Model 10959-201 and -203
Wall-Mount Audio Messenger Interfaces
Confidentiality Notice .....................................................................................................................1
Product Overview ............................................................................................................................1
Features .................................................................................................................................................... 1
Options ..................................................................................................................................................... 2
Configurations ......................................................................................................................................... 2
Alarms ................................................................................................................................................................... 2
Inputs/Outputs ....................................................................................................................................................... 2
Timed Events ........................................................................................................................................................ 2
Optional Telephone Operation .............................................................................................................................. 3
®
Operation .......................................................................................................................................... 3
Optional ADVANCE Operation ........................................................................................................................... 4
Optional Zone Operation ...................................................................................................................................... 4
Optional AMI Redundancy ................................................................................................................................... 4
Installation ......................................................................................................................................5
Mounting .................................................................................................................................................. 5
Wiring ...................................................................................................................................................... 6
Digital Outputs ...................................................................................................................................................... 6
Digital Inputs ........................................................................................................................................................ 7
Audio .................................................................................................................................................................... 8
System ................................................................................................................................................................... 8
Ethernet ................................................................................................................................................................. 9
Power .................................................................................................................................................................... 9
Optional PBX Connection .................................................................................................................................... 9
®
........................................................................................................................................................... 9
Settings and Adjustments ..............................................................................................................10
Opening the Unit ................................................................................................................................... 10
Level Adjustments ................................................................................................................................ 11
Display Brightness .............................................................................................................................................. 11
Phone Line Levels .............................................................................................................................................. 11
Party Line Levels ................................................................................................................................................ 11
Page Line Levels ................................................................................................................................................. 11
Jumper Settings ..................................................................................................................................... 11
600-Ohm Line Termination ................................................................................................................................ 11
AUDBUS1 Termination ..................................................................................................................................... 11
AUDBUS2 Termination ..................................................................................................................................... 11
Audio Contact Supervision ................................................................................................................................. 11
GAI-Tronics Corporation 400 E. Wyomissing Ave. Mohnton, PA 19540 USA
610-777-1374 800-492-1212 Fax: 610-796-5954
V
ISIT WWW
®
G A I - T R O N I C S
C O R P O R A T I O N
A H U B B E L L C O M P A N Y
T
C
A B L E O F
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
O N T E N T S
Pub. 42004-403F
Advertisement
Table of Contents
Related Manuals for Hubbell GAI-TRONICS 10959-201
Summary of Contents for Hubbell GAI-TRONICS 10959-201
-
Page 1: Table Of Contents
Pub. 42004-403F ® G A I - T R O N I C S C O R P O R A T I O N A H U B B E L L C O M P A N Y Model 10959-201 and -203 Wall-Mount Audio Messenger Interfaces A B L E O F... - Page 2 Table of Contents Pub. 42004-403F 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Date and Time Set Up ........................... 13 Date Set Up ................................. 13 Time Set Up ................................ 13 Operation ............................14 LCD Display at Initial Power Up......................14 LCD Display during Operation ......................
-
Page 3: Confidentiality Notice
. 42004-403F ® G A I - T R O N I C S C O R P O R A T I O N A H U B B E L L C O M P A N Y Model 10959-201 and -203 Wall-Mount Audio Messenger Interfaces Confidentiality Notice... -
