COLOR TELEVISION RECEIVER
COLOR TELEVISION RECEIVER
Chassis :
KS1A(P)
Model :
CS15K8SX/XHK
CS21S1ZX/AWE
CZ21S4TX/BOB
CS21S4SX/AWE
CZ21D8TX/BOB
CS21D8ZX/AWE
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
CS21S1SX/XSG
CS21S4WX/BWT
CS21S4STX/AWE
CS21S4ZX/AWE
CS21D8SX/XSG
QQ :376315150
2007.04.26
手机:13942296513
CONTENTS

Advertisement

Table of Contents
loading

Related Manuals for Samsung CS15K8SX/XHK

Summary of Contents for Samsung CS15K8SX/XHK

  • Page 1: Table Of Contents

    COLOR TELEVISION RECEIVER Chassis : KS1A(P) Model : CS15K8SX/XHK CS21S1SX/XSG CS21S1ZX/AWE CS21S4WX/BWT CZ21S4TX/BOB CS21S4STX/AWE CS21S4SX/AWE CS21S4ZX/AWE CZ21D8TX/BOB CS21D8SX/XSG CS21D8ZX/AWE QQ :376315150 2007.04.26 手机:13942296513 COLOR TELEVISION RECEIVER CONTENTS Precautions Specifications and IC Data Disassembly and Reassembly Alignment and Adjustment Troubleshooting Exploded View and Parts List...
  • Page 2 ELECTRONICS © Samsung Electronics Co., Ltd. Feb. 2002 Printed in Korea AA81-00082A...

  • Page 3: Precautions

    Precautions 1. Precautions Follow these safety, servicing and ESD precautions to prevent damage and protect against potential hazards such as electrical shock and X-rays. 1-1 Safety Precautions 1. Be sure that all of the built-in protective devices are replaced. Restore any missing (READING SHOULD NOT BE ABOVE protective shields.
  • Page 4 14. Components, parts and wiring that appear to have overheated or that are otherwise damaged should be replaced with parts that meet the original specifications. Always determine the cause of damage or overheat- ing, and correct any potential hazards. Samsung Electronics...
  • Page 5 Precautions 1-2 Servicing Precautions Warning1: First read the “Safety Precautions” section of this manual. If some unforeseen circumstance creates a conflict between the servicing and safety precautions, always follow the safety precautions. Warning2: An electrolytic capacitor installed with the wrong polarity might explode. 1.
  • Page 6 4. Do not use freon-propelled chemicals. These unpackaged replacement ESDs. Motions such can generate electrical charges that damage as brushing clothes together, or lifting a foot ESDs. from a carpeted floor can generate enough static electricity to damage an ESD. Samsung Electronics...

  • Page 7: Specifications And Ic Data

    Black stripe, 90 degree deflection 21 Inch A51KQJ63X Power Requirements: AC 100~240V, 50/60Hz Antenna Input Impedance: VHF, UHF : Telescopic dipole antenna (75 ohm unbalanced type ) Speaker Impedance 8 ohm, 5W+5W (Dual Type) 16 ohm, 3W (Monitor Type & Dual Type) Samsung Electronics...
  • Page 8 SOUND-AMP (3W x 1CH or 3W x 2CH or 5W x 2CH) KA5Q0765R POWER IC (STR) IC801S CUSTOM REGULATOR (5V, 8V, 3.3V) IC802 KA7632 IC902 24C08/KS28C040 EEPROM PC801S TCET1108 / LTV817B PHOTO COUPLER SIF - IC IC101 U4468B TEMIC Samsung Electronics...
  • Page 9 KS24C080(Pin 8) U4468B(Pin 16) TRANSISTOR SAW-FILTER TRANSISTOR G3956M K9260M 2SD1651 UPC574J 2SD1650 2SD2499 KSC815-Y KA33V KSA614 KSA539-Y BC548 KTC9014 E B C TRANSISTOR LA7840 TDA6107Q KA7632 KSR1012 KSR1010 KSR2010 KTD863-Y KSC2331-Y E C B Fig. 2-1 Semiconductor Base Diagrams Samsung Electronics...
  • Page 10 MEMO...

  • Page 11: Disassembly And Reassembly

    Disassembly and reassembly 3. Disassembly and Reassembly 3-1 Back Cover Removal 1. After removing the screws, press the tension rib and pull the cabinet backwards. 2. To reassemble, press the tension rib (see diagram). Samsung Electronics...
  • Page 12 2. Remove the Anode Cap from the CRT. 3. Remove the main board by pulling it with both hands. Warning: The FBT is charged with high voltage. Before removing the Anode Cap, discharge the voltage through one of the heat sinks on the main board. Samsung Electronics...
  • Page 13 Disassembly and reassembly 3-3 Speaker Removal 1. Remove the speaker by pressing the tension rib. 1. Remove the screws. 2. Remove the speaker by pressing the tension rib. Samsung Electronics...
  • Page 14 Always lift the picture tube by grasping it firmly around the faceplate, (2) Never lift the tube by its neck. (3) Do not scratch the picture tube or apply excessive pressure. Fractures of the glass may cause an implosion. Samsung Electronics...

