AudioArts Engineering RD-12 Technical Manual

Digital audio console
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RD-12 Digital Audio
Console
T
M
ECHNICAL
ANUAL
March 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RD-12 and is the answer not in the manual?

Questions and answers

Related Manuals for AudioArts Engineering RD-12

Summary of Contents for AudioArts Engineering RD-12

  • Page 1 RD-12 Digital Audio Console ECHNICAL ANUAL March 1999...
  • Page 2 RD-12 Digital Audio Console Technical Manual - 1st Edition ® ©1999 Audioarts Engineering* AUDIOARTS ENGINEERING 600 Industrial Drive New Bern, North Carolina 28562 252-638-7000 *a division of Wheatstone Corporation RD-12 / March 1999 R-16 / Dec 1997...
  • Page 3 If the above instructions are followed the procedure should be routine; if they are not, you could run the risk of damaging the console's logic chips. Again, to avoid ANY possibility of this damage, whenever possible we strongly recommend powering down the console before replacing any modules. RD-12 / March 99...
  • Page 4 Attention! Console Clock Battery Backup To activate battery backup of the console’s clock simply pull out the yellow strip from the clock display card, that is mounted on the inside of console meterbridge, as shown on the picture below. Console Clock Display Card R R R R R M M M M M ! ! ! ! !
  • Page 5 E X T R A C T O R T O O L S Module Removal Tools Your Audioarts RD-12 audio console is equipped with two "module extractor tools" which are mounted underneath the console armrest, to the far right (just above and to the left of the righthand mainframe headphone jack).

  • Page 6: Table Of Contents

    AUDIO CONNECTIONS ..................2-5 CONTROL CONNECTIONS ................... 2-6 Remote ON & OFF ....................2-6 Talkback to Control Room ..................2-6 On Tally ........................2-6 Off Tally ........................2-7 page Contents – 1 RD-12 / March 99 RD-12 / Nov 03...
  • Page 7 Cue Interrupt ......................5-3 Cue Mute ........................5-3 Mono Cue ......................... 5-3 Hook-ups ..................5-4 AMP A, B Connectors — AUDIO ................5-4 AMP B Connector — CONTROL ................5-4 page Contents – 2 RD-12 / March 99 RD-12 / Jan 00...
  • Page 8 Tallies ........................9-4 Cue Dropout ......................9-5 Gain Trimpots ......................9-5 Internal Programming Options - Piggyback PCB ...... 9-5 External In ......................... 9-5 Cue Pre/Post ......................9-5 Gain Trimpots ......................9-5 Hook-ups ..................9-6 page Contents – 3 RD-12 / March 99...
  • Page 9 AMP A, B Connectors - CONTROL ................. 12-4 AMP D Connector - AUDIO ..................12-5 AMP C, D Connectors - CONTROL ................ 12-5 Chapter 13 - Tape Remote Module; optional Overview ..................13-2 Hook-ups ..................13-3 page Contents – 4 RD-12 / March 99 RD-12 / June 00...
  • Page 10 Digital/Audio Line Select Rackmount Schematic (LSR-500) ......15-15 Tape Remote Module Schematic (TRD-500) ............. 15-17 Intercom Module Schematic (ICMD-500) ............15-18 Appendix - Replacement Parts List Replacement Parts List ............. A-2 page Contents – 5 RD-12 / March 99 RD-12 / Aug 00...
  • Page 11 The VU/Timer Cable................... 1-6 Energizing......................1-6 Audio and Control Wiring............1-7 Connection Procedures ..................1-7 Insert Points......................1-7 Unbalanced Connections ................... 1-7 Hand crimp tool wiring instructions..............1-8 page 1 – 1 RD-12 / March 99 RD-12 / Nov 03...

  • Page 12: Countertop Mounting

    Console placement should avoid proximity to any electro- magnetic fields, such as large power transformers, motors, and fluores- cent lighting fixtures. The required cut-out width is 31 5/8” for RD-12 or 43 5/8” for RD-20, and cut-out front-to-back dimension is 18 3/8”.
  • Page 13 (and is often by code) tied to the above-mentioned earth ground at one point. This point is the SYSTEM EARTH GROUND. page 1 – 3 RD / Oct 00 RD-12 / March 99...

  • Page 14: Power Supplies

    Under no circumstances should the metal cover be removed! If you have a problem with the power supply, the SPS-180R unit must be returned to Audioarts for repair. page 1 – 4 RD-12 / Nov 03 RD-12 / March 99...
  • Page 15 Power Supply PS Cable Pinout Phantom Digital Ground Digital Ground Power Supply End Console End Digital+ 10-pin Connector 8-pin Connector Digital+ Female Male Analog Ground -V in +V in page 1 – 5 RD-12 / March 99 RD / Nov 2003...