Page 4: Options
Pub. 42004-403F 2 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Options Telephone access ® Integration to Page/Party systems Up to 40 user defined inputs and 40 user defined outputs Audio routing to eight zones ... -
Page 5: Optional Telephone Operation
Pub. 42004-403F 3 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Optional Telephone Operation The Telephone Interface has multiple operational modes. The appropriate mode is configurable by the AMI Configuration Tool software application. The AMI can provide passcode-protected telephone access to the system. The AMI can be configured to allow telephone access only if the correct Remote Access Security Code is entered. -
Page 6: Optional Advance Operation
Pub. 42004-403F 4 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Optional ADVANCE Operation ® The Page/Party operation allows for the AMI to play messages/alarms and connect phone calls to an ADVANCE system. When the AMI is interfaced to an ADVANCE system, the operation of the telephone interface is as described above, and includes all page modes. -
Page 7: Installation
Pub. 42004-403F 5 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Installation Power Disconnect. The power cord is the main power disconnect for all units. Disjontion de l’alimentation. Le cordon d’alimentation est la disjonction d’alimentation principale tous les appareils. Para Desconectar la Alimentación: El cable de alimentación es el medio principal de desconexión del equipo. -
Page 8: Wiring
Pub. 42004-403F 6 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Wiring Figure 2. Wiring Connections (Model 10959-203 shown) Digital Outputs Terminal block TB1, labeled is located on the termination PCBA. It provides eight DIGITAL OUTPUTS digital common ground outputs. The outputs are open collector active low. The controlled circuit must use the same voltage used to power the AMI. -
Page 9: Digital Inputs
Pub. 42004-403F 7 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Table 2. Digital Output Assignment Termination Internal Terminal Function or ACT PCBA Label Pin-Out Description TB1-1 Ground or dc common TB1-2 Output 1 TB1-3 Output 2 TB1-4 Output 3 TB1-5 Output 4... -
Page 10: Audio
Pub. 42004-403F 8 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Audio Terminal block TB3, labeled is located on the termination PCBA. It provides connections for AUDIO audio inputs and outputs, and for local RS-485 data connections. Audio connections to a public address amplifier require shielded pair conductors. -
Page 11: Ethernet
Pub. 42004-403F 9 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Ethernet The Ethernet connector, plug J1, is located on the termination PCBA, and is reserved for future implementation. Power The terminal block TB6, labeled CLASS 2 12 –24 VDC is located on the termination PCBA. It provides power connection for the AMI. -
Page 12: Settings And Adjustments
Pub. 42004-403F 10 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Settings and Adjustments Opening the Unit Loosen the four screws on the front cover. Open the front cover of the enclosure to the left. Figure 3. Model 10959-203 AMI (opened with connections and adjustments labeled). f:\standard ioms - current release\42004 instr. -
Page 13: Level Adjustments
Pub. 42004-403F 11 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Level Adjustments Display Brightness R237 on the Main PCBA adjusts the brightness of the LCD display on the front of the assembly. Phone Line Levels On the optional Telephone Interface PCBA two potentiometers adjust telephone audio levels. The Receiver Volume potentiometer, R36, adjusts the volume level from the telephone line. - Page 14 Pub. 42004-403F 12 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Table 8. Termination PCBA Jumper Functions Jumper Output Position Function TB3-5, 6 600-ohm resistor connected (ADVANCE position) Audio bus 1 Default: unterminated TB3-1, 2 600-ohm resistor connected (ADVANCE position) 600 ohms Default: unterminated TB3-3, 4...
-
Page 15: Date And Time Set Up
Pub. 42004-403F 13 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Date and Time Set Up Date Set Up Push buttons on the top edge of the Main PCBA of the unit allows for date set up. Complete the following procedure to set the date. -
Page 16: Operation
Pub. 42004-403F 14 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Operation ® Once the CompactFlash is programmed and installed into the unit, the unit operates based on system inputs and outputs or by manual operation. LCD Display at Initial Power Up At initial power up, the AMI unit completes a self-diagnostic of its settings. -
Page 17: Lcd Display During Operation
Pub. 42004-403F 15 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES LCD Display during Operation The LCD uses various symbols to indicate AMI activity. The VU meter indicates the volume of a page playing. Mute indicates the page audio is muted. ... -
Page 18: Push-Button Operation
Pub. 42004-403F 16 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Push-Button Operation The front panel push buttons allow for various control features including, Play a Message, Stop a message, and Firmware Update. Stop Message This function halts the currently playing message. The button sequence is used: ... -
Page 19: Ami Configuration Tool (Act)
Pub. 42004-403F 17 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES AMI Configuration Tool (ACT) Overview The Audio Messenger Interface Configuration Tool (ACT) software is used to define and change configurations for the Audio Messenger Interface (AMI), and is included with all models of AMI. To ®... -
Page 20: Output
Pub. 42004-403F 18 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Output Each output circuit must be enabled or disabled. If enabled, it must be programmed with several parameters such as: Title, which contains a brief text description of the output and its use ... -
Page 21: Compactflash
Pub. 42004-403F 19 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES CompactFlash ® ® The CompactFlash memory card stores the system configuration, speech messages, and alarm tones. Formatting ® All new CompactFlash memory cards must be formatted specifically for use with the AMI. Formatting is accomplished using the following DOS-format command from Windows command prompt: ®... -
Page 22: Replacement Parts
Pub. 42004-403F 20 of 20 10959-201 -203 W ODEL OUNT UDIO ESSENGER NTERFACES Communications ADVANCE ............................RS-485 Phone line ............................DTMF I/O Control Digital outputs ......................... Open collector Maximum output sink current ..................100 mA per output Maximum output voltage ....................AMI input voltage Isolated output .............. - Page 23 Warranty Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product literature, and if applicable, shall be fit for the purpose specified in the agreed-upon quotation or proposal document.