  • Page 15: Alignment And Adjustment

    “FACTORY” or “Power OFF” keys. 3. Access the Adjustment Mode by pressing the “VOLUME” keys ( Up or Down). The adjust- ment parameters are listed in the accompany- ing table, and selected by pressing the CHAN- NEL keys ( , ). Samsung Electronics...
  • Page 16 SE CAM - L V i s i o n I F L CO 0 ~ 1 T XP T T X P o s i t i o n 0 ~ 1 5 NOTE : PVS,PVA, PHS, parameters must be aligned using the 50Hz vertical-field rates. Samsung Electronics...
  • Page 17 Alignment and Adjustments 4-2-3 Option Bytes In the Service Mode, various can be selected via the Option Table. Example: Option Table : xx xx xx xx SYSTEM AUDIO MONO JACK ZOOM NOR/ZOOM/16:9 AUTO POWER 2nd SIF HOTEL MODE Samsung Electronics...
  • Page 18 7. Do not attempt to connect or disconnect any wires while the TV is turned on. Make sure that the power cord is disconnected before replacing any parts. 8. To protect against shock hazard, use an isola- tion transformer. Samsung Electronics...
  • Page 19 3. Use the P mode key (on the remote control) for the STANDARD picture. 4. Adjust the Screen VR (on the FBT) so that the voltage on the oscilloscope becomes 120+2.5V (See Fig. 4-1). 120 2.5V 14" :120 2.5V 20, 21" : 120 2.5V Fig. 4-1 Samsung Electronics...
  • Page 20 Fig. 4-4 2. Adjust RG,BG so that the levels are suitable to each local area. (c) High-Light Adjustment 1. Set SCT to 55 FL (20”. 21”), 65 FL(14”) in the Factory Service Mode with using CA100. See Fig. 4-4 Samsung Electronics...
  • Page 21 8. Since the 4-pole magnets and 6-pole magnets lines in the center area of the screen. interact, the dot movement is complex (Fig. 4-5). RED/BLUE GREEN BLUE BLUE RED/BLUE GREEN 6-Pole Magnet Movement 4-Pole Magnet Movement Fig. 4-5 Center Convergence Adjustment Samsung Electronics...
  • Page 22 4. Fig. 4-7 4. Adjust with VS (Vertical shift) so that the top margin of the picture is 4. Fig. 4-8 5. Adjust with HS (Horizontal Shift) so that the lion-head pattern and CRT centers are aligned. Samsung Electronics...

  • Page 23: Troubleshooting

    Measure the Check/Replace Voltage of Each Pin TU01S of TU01S Check IC201S Check/Replace Pins 2,3 IC201S See "No Sound" (Video OK) Check IC201S Check/Replace Pins 40,49,50 IC501, IC201S See "No Sound" See "No Video" (Video OK) (Sound OK) Samsung Electronics...
  • Page 24 IC802 (KA7632) Pin 9 (9V) Pin 10 (5V) Check IC201S Check/Replace Pin 1 (3.3V) IC201S Check IC201S Check/Replace Pin 1 : Stand-by : 0V IC201S, (µ-com). Normal : 3.3V Check/Replace Check IC201S, IC201S, Q401, Q402. Pin 33 (H-out) Samsung Electronics...
  • Page 25 IC201S Check IC201S Pins 38/R214, R215 Check IC201S Pin 49 (V-GUARD) Check/Replace Pin 50 (Cut-off) IC201S Pin 51~53 (R,G,B-out) Check IC501 Check/Replace on the CRT PCB IC501 Check/Replace R421, R505 (HEATER 6.3Vrms) D503 (CRT G1 pin) CRT, V999S Samsung Electronics...
  • Page 26 Pin 44 (Sound Out) IC201S Check/Replace Check IC601 Q904, IC201S Pins 6 (0V) Check IC601 Check/Replace Pin 3,13 (B+ 10-12.5V) R814, R815 Check/Replace Check IC601 IC601 Check/Replace A/V Front assembly. 5-5 No TTX Check/Replace Check IC201S IC201S See No Video Samsung Electronics...

