- Page 1 OPERATOR HANDBOOK Gasoline LIQUEFIED PETROLEUM GAS (LPG) NATURAL GAS (NG) ENGINES Part #: 1070150 EDI 2023 May, 2023...
- Page 2 ARNING:...
- Page 3 Engine Distributors Incorporated Engine Distributors policy is one of continuous improvement and while every effort is made to ensure that this publication is up to date and correct in all respects, the right to change prices, specifications and equipment at any time without notice is reserved.
-
Page 4: Table Of Contents
CONTENTS HEALTH & SAFETY ......................6 General Guidelines: ....................6 Important Safety Notice................... 6 Notes, Cautions, and Warnings ................7 FORWARD ........................8 ENGINE IDENTIFICATION....................8 U.S.A. Engine Identification Decal ................9 Federal Emissions Warranty Statement..............10 California Emission Control Warranty Statement............ 10 What Is Covered? .................... - Page 5 CONTENTS STOPPING THE ENGINE ....................17 Normal Conditions....................17 Abnormal Conditions....................17 RUNNING-IN PROCEDURE .................... 17 FUEL RECOMMENDATION..................... 18 LUBRICATION AND MAINTENANCE................18 RECOMMENDED MAINTENANCE SCHEDULES............19 RECOMMENDED MAINTENANCE OPERATIONS ............20 Recommended Lubricants ..................20 Used Engine Oils ....................21 Change Engine Oil ....................
-
Page 6: Health & Safety
HEALTH & SAFETY WARNING: THE FOLLOWING HEALTH AND SAFETY RECOMMENDATIONS SHOULD BE CAREFULLY OBSERVED. Carrying out certain operations and handling some substances can be dangerous or harmful to the operator if the correct safety precautions are not observed. Some such precautions are recommended at the appropriate points in this book. -
Page 7: Notes, Cautions, And Warnings
There are numerous variations in procedures, techniques, tools and parts for servicing equipment, as well as in the skill of the individual doing the work. This manual cannot possibly anticipate all such variations and provide advice or cautions as to each. Accordingly, anyone who departs from the instructions provided in this Manual must first establish that neither personal safety nor equipment integrity are compromised by the choice of methods, tools or parts. -
Page 8: Forward
ENGINE IDENTIFICATION Because Engine Distributors has such a wide range of industrial gasoline and diesel engines - manufactured both in the U.S. and overseas - it is important that you have as complete identification of the engine as possible in order to provide the correct replacement parts. Review the list of distributors for a distributor in your area. -
Page 9: Engine Identification Decal
EDI Engine Identification Decal An identification Decal is affixed to the valve cover of the engine. The decal contains the engine serial number which identifies this unit from all others. Use all numbers when seeking information or ordering replacement parts for this engine. -
Page 10: Federal Emissions Warranty Statement
(ECM), catalytic converter and air induction system. Also included may be sensors, hoses, belts, connectors and other emission-related assemblies. Where a warrantable condition exists, Engine Distributors, Inc will repair your LSI engine at no cost to you including diagnosis, parts, and labor. -
Page 11: What Is Covered
What is Covered Below is a list of the systems that affect emissions on your engine. Emission control components on these systems are covered by the emissions warranties as applicable. If failure of one of the components listed below results in failure of another part, both will be covered by this warranty. For detailed information concerning specific components covered by these emission control systems warranties, ask your dealer. -
Page 12: Parts And Service
SERVICE LITERATURE A service manual can be purchased from your EDI distributor. This publication will provide the necessary servicing and overhaul information for your Ford Power Products engine. • RSG862 SERVICE MANUAL – 1070200 EDI • RSG862 PARTS LIST – 1070190 EDI BEFORE OPERATING THE ENGINE 1. -
Page 13: Safety Switch (Where Fitted)
1. Auxiliary Circuits - When moved to this position the auxiliary electrical equipment such as radios and heater fans, can be operated without also connecting the starting circuit with the battery. 2. Off - When set to this position, the switch disconnects the auxiliary electrical equipment and the starting circuit from the battery. -
