QUIET button • OUTDOOR UNIT QUIET operation. Page 12 OFF TIMER button (NIGHT SET mode) Page 14 ON TIMER button TIMER CANCEL button... -
Page 18: Preparation Before Operation
Read before Operation Preparation Before Operation CAUTION Incorrect handling of batteries can result in injury from battery leakage, rupturing or heating, or lead to equipment failure. Please observe the following precautions and use safely. • If the alkaline solution from the batteries should get in the eyes, do not rub the eyes. Instead, immediately flush the eyes with tap water and seek the attention of a medical professional. - Page 19 Read before Operation To set the clock Press “ ” is displayed on the LCD. “ ” and “ ” blink. Press to set the current day of the week. Press “ ” blinks. Press to set the clock to the present time. •...
-
Page 20: Basic Operation
Basic Operation AUTO · DRY · COOL · HEAT · FAN Operation The air conditioner operates with the operation mode of your choice. From the next time on, the air conditioner will operate with the same operation mode. To start operation Press and select an operation mode. -
Page 21: Tips For Saving Energy
Basic Operation To change the temperature setting Press • Press to raise the temperature and press to lower the temperature. COOL operation HEAT operation AUTO operation DRY or FAN operation The temperature setting cannot 18.0 – 32.0°C 10.0 – 30.0°C 18.0 –... -
Page 22: Adjusting The Airflow Rate
Basic Operation Adjusting the Airfl ow Rate You can adjust the airfl ow rate to increase your comfort. To adjust the airfl ow rate setting Press • Each pressing of changes the airfl ow rate setting in sequence. AUTO Indoor unit quiet Airflow rate 1-5 (Low to High) •... -
Page 23: Useful Functions
Useful Functions SUPER POWERFUL Operation SUPER POWERFUL operation quickly maximises the cooling (heating) effect in any operation mode. In this mode, the air conditioner operates at maximum capacity. To start SUPER POWERFUL operation Press during operation. • “ ” is displayed on the LCD. •... -
Page 24: Econo Operation
Useful Functions ECONO Operation ECONO operation enables effi cient operation by limiting the maximum power consumption. This function is useful to prevent the circuit breaker from tripping when the unit operates alongside other appliances on the same circuit. To start operation Press during operation. -
Page 25: Outdoor Unit Quiet Operation
Useful Functions OUTDOOR UNIT QUIET Operation OUTDOOR UNIT QUIET operation lowers the noise level of the outdoor unit by changing the frequency and fan speed of the outdoor unit. This function is convenient during the night-time operation. To start operation Press •... -
Page 26: Timer Operation
TIMER Operation ON/OFF TIMER Operation Timer functions are useful for automatically switching the air conditioner on or off in the morning or at night. You can also use the ON TIMER and OFF TIMER together. To use ON TIMER with a 24 hour clock display (24 HOUR ON/OFF TIMER) •... - Page 27 TIMER Operation To use OFF TIMER with a 24 hour clock display (24 HOUR ON/OFF TIMER) • Check that the clock is correct. If not, set the clock to the present time. Page 6 • To set the OFF TIMER in an hours remaining display. Page 15 Press “ ...
- Page 28 TIMER Operation ON/OFF TIMER Operation To use the ON/OFF TIMER with an hours remaining display (COUNT UP-DOWN ON/OFF TIMER) • Check that the clock is correct. If not, set the clock to the present time. Page 6 Press and hold for about 5 seconds, when signal indicator ( ...
-
Page 29: Troubleshooting
When the Need Arises Troubleshooting „ Fault diagnosis by remote controller • The remote controller can receive relevant error codes from the indoor unit. When is held down for about 5 seconds, “ ” blinks in the temperature display section. Press repeatedly until a long beep is produced. - Page 30 Memo...
- Page 32 The two-dimensional bar code is a manufacturing code. 3P477582-2 M16B322 (1706)
