Everflourish MW202US-RF Instruction Manual

Everflourish MW202US-RF Instruction Manual

Rf remote socket and transmitter

Advertisement

Ref: EMW202T1 + MW202US-RF

Function

1. The remote control socket turns on and off the connected lighting or appliance by a wireless
transmitter using radio frequency up to 25 meters away.
2. It is ideal for lighting control, for the purposes of home automation and energy saving.
3. The receiver has the indicator light for power supply status.

Operation

1. No command setting required.
2. Connect the remote control socket to the mains power supply.
3. Turn off the appliance before connecting to the remote control.
4. Remove the plastic tab at the battery holder on the transmitter to allow battery contact.
5. Press the corresponding "ON", "OFF" button on the transmitter to switch on and off the
connected appliance by remote control
6. The indicator on the receiver blink once for every reception of power on/off
7. When the indicator light on the transmitter goes dim, it means the battery is in low power. Open
the battery holder (as per below figure) and replace it with equivalent battery in correct polarity
Caution
1. Always switch off your appliance before connection.
2. For INDOOR USE ONLY
3. Appliances to be connected to the remote control socket MUST NOT exceed the voltage and
frequency ratings as in "Specifications".

Specifications

EMW202US-RF
1. Power Rating : 120VAC, 60Hz,
2. Resistive load: 1000W max.
3. Frequency:
: 433.92 MHz
4. Distance:
: up to 80 feet in open area
EMW202T1
1. Battery
: CR2032 3VDC (included)
2. Frequency
: 433.92
3. Distance
: up to 80 feet in open area
Holder:
Everflourish Electrical Co., Ltd.
Renjiu Village, Wuxiang Town, Yinzhou, Ningbo, 315111 P.R. China
Instruction Manual for
RF Remote Socket and Transmitter
MHz