  • Page 27: Exploded View And Parts List

    Exploded View & Parts List 6. Exploded View & Parts List 6-1 CS15K8SX/XHK Code No Description Specification Q’ty Remark AA91-00619K ASSY CABINET FRONT;,15K8 EPP,(SPK)SV012P AA64-01730K CABINET-FRONT;15K8,HIPS,HB,G4309,SV012P+ AA64-70127A BADGE-BRAND;-,AL,-,-,L=40,SAMSUNG,SILVER AA64-01371E KNOB POWER;15K8,ABS,HB,G3676,SVM3012 AA61-60003J SPRING-CS;-,SUS304,-,-,OD6,N7,OD6,-,-,-, AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- AA96-10137B ASSY-SPEAKER;-,8OHM,3W,3001-001020,AA39- 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR SPK+CF AA64-01370E KNOB CONTROL;15K8,ABS,HB,G3676,SVM3012...
  • Page 28 KNOB CONTROL;50.53S1,ABS,-,-,-,HB,G3676, 1-12 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR KC+CF 1-13 AA63-50356B GRILLE WOOFER;21S1,SECC,T0.5,-,-,-,-,SV7 1-14 AA96-00163B ASSY SPEAKER;-,8ohm,6W,3001-001034,350/7 1-15 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR SPK+CF AA91-02945A ASSY CPT;CS21S1SX/TAW AA65-30107A CLAMP-D,COIL;20~22 INCH,NYLON 66,V2,-,NT AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,- CRT+CF 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- V999S AA64-31327U CABINET BACK;21S1,HIPS,HB,G4309,D/S 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR CB+CF AA96-20109B ASSY-POWER,CORD;-,CP2/NO(4.0),H/C250,KKP Samsung Electronics...
  • Page 29 1-11 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR KC+CF 1-12 AA96-10146C ASSY SPEAKER;-,8ohm,5W,3001-000274,350/7 1-13 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR SPK+CF AA91-03045A ASSY CPT;CZ21D8TX/BOB 2-1 AA65-30107A CLAMP-D,COIL;20~22 INCH,NYLON 66,V2,-,NT D-COIL 2-2 AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,- CRT+CF 2-3 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- V999S AA64-01422J CABINET BACK;21D8,HIPS,V2,G4309 3-1 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, CB+CF 3-2 AA96-20109B ASSY-POWER,CORD;-,CP2/NO(4.0),H/C250,KKP Samsung Electronics...
  • Page 30 KC+CF 1-13 AA96-00626A ASSY SPEAKER;-,8OHM,15W,001115/001088,35 1-14 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR SPK+CF 1-15 3001-001115 SPEAKER;15W,8ohm,93dB,110 1-16 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR TW+CF AA91-03011A ASSY CPT;CZ21S4TX/BOB AA65-30107A CLAMP-D,COIL;20~22 INCH,NYLON 66,V2,-,NT D-COIL AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,- CRT+CF 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- V999S AA64-00707F CABINET BACK;21S4,HIPS,V2,G4309 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, CB+CF AA96-20109B ASSY-POWER,CORD;-,CP2/NO(4.0),H/C250,KKP Samsung Electronics...