Page 14: Instruments
INSTRUMENTS Your Ford Powered Equipment will have been fitted with instruments selected by the manufacturer. The types of instruments most likely to be encountered are detailed here. A typical instrument panel is shown below. Ammeter (Where Fitted) This instrument registers the charging current which is being passed to the battery from the alternator. -
Page 15: Temperature Gauge (Where Fitted)
Malfunction Indicator Light (Where Fitted) Used on all industrial engines. This light will illuminate whenever there is an engine malfunction such as low oil pressure, high engine temperature, fuel injection system fault. The engine can be programmed to shut down in the event of a malfunction. Charge Indicator Light (Where Fitted) If an alternator is fitted to your engine, a charge indicator light will also be fitted. -
Page 16: Starting The Engine
STARTING THE ENGINE WARNING: ALL INTERNAL COMBUSTION ENGINES GIVE OFF VARIOUS FUMES AND GASES WHILE RUNNING. DO NOT START OR RUN THE ENGINE IN A CLOSED OR POORLY VENTILATED BUILDING WHERE THE EXHAUST GASES CAN ACCUMULATE. AVOID BREATHING THESE GASES AS THEY MAY CONTAIN POISONOUS CARBON MONOXIDE WHICH CAN ENDANGER YOUR HEALTH OR LIFE IF INHALED STEADILY FOR EVEN A FEW MINUTES. -
Page 17: Stopping The Engine
STOPPING THE ENGINE Normal Conditions Following normal operating conditions, lower the engine speed to idle, disengage the clutch, and then turn the ignition switch to the OFF position. If the engine has been running under high power, let it run at fast idle speed a few minutes to cool the engine down. Abnormal Conditions Under abnormally overheated conditions, the engine may continue to run after the ignition switch is turned off. -
Page 18: Fuel Recommendation
FUEL RECOMMENDATION This engine is designed to operate on dry fuel such as LPG Grade HD5 or NG (1050 BTU/ft^ CAUTION: Use of fuels rated lower than the grades specified above may cause persistent, heavy spark knock, which can lead to engine damage. If your engine knocks heavily, or if you hear continuous spark knock while maintaining constant operating speeds, consult your distributor or another qualified technician. -
Page 19: Recommended Maintenance Schedules
RECOMMENDED MAINTENANCE Check engine oil level and top up if necessary Check engine coolant level and top up if necessary with correct mixture Check visually for oil, fuel or coolant leaks Check all instruments, controls and warning lights. Check hot and cold start functions Check coolant, oil, fuel, exhaust and vacuum hoses/pipes for leaks, damage,... -
Page 20: Recommended Maintenance Operations
RECOMMENDED MAINTENANCE OPERATIONS Recommended Lubricants CAUTION: Do not use supplemental oil additives or other engine treatments. They are unnecessary and could, under certain conditions, lead to engine damage which is not covered by Ford warranty. Lubricating oil cleanliness is vital for the successful operation of your engine. The oil should be stored under the cleanest possible conditions. -
Page 21: Used Engine Oils
Used Engine Oils WARNING: PROLONGED AND REPEATED CONTACT MAY CAUSE SERIOUS SKIN DISORDERS INCLUDING DERMATITIS AND SKIN CANCER. WARNING: AVOID EXCESSIVE CONTACT—WASH THOROUGHLY AFTER CONTACT. KEEP OUT OF THE REACH OF CHILDREN. WARNING: PROTECT THE ENVIRONMENT: IT IS ILLEGAL TO POLLUTE DRAINS, WATER COURSES OR SOIL. -
Page 22: Check Engine Oil Level
Check Engine Oil Level 1. Make sure the equipment is standing level and that the engine is stopped. 2. Pull out the dipstick and wipe it with a clean rag. 3. Insert the dipstick fully and again remove it. At no time should the level of the oil fall below the lower mark on the dipstick. -
Page 23: Ignition System
Ignition System The 6.2L engine is equipped with a coil-on-plug ignition system. Rather than a remotely mounted coil with secondary ignition wires, this system has a separate ignition coil mounted on each spark plug. Operation of the coils is controlled by the engine computer module (GCP), which computes ignition timing based on inputs from engine sensors. - Page 24 WARNING: PROTECTIVE GOGGLES MUST BE WORN TO PROTECT THE EYES WHEN USING COMPRESSED AIR. 4. Check the gaps of the new spark plugs with a feeler gauge, and, where necessary, bend the outer ground extension to achieve the specified gap. 5.