  • Page 16: The Vu/Timer Cable

    Once you have verified proper power-up, unplug the rackmount power supplies to de-energize the console. You may now proceed to wire up audio and control connections. page 1 – 6 RD-12 / March 99 RD-12 / Nov 03...

  • Page 17: Audio And Control Wiring

    I N S T A L L A T I O N a n d P O W E R Audio and Control Wiring All audio and control I/O connections to the RD-12 console are made through 12-pin AMP type connectors. The supplied 12-pin connectors use crimp type pins.

  • Page 18: Hand Crimp Tool Wiring Instructions

    (see next page). Note that metallized plastic hoods for each connector are also supplied with the console. (4) Final step: jaws fully closed; the insulation tabs have been crimped. page 1 – 8 RD-12 / Jun 2004 RD-12 / March 99...
  • Page 19 Nylon Housing. STEP 3. Push ball at top of extractor down toward pin terminal; pin terminal will extract from Nylon Housing. page 1 – 9 RD-12 / Jun 2004 RD-12 / March 99...
  • Page 20 Talkback........................2-4 Superphone Output Assign ..................2-5 Hook-ups..................2-5 AUDIO CONNECTIONS..................2-5 CONTROL CONNECTIONS................... 2-6 Remote ON & OFF ....................2-6 Talkback to Control Room ..................2-6 On Tally........................2-6 Off Tally........................2-7 page 2 – 1 RD-12 / March 99...
  • Page 21 All audio and control input and output signals are made via four 12- pin AMP type connectors. page 2 – 2 RD-12 / March 99 RD-12 / June 00...

  • Page 22: Internal Programming Options

    Mutes When a microphone is live in a room, that room’s monitor speakers must be muted to prevent feedback. The RD-12 console has three mute control lines: control room, studio one and studio two. Each of these may be activated by either an A or B microphone input. The first three positions...

  • Page 23: Tallies

    ON/OFF switches. Talkback Typically, one of the console’s RD-12 input modules will be used for the control room (CR) console operator’s microphone. The fourth position of dipswitch SW1 allows that microphone to also function as a talkback mic.

  • Page 24: Superphone Output Assign

    Note the insert points are normally bypassed by PCB-mounted slide switch SW7 (see page 2-3). Regardless of this switch setting, the Insert Out pins may be used as a channel direct output if desired. page 2 – 5 RD-12 / March 99...

  • Page 25: Control Connections

    (Pins 5, 6 of C and D). This will turn the module OFF. Note this is a non- latching mode; the module will turn ON again as soon as the closure stops. (User-supplied momentary contact switch required.) page 2 – 6 RD-12 / March 99...

  • Page 26: Talkback To Control Room

    In either case, current should not exceed 30 milliamps. is suggested. Off Tally Identical to “On Tally” (preceding) only this function keys off the module’s channel OFF switch. Off Tally A is Pin 10(D); Off Tally B is Pin 10(C). page 2 – 7 RD-12 / March 99...
  • Page 27 CONTROL CONNECTIONS ................... 3-6 Remote ON & OFF ....................3-6 On Tally ........................3-7 External START & STOP ..................3-7 Ready ........................3-7 Typical Hook-Up Diagram ..................3-8 page 3 – 1 RD-12 / March 99 RD-12 / Jan 00...

  • Page 28: Module Overview

    All audio and control input and output signals are made via four 12- pin AMP type connectors mounted in the bottom of the console’s mainframe, directly underneath each individual module. page 3 – 2 RD-12 / March 99 RD-12 / July 99...

  • Page 29: Internal Programming Options

    Mutes Like MMD-5 inputs, an SLD-5 module can be programmed to mute studio speakers when the channel is ON. The RD-12 console has three mute control lines: control room, studio one and studio two. Each of these may be activated by either an A or B input source. The first three positions...

  • Page 30: Utility Bus Pre-Fader

    OFF switch is locked up. With SW7 set to PULSE this type of problem is eliminated; the module is turned off and left immediately ready for further control input. page 3 – 4 RD-12 / March 99 RD-12 / Aug 01...

  • Page 31: Remote Start/Stop - Normal Vs. Efs

    Pin 9 – B In Lt HI Pin 8 – B In Lt LO Pin 10 – B In Rt SH Pin 12 – B In Rt HI 11 10 Pin 11 – B In Rt LO page 3 – 5 RD-12 / March 99...