  • Page 31: Electrical Parts List

    ASSY CHASSIS ..5 LS03 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm ..5 LS04 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm ..5 PCB AA41-00139A PCB-STEREO/LINE-ST/MTS-M;DREAM-1,1L,FR-1 S.N.A AA91-03365A ASSY CHASSIS;CS15K8SX/XHK,HONGKONG,KS1A ..5 RS01 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM AA94-07650A ASSY PCB MAIN;CS15K8SX/XHK,KS1A,HONGKONG S.N.A ..5 RS02 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 C901 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm ..5 RS03 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 CLAMP AA65-30018A CLAMP-WIRE;DONG-A,NYLON-66,-,-,-,DATL-60...
  • Page 32 2201-000991 C-CERAMIC,DISC;0.56nF,10%,2kV,Y5P,TP,7.5 ..5 DZ803 0403-000699 DIODE-ZENER;TZP27B,27V,27-30.8V,1W,DO-41 ..5 C812 2401-000262 C-AL;100uF,20%,160V,HR,TP,16x25,7.5 ..5 DZ804 0403-000510 DIODE-ZENER;MTZJ6.2B,6.2V,5.96-6.27V,500 ..5 C813 2401-002290 C-AL;47uF,20%,160V,GP,TP,13x20,5 ..5 DZ805 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500mW,D ..5 C814 2201-000991 C-CERAMIC,DISC;0.56nF,10%,2kV,Y5P,TP,7.5 ..5 DZ806 0403-001317 DIODE-ZENER;MTZJ3.0B,3.01-3.22V,500mW,DO ..5 C816 2201-000375 C-CERAMIC,DISC;0.22nF,5%,50V,RH,TP,12.5x ..5 DZ807 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 Samsung Electronics...
  • Page 33 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm ..5 R117 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 FD801S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M S.N.A ..5 R202 2001-000689 R-CARBON;390KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 GT101 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO S.N.A ..5 R203 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 GT301 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO S.N.A ..5 R204 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 34 AA39-20010D LEAD CONNECTOR-ASSY;,1P,YFH800-01,S,400, ..5 R809 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6..3 AA65-30111A CLAMP-WIRE;ALL MODEL,NYLON,V0,-,WHT,1T 1 S.N.A ..5 R810 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6. AA95-01724B ASSY SUB-A/V,FRONT;S4,KS1ASTEREO,AA95-01 S.N.A ..5 R814 2008-001087 R-FUSIBLE(S);1.8ohm,5%,2W,AG,TP,3.9x12mm ...3 CN702 AA39-20461C LEAD CONNECTOR-ASSY;,11P,YBNH250-11,6709 ..5 R815 2008-001087 R-FUSIBLE(S);1.8ohm,5%,2W,AG,TP,3.9x12mm ...3 CN704A AA39-00094A LEAD CONNECTOR-ASSY;,3(2)P,YBNH250-03,35 Samsung Electronics...
  • Page 35 AA27-00161A DEFLECTION YOKE;15DF,CDY-MT1501A,ST-3,A3 ...3 AA27-00002A MAGNET-CONVERGENCE;-,JH291-SC-OB,29.1MM ...3 AA03-00146A CRT COLOR;A36QDT351X,+380mG,2.5mH,22.5mH AA98-70014G ASSY TBC WIRE(P);-,15inch,NTSC,1P,KS2A/C S.N.A AA27-00077A COIL DEGAUSSING;-,-,4.3mH,20%,70T,9OHM,- ASSY COVER REAR AA90-01975W ASSY COVER REAR;CS15K8SX/XHK AA64-01731H CABINET BACK;15K8,HIPS,V0,G4309 S.N.A AA64-60385B INLAY-BACK;50.5366,PS,T0.3,-,-,BLK,LINE S.N.A AA65-30008A CLAMP-CORD;-,PE,HB,-,BLK,- S.N.A ASSY COVER FRONT AA90-01813W ASSY COVER FRONT;CS15K8SX/XHK AV+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL)
  • Page 36 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..5 C605 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 ..5 C104 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 ..5 C606 2301-000289 C-FILM,PEF;5.6nF,5%,50V,TP,7x6x3,5 ..5 C105 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V ..5 C607 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 C106 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V ..5 C610 2301-000289 C-FILM,PEF;5.6nF,5%,50V,TP,7x6x3,5 ..5 C107 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 ..5 C611 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm Samsung Electronics...
  • Page 37 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY810 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ205 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY813 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ207 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY818 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ301 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D ..5 EY819 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A Samsung Electronics...
  • Page 38 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 ..5 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R504 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 ..5 Q205 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R505 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10 ..5 Q301 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..5 R506 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 Q402 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO- ..5 R510 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics...
  • Page 39 ..5 R911 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-40514A INDICATOR-LED;CT50S1,ACRYL,-,CLR,-,-,- ..5 R912 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-40515T DECORATION-FRONT;21S1,HIPS,-,-,-,HB,BLK, ..5 R913 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-70123D BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,GOLD,R S.N.A ..5 R914 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA96-00163B ASSY SPEAKER;-,8ohm,6W,3001-001034,350/7 S.N.A ..5 R915 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM ..4 3001-001034 SPEAKER;6W,8ohm,90dB,140Hz ..5 R916 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM...
  • Page 40 ..5 CS20 2201-000472 C-CERAMIC,DISC;0.33nF,5%,50V,SL,TP,8.5x3 ..4 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T ..5 CS21 2401-000027 C-AL;4.7uF,20%,50V,GP,TP,5x11,5 ..4 P803S 1404-001156 THERMISTOR-PTC;9OHM,+30%/-20%,220VRMS,27 ..5 CS22 2201-000472 C-CERAMIC,DISC;0.33nF,5%,50V,SL,TP,8.5x3 ..4 PC801S 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST ..5 CS23 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..4 RM901 AA32-00009A MODULE REMOCON;FRP-3521H3,38KHZ,940NM,ME ..5 CS24 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5 7-10 Samsung Electronics...
  • Page 41 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 D901 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, ..5 C604 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 ..5 DZ101 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T ..5 C605 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 ..5 DZ201 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 C606 2301-000289 C-FILM,PEF;5.6nF,5%,50V,TP,7x6x3,5 ..5 DZ203 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO ..5 C607 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 Samsung Electronics 7-11...
  • Page 42 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 EY809 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 Q203 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..5 EY810 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 EY813 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 Q205 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T 7-12 Samsung Electronics...