-
Page 25: Electronic Actuator
Electronic Actuator In the event that your engine is equipped with an electronic actuator, any necessary adjustment should be made by your Power Products Distributor listed at the back of this manual. The adjusting procedure requires the use of tools which are not readily available to consumers Check Condition of Ancillary Drive Belts WARNING: ENGINE SHOULD BE STOPPED AND ANY REMOTE STARTER... -
Page 26: Renew Air Cleaner Element
Renew Air Cleaner Element Your air cleaner filters air entering the engine induction system and acts as a silencer and a flame arrester. Air that contains dirt and grit produces an abrasive fuel mixture, and can cause severe damage to the cylinder walls and piston rings. Damage to the cylinder walls and piston rings will cause high oil consumption and short engine life. -
Page 27: General Maintenance Information
GENERAL MAINTENANCE INFORMATION The following section outlines some aspects of general maintenance which will be of value to the operator. Cooling System To obtain maximum engine service life, its operating temperature must be maintained by an efficient cooling system. CAUTION: Under no circumstances should the engine be started without liquid in the cooling system. - Page 28 antifreeze contains additional corrosion inhibitors designed to provide lasting protection for the engine. Only this antifreeze, or proprietary antifreeze meeting Ford specification WSSM97B44- D or Ford specification ESE-M97B44-A should be used when topping-up or re-filling the cooling system. Motorcraft Super Plus 2000 coolant has long life characteristics and if the concentration is kept to a maximum of 50% it will provide adequate frost protection and inhibiting for the life of the engine.
-
Page 29: Draining, Flushing And Filling The Cooling System
Draining, Flushing and Filling the Cooling System WARNING: NEVER REMOVE THE PRESSURE RELIEF CAP WHILE THE ENGINE IS OPERATING OR WHEN THE COOLING SYSTEM IS HOT. MAY CAUSE PERSONAL INJURY OR DAMAGE TO COOLING SYSTEM OR ENGINE. TO REDUCE THE RISK OF HAVING SCALDING HOT COOLANT OR STEAM BLOW OUT OF THE DEGAS BOTTLE WHEN REMOVING THE PRESSURE RELIEF CAP, WAIT UNTIL THE ENGINE HAS COOLED... -
Page 30: Engine Lubrication System
Engine Lubrication System The lubrication system should be maintained regularly -- Refer to “RECOMMENDED MAINTENANCE SCHEDULES” on page 20, with the correct grade of lubricant as specified in the maintenance summary -- Refer to “Recommended Lubricants” on page 21. The system is of the force feed type, the lubricating oil being circulated to the engine bearings under pressure by an oil pump driven from the... -
Page 31: Electrical System
Electrical System A NEGATIVE EARTH (NEGATIVE GROUND) SYSTEM IS USED. ECU - Power Distribution Box Fuse Amps Circuits protected Battery Voltage to EPR Ignition Voltage to GCP and Relays Battery Voltage to GCP Fuel pump Battery Voltage out of Power Relay Alternator Generator This is mounted on a bracket at the front of the engine and is driven from the crankshaft by a... -
Page 32: Storage
Storage - One Month • While the engine is running, treat upper cylinders by spraying engine fogging agent (from your local aftermarket supplier) into the air intake for about two minutes. Open throttle for short burst of speed, shut off engine and allow it to come to a stop while continuing to spray into air intake. -
Page 33: Engine System Check
ENGINE SYSTEM CHECK GCP System Check NOTE: Most items listed in the possible cause column may not set a diagnostic fault indicator or illuminate the MIL light. NOTE: EDI engines are used in many different applications and equipment. When performing any system diagnosis be aware of any OEM inputs or equipment monitoring devices that may have an effect on the engine’s performance or any of the engine’s operating systems. - Page 35 Engine Performance - While Under Load...
- Page 37 Engine Concerns...
-
Page 38: Specifications
SPECIFICATIONS GENERAL SPECIFICATIONS V-8, 16 valves, 4 Stroke spark ignition 90˚ Overhead Engine Type: Valve (OHV) chain driven camshaft operating the valves via roller cam followers and hydraulic lash adjusters. Liter/CID: 6.2L / 379 CID Bore: mm (inch) 102 (4.02) Stroke: mm (inch) 95 (3.74) Number of Cylinders:... - Page 39 DRIVE BELT 6 Groove Serpentine Belt Belt Length and Type: 82.5 inches (2095.5mm) ELECTRICAL SYSTEM Polarity: Negative to earth (ground) Ground B- directly to Engine Block. Grounding: Engine Block ground strap to chassis (unpainted surface) Alternator Output: 157 Amp @ 2,000 RPM 750 CCA / 140 RC (950 CCA @ 0˚F) Minimum Battery Capacity: IGNITION SYSTEM...
-
Page 40: Tightening Torques
TIGHTENING TORQUES... -
Page 41: Conversion Table
CONVERSION TABLE... -
Page 42: Ford Power Products Service
EDI DISTRIBUTORS Visit www.edi-dist.com/distributors for a complete list of North American and Worldwide distributors. or Call 1-800-220-2700...