  • Page 43 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 ..5 R927 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R503 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 ..5 R928 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R504 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 ..5 R929 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R505 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10 ..5 R931 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R506 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R932 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-13...
  • Page 44 AA91-00118V ASSY CABINET FRONT;,21S1 L/S KS1A,(SPK)S ...3 KC+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A ...3 KNOPOW AA61-60003J SPRING-CS;-,SUS304,-,-,OD6,N7,OD6,-,-,-, S.N.A ...3 SPK+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A ...3 AA64-31326M CABINET-FRONT;53S1,HIPS,HB,G4309,SV704P S.N.A ...3 AA64-40513B WINDOW-REMOCON;-,50S1,-,PC,V0,VIOLET,- S.N.A ...3 AA64-40514A INDICATOR-LED;CT50S1,ACRYL,-,CLR,-,-,- ...3 AA64-70123B BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,SILVER S.N.A ...3 AA96-00163B ASSY SPEAKER;-,8ohm,6W,3001-001034,350/7 S.N.A 7-14 Samsung Electronics...
  • Page 45 ..5 C606 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm ..4 AA97-06873A ASSY AUTO-MAIN;CS21S4SX/AWE,KS1A,NIGERIA S.N.A ..5 C607 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 C101 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5 ..5 C610 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm ..5 C102 2202-000279 C-CERAMIC,MLC-AXIAL;47pF,5%,50V,SL,TP,3..5 C611 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 C103 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..5 C612 2401-000480 C-AL;10uF,20%,50V,GP,TP,5x11,5 Samsung Electronics 7-15...
  • Page 46 S.N.A ..5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY808 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ205 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY809 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ207 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY810 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ301 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D ..5 EY813 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A 7-16 Samsung Electronics...
  • Page 47 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 ..5 Q203 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..5 R505 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10 ..5 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R506 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 Q205 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R510 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 Q301 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..5 R511 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-17...
  • Page 48 AA39-20461C LEAD CONNECTOR-ASSY;,11P,YBNH250-11,6709 ..5 R928 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 CN704A AA39-00094A LEAD CONNECTOR-ASSY;,3(2)P,YBNH250-03,35 ..5 R929 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 JE601 3722-000143 JACK-PHONE;1P(VER),3.4PI,AG,BLK,NO ..5 R931 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 JR01 3722-001031 JACK-PIN;3P,3.6mm,#18,AU ..5 R932 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA97-07200A ASSY AUTO-A/V FRONT;,KS1A,PAL,AA95-01435 S.N.A 7-18 Samsung Electronics...
  • Page 49 ...3 TW+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A ...3 AA64-00711C KNOB POWER;21S4,ABS,-,-,-,HB,G3676,-,NO- ...3 AA64-00713B WINDOW REMOCON;-,21S4,-,PC,V0,VIOLET,- S.N.A ...3 AA64-00714B INDICATOR LED;21S4,ACRYL,-,CLR,-,-,- ...3 AA64-70123B BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,SILVER S.N.A ...3 AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,2 S.N.A ...3 AA65-30105A CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,1 S.N.A ...3 AA96-00626A ASSY SPEAKER;-,8OHM,15W,001115/001088,35 S.N.A ..4 3001-001088 SPEAKER;5W,8ohm,90dB,250Hz+-50Hz...
  • Page 50 S.N.A ..5 C207 2305-000412 C-FILM,MPEF;470nF,5%,63V,TP,-,5mm ..5 RS01 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 C208 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..5 RS02 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 C209 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 ..5 RS03 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 C210 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..5 RS04 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 C211 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP 7-20 Samsung Electronics...
  • Page 51 2401-003028 C-AL;100uF,20%,25V,WT,TP,6.3x11,5 ..5 DZ810 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..5 C822 2401-000711 C-AL;2200uF,20%,25V,GP,TP,16x25,7.5 ..5 DZ901 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500mW,DO ..5 C823 2401-000302 C-AL;100uF,20%,25V,GP,TP,6.3x11,5 ..5 DZ903 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..5 C825 2401-003028 C-AL;100uF,20%,25V,WT,TP,6.3x11,5 ..5 DZ904 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 ..5 C827 2401-000927 C-AL;22uF,20%,250V,GP,TP,13x20,5 ..5 DZ905 0403-000508 DIODE-ZENER;MTZJ5.6B,5.6V,5.45-5.73V,500 Samsung Electronics 7-21...
  • Page 52 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 GT402 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO S.N.A ..5 R207 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ..5 GT501 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO S.N.A ..5 R208 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 GT502 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO S.N.A ..5 R209 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 GT801 AA60-40014A PIN-GT,ASSY;1P,-,-,AUTO S.N.A ..5 R210 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3.2MM 7-22 Samsung Electronics...
  • Page 53 S.N.A ..5 R810 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP,2.4X6..5 R814 2008-001113 R-FUSIBLE(S);0.22ohm,10%,2W,AG,TP,3.9x12 ..5 R815 2008-001113 R-FUSIBLE(S);0.22ohm,10%,2W,AG,TP,3.9x12 ..5 R817 2004-004089 R-METAL(S);123Kohm,1%,1/2W,AA,TP,2.5x6.5 ..5 R818 2004-001399 R-METAL(S);5.1Kohm,1%,1/2W,AA,TP,2.4x6.4 ..5 R819 2004-001390 R-METAL(S);1Kohm,2%,1/2W,AA,TP,2.4x6.4mm ..5 R821 2001-001125 R-CARBON(S);300KOHM,5%,1/2W,AA,TP,2.4X6..5 R822 2004-001983 R-METAL(S);2.49Kohm,1%,1/2W,AA,TP,2.4x6..5 R823 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP,2.4X6.4 Samsung Electronics 7-23...
  • Page 54 ..5 C506 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m ..4 AA97-04842A ASSY AUTO-MAIN;CS21S4ZX/AWE,KS1A,NIGERIA S.N.A ..5 C601 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm ..5 C101 2401-001101 C-AL;330uF,20%,16V,GP,TP,8x11.5,5 ..5 C603 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 C102 2202-000279 C-CERAMIC,MLC-AXIAL;47pF,5%,50V,SL,TP,3..5 C604 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 ..5 C103 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..5 C605 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 7-24 Samsung Electronics...
  • Page 55 S.N.A ..5 DZ101 0403-000700 DIODE-ZENER;TZP33A,33V,31-35V,1W,DO-41,T ..5 EY807 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ201 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY808 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ203 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO ..5 EY809 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY810 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A Samsung Electronics 7-25...
  • Page 56 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 ..5 Q201 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..5 R502 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 Q202 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R502H 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 ..5 Q203 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..5 R503 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 ..5 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R504 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 7-26 Samsung Electronics...
  • Page 57 ...3 AA64-00713B WINDOW REMOCON;-,21S4,-,PC,V0,VIOLET,- S.N.A ..5 R916 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-00714B INDICATOR LED;21S4,ACRYL,-,CLR,-,-,- ..5 R917 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-70123B BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,SILVER S.N.A ..5 R918 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,2 S.N.A ..5 R919 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA65-30105A CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,1 S.N.A...
  • Page 58 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR S.N.A ..5 C216 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 AA62-30175D HEAT-SINK,PS;-,SECC,T1.0,-,33X15X30 FT-2 S.N.A ..5 C217 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, ..4 IC801S AA96-00242A ASSY H/S;-,-,AA62-30186B,KA5Q0765R,- S.N.A ..5 C218 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..5 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A ..5 C219 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 7-28 Samsung Electronics...
  • Page 59 S.N.A ..5 C904 2301-000383 C-FILM,PEF;10nF,5%,50V,TP,6x7x3.2mm,5mm ..5 EL404 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- S.N.A ..5 C906 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 ..5 EL407 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- S.N.A ..5 C908 2201-000573 C-CERAMIC,DISC;0.047nF,5%,50V,NP0,TP,5x3 ..5 EL408 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- S.N.A ..5 C909 2201-000573 C-CERAMIC,DISC;0.047nF,5%,50V,NP0,TP,5x3 ..5 EL501 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- S.N.A Samsung Electronics 7-29...
  • Page 60 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 HIC01 AA13-20004W IC-HYBRID;-,PAP103T,SIP,6P,PRE-AMP,TP ..5 R308 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6..5 IC803 1203-001217 IC-POSI.ADJUST REG.;431,TO-92,3P,4.58MIL ..5 R313 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 J125 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP,2.4X6.4MM ..5 R314 2003-000537 R-METAL OXIDE(S);1Kohm,5%,1W,AF,TP,3.3x9 ..5 J137 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R315 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x 7-30 Samsung Electronics...
  • Page 61 ...3 AA64-00713B WINDOW REMOCON;-,21S4,-,PC,V0,VIOLET,- S.N.A ..5 R903 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-00714B INDICATOR LED;21S4,ACRYL,-,CLR,-,-,- ..5 R904 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-70123B BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,SILVER S.N.A ..5 R905 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ...3 AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,2 S.N.A ..5 R906 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ...3 AA65-30105A CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,1 S.N.A...
  • Page 62 2401-001026 C-AL;3.3UF,20%,50V,GP,TP,5X11,5 ..4 C801 2401-003339 C-AL;220uF,20%,400V,GP,ST,30x35,10 ..5 CS07 2201-000982 C-CERAMIC,DISC;10nF,+80-20%,50V,Y5V,TP,4 ..4 CN701 3711-000628 CONNECTOR-HEADER;-,11P,1R,2.5mm,STRAIGHT ..5 CS09 2301-000111 C-FILM,PEF;1.8nF,5%,50V,TP,6.5x3.0x5.5mm ..4 CR402S 2306-000188 C-FILM,MPPF;330nF,5%,400V,TP,26x19.5x11, ..5 CS11 2401-000486 C-AL;10uF,20%,50V,GP,TP,6.3x7mm,5 ..4 CR410S 2303-001015 C-FILM,PPF;5.5nF,5%,1.6kV,TP,29x9.5x17,2 ..5 CS12 2401-000486 C-AL;10uF,20%,50V,GP,TP,6.3x7mm,5 ..4 CX801S 2306-000318 C-FILM,MPPF;220nF,20%,250V,TP,-,22.5mm 7-32 Samsung Electronics...
  • Page 63 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, ..5 D103 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, ..5 C248 2301-000445 C-FILM,PEF;4.7nF,5%,50V,TP,5.5x7x3mm,5mm ..5 D201 0401-000005 DIODE-SWITCHING;1N4148,100V,200mA,DO-35, ..5 C301 2305-000285 C-FILM,MPEF;220NF,5%,100V,TP,10.5X5.5X15 ..5 D301 0402-001105 DIODE-RECTIFIER;ERB43-04SV1,400V,1.0A,-, ..5 C302 2201-000259 C-CERAMIC,DISC;0.18nF,10%,500V,Y5P,TP,5..5 D302 0402-001352 DIODE-RECTIFIER;GUF15G-20A,400V,1.5A,DO- ..5 C303 2201-000556 C-CERAMIC,DISC;0.47nF,10%,500V,Y5P,TP,5..5 D303 0402-000132 DIODE-RECTIFIER;1N4004,400V,1A,DO-41,TP Samsung Electronics 7-33...
  • Page 64 2701-000127 INDUCTOR-AXIAL;15uH,10%,2.5x3.4mm ..5 EY403 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm ..5 EY404 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 L205 2701-000159 INDUCTOR-AXIAL;22uH,10%,4.2x9.8mm ..5 EY405 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 L301 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm ..5 EY406 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 L302 2701-000142 INDUCTOR-AXIAL;1uH,10%,2.5x3.4mm 7-34 Samsung Electronics...
  • Page 65 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m ..5 R903 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R306 2004-004366 R-METAL(S);1.3Kohm,1%,1/2W,AA,TP,2.5x6.5 ..5 R904 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R307 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R905 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ..5 R308 2001-001093 R-CARBON(S);2.2KOHM,5%,1/2W,AA,TP,2.4X6..5 R906 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ..5 R313 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R907 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-35...
  • Page 66 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-01426B WINDOW REMOCON;21D8,PC,-,-,-,VOILET,-,- S.N.A ..5 R923 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-01425F KNOB POWER;21D8,ABS,HB,G3676,SV012P ..5 R924 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-70123B BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,SILVER S.N.A ..5 R925 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA65-30105A CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,1 S.N.A ..5 R926 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA96-10146C ASSY SPEAKER;-,8ohm,5W,3001-000274,350/7 S.N.A...
  • Page 67 2202-000279 C-CERAMIC,MLC-AXIAL;47pF,5%,50V,SL,TP,3..5 C604 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 ..5 C103 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..5 C605 2401-000660 C-AL;2.2uF,20%,50V,GP,TP,5x11,5 ..5 C104 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 ..5 C606 2301-000289 C-FILM,PEF;5.6nF,5%,50V,TP,7x6x3,5 ..5 C105 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V ..5 C607 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 C106 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V ..5 C610 2301-000289 C-FILM,PEF;5.6nF,5%,50V,TP,7x6x3,5 Samsung Electronics 7-37...
  • Page 68 S.N.A ..5 DZ203 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500mW,DO ..5 EY808 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY809 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ205 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY810 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ207 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY813 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A 7-38 Samsung Electronics...
  • Page 69 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7 ..5 Q203 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..5 R504 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP,2.4X6.4 ..5 Q204 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R505 2008-001011 R-FUSIBLE(S);0.18ohm,10%,2W,AF,TP,3.9x10 ..5 Q205 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R506 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 Q301 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T ..5 R510 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM Samsung Electronics 7-39...
  • Page 70 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-01426B WINDOW REMOCON;21D8,PC,-,-,-,VOILET,-,- S.N.A ..5 R911 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-01425H KNOB POWER;21D8,ABS,HB,BLK ..5 R912 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-70123D BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,GOLD,R S.N.A ..5 R913 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA65-30105A CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,1 S.N.A ..5 R914 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA96-10146C ASSY SPEAKER;-,8ohm,5W,3001-000274,350/7 S.N.A...
  • Page 71 2904-001063 FILTER-SAW AV;38.9MHz,SIP5K,TP,18.5dB,B/ ..5 C504 2401-001232 C-AL;4.7uF,20%,250V,GP,TP,10x12.5,5 ..4 SW801S 3403-001107 SWITCH-PUSH;250V,5A,DPST,-,KDC-A04 ..5 C505 2202-000825 C-CERAMIC,MLC-AXIAL;680pF,10%,50V,Y5P,TP ..4 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,-,-,7.1mH,-,-,102uH, ..5 C506 2401-000430 C-AL;10uF,20%,250V,GP,TP,10x16mm,5m ..4 T801S AA26-00134A TRANS SWITCHING;,CS21S5T,160V~260V,PM2 P ..5 C601 2401-001998 C-AL;1000uF,20%,25V,GP,TP,10x20,5mm ..4 TU01S AA40-00070A TUNER;TEDE9-203A,PAL,181CH,38.9MHZ,75OHM Samsung Electronics 7-41...
  • Page 72 S.N.A ..5 DZ204 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY810 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ205 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY813 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ207 0403-000720 DIODE-ZENER;MTZJ9.1B,9.1V,8.57-9.01V,500 ..5 EY818 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A ..5 DZ301 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.20V,500mW,D ..5 EY819 AA60-40011A EYELET;ID2.0,OD2.8,-,-,BST,- S.N.A 7-42 Samsung Electronics...
  • Page 73 ..5 R719 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 Q905 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T ..5 R720 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R108 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R721 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R109 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R801 2003-002171 R-METAL OXIDE(S);150ohm,5%,2W,AG,TP,3.9x ..5 R110 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R806 2001-001108 R-CARBON(S);22KOHM,5%,1/2W,AA,TP,2.4X6.4 Samsung Electronics 7-43...
  • Page 74 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ...3 AA64-01426B WINDOW REMOCON;21D8,PC,-,-,-,VOILET,-,- S.N.A ..5 R906 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ...3 AA64-01425F KNOB POWER;21D8,ABS,HB,G3676,SV012P ..5 R907 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA64-70123B BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,SILVER S.N.A ..5 R908 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA65-30105A CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,1 S.N.A ..5 R909 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ...3 AA96-10146C ASSY SPEAKER;-,8ohm,5W,3001-000274,350/7 S.N.A...
  • Page 75 ..5 C215 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 LS03 2701-000114 INDUCTOR-AXIAL;10uH,10%,2.5x3.4mm ..5 C216 2305-000289 C-FILM,MPEF;220nF,5%,63V,TP,-,5mm ..5 LS04 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2.5x3.4mm ..5 C217 2301-000342 C-FILM,PEF;2.2nF,5%,50V,TP,7.4x3.9x13mm, ..5 PCB AA41-00139A PCB-STEREO/LINE-ST/MTS-M;DREAM-1,1L,FR-1 S.N.A ..5 C218 2305-000665 C-FILM,MPEF;100nF,5%,63V,TP,7.5x4.0x5.0m ..5 RS01 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 C219 2401-000603 C-AL;1uF,20%,50V,GP,TP,5x11,5 Samsung Electronics 7-45...
  • Page 76 S.N.A ..5 C906 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P,TP,3 ..5 EL407 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- S.N.A ..5 C908 2201-000573 C-CERAMIC,DISC;0.047nF,5%,50V,NP0,TP,5x3 ..5 EL408 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- S.N.A ..5 C909 2201-000573 C-CERAMIC,DISC;0.047nF,5%,50V,NP0,TP,5x3 ..5 EL501 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- S.N.A ..5 C910 2401-001840 C-AL;100uF,20%,16V,GP,TP,6.3x11,5 ..5 EL502 AA60-40011B EYELET;ID2.2,OD3.2,-,-,BSP,- S.N.A 7-46 Samsung Electronics...
  • Page 77 ..5 J137 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R314 2003-000537 R-METAL OXIDE(S);1Kohm,5%,1W,AF,TP,3.3x9 ..5 J142 2701-000115 INDUCTOR-AXIAL;10uH,10%,3x7mm ..5 R315 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x ..5 J910 3301-000287 CORE-FERRITE BEAD;AA,3.5x1.0x6.0mm,1500, ..5 R316 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x ..5 L102 2701-000159 INDUCTOR-AXIAL;22uH,10%,4.2x9.8mm ..5 R402 2003-002178 R-METAL OXIDE(S);1Kohm,5%,2W,AG,TP,3.9x1 Samsung Electronics 7-47...
  • Page 78 AA64-00707F CABINET BACK;21S4,HIPS,V2,G4309 ..5 R902 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM AA64-60385B INLAY-BACK;50.5366,PS,T0.3,-,-,BLK,LINE S.N.A ..5 R903 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM AA65-30008A CLAMP-CORD;-,PE,HB,-,BLK,- S.N.A ..5 R904 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R905 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ..5 R906 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP,1.8x3.2mm ..5 R907 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM ..5 R908 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM 7-48 Samsung Electronics...
  • Page 79 TW+CF 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A ...3 AA64-00711C KNOB POWER;21S4,ABS,-,-,-,HB,G3676,-,NO- ...3 AA64-00713B WINDOW REMOCON;-,21S4,-,PC,V0,VIOLET,- S.N.A ...3 AA64-00714B INDICATOR LED;21S4,ACRYL,-,CLR,-,-,- ...3 AA64-70123B BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,SILVER S.N.A ...3 AA65-00011C CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,2 S.N.A ...3 AA65-30105A CLAMP-WIRE;ALL MODEL,NYLON 66,V2,-,NTR,1 S.N.A ...3 AA96-00626A ASSY SPEAKER;-,8OHM,15W,001115/001088,35 S.N.A ..4 3001-001088 SPEAKER;5W,8ohm,90dB,250Hz+-50Hz...
  • Page 80 MEMO 7-50 Samsung Electronics...

  • Page 81: Block Diagram

    Block Diagram 8. Block Diagram 8-1 KS1A T U NE R -F /S SI F SA W V E R T IC AL T A E L -G 2 5 3 D K9260M A M P S/ W V I F SA W G3956M L A7840 (Option)

  • Page 82: Wiring Diagram

    SOUND L OUT SOUND L IN SOUND R OUT SOUND R IN CN603 FRONT AUDIO IN R + OUT R - OUT 21 PIN AUDIO IN L + OUT L - OUT 21 PIN VIDEO IN FRONT VIDEO IN Samsung Electronics...
  • Page 83 MEMO...

  • Page 84: Schematic Diagrams

    10. Schematic Diagrams 10-1 ONECHIP & MICOM TP01 TP02 TP03 TP05 TP04 TP06 TP11 TP04 TP08 TP05 TP12 TP09 TP10 TP03 TP06 TP07 TP08 TP09 TP13 TP01 TP10 TP11 TP12 TP02 TP07 TP14 TP13 TP14 : Power Line Samsung Electronics 10-1...
  • Page 85 Schematic Diagrams 10-2 SOUND, EXT-A/V (RCA) TP01 TP01 TP02 TP02 : Power Line 10-2 Samsung Electronics...
  • Page 86 Schematic Diagrams 10-3 SOUND, EXT-A/V (SCART) TP01 TP01 TP02 TP02 : Power Line Samsung Electronics 10-3...
  • Page 87 Schematic Diagrams 10-4 POWER / CRT / VERTICAL / HORIZONTAL TP01 TP02 TP03 TP06 TP05 TP04 TP03 TP05 TP02 TP04 TP06 TP01 : Power Line 10-4 Samsung Electronics...