  • Page 32: Control Connections

    A 5 volt signal (which may be sourced by the external machine), page 3 – 6 RD-12 / March 99 RD-12 / Jul 00...

  • Page 33: On Tally

    READY provide a 5 volt signal to Pin 8 (C), positive relative to Pin 6 (C). As long as the voltage is maintained, the module’s OFF LED will be illuminated. A diagram showing typical connections is shown on the next page. page 3 – 7 RD-12 / March 99 RD-12 / Jan 00...
  • Page 34 A OFF- ITC Delta III DB-25 Connection Instructions ITC Delta III Cart Player ref: RD-12 Stereo Line Input Module (SLD-5) (Use two AMP male connectors on each end of cable) page 3 – 8 RD-12 / March 99 RD-12 / Apr 00...
  • Page 35 AMP A, B Connectors — Analog Audio............4-3 AMP D Connector — Digital Outputs............... 4-4 Master Output Module 2 (AUD and UTIL) AMP A, B Connectors — Analog Audio............4-4 AMP D Connector — Digital Outputs............... 4-4 page 4 – 1 RD-12 / March 99...

  • Page 36: Module Overview

    O U T P U T M O D U L E S Output Modules (OMD-5) Module Overview Each RD-12 console has two master output modules: the first handles the console’s Program outputs (OM1), the second Audition and Utility (OM2). OM1 output module has installed jumpers J3, J4 for Program output;...

  • Page 37: Internal Programming Options

    Bypass” (preceding section) if you intend to use these points. Pin 10 – PGM Rt Insert In SH Pin 12 – PGM Rt Insert In HI Pin 11 – PGM Rt Insert In LO page 4 – 3 RD-12 / March 99...

  • Page 38: Amp D Connector - Digital Outputs

    Pin 9 – UTIL AES Out HI Pin 8 – UTIL AES Out LO Pin 10 – AUD AES Out SH Pin 12 – AUD AES Out HI Pin 11 – AUD AES Out LO page 4 – 4 RD-12 / March 99...
  • Page 39 Cue Mute ........................ 5-3 Mono Cue ....................... 5-3 Hook-ups..................5-4 AMP A, B Connectors — AUDIO................5-4 AMP B Connector — CONTROL................5-4 On-Air Tally....................... 5-4 AMP D Connector — AUDIO.................. 5-5 page 5 – 1 RD-12 / March 99...

  • Page 40: Module Overview

    Control Room Module (CRD-5) Module Overview The CRD-5 module is the RD-12 console operator’s monitor module. It allows him to listen to the console’s three stereo outputs (PGM, AUD & UTL) as well as two external stereo line level inputs brought directly into the module.

  • Page 41: Internal Programming Options

    (down). This will send a summed L+R cue signal to both cue left and right signal paths. Note the factory default setting for this switch is stereo cue. page 5 – 3 RD-12 / March 99 RD / July 99...

  • Page 42: Hook-Ups

    2 amps @30VDC. Pin 11 – On-Air Tally Relay COM Pin 12 – On-Air Tally Relay N.O. page 5 – 4 RD-12 / March 99...

  • Page 43: Amp D Connector - Audio

    Pin 8 – Lt Ext 2 In LO Pin 10 – Rt Ext 2 In SH Pin 12 – Rt Ext 2 In HI Pin 11 – Rt Ext 2 In LO page 5 – 5 RD-12 / Nov 03 RD-12 / March 99...
  • Page 44 Hook-ups ..................6-4 AMP A, B Connectors — AUDIO ................6-4 AMP B Connector — CONTROL ................6-4 Tally 2 and Tally 3 ..................... 6-4 AMP C, D Connectors — AUDIO ................6-5 page 6 – 1 RD-12 / March 99...

  • Page 45: Module Overview

    C and D connectors (near the console armrest) accept the module’s two external source inputs, and output two additional pre- level control studio outputs.All audio connections are (+4dBu bal- anced) analog signals. page 6 – 2 RD-12 / March 99...

  • Page 46: Internal Programming Options

    TB signal. Note also if a studio is muted, talkback cannot be heard. However, if a studio is programmed to DIM instead of MUTE, talkback audio could presumably make it from the studio monitor speakers to the open studio mic. page 6 – 3 RD-12 / March 99...

  • Page 47: Hook-Ups

    Maximum current through Pin 12 – Tally 2 Relay N.O. the tally relay closures is Pin 8 – Tally 3 Relay COM 2 amps @30VDC. Pin 9 – Tally 3 Relay N.O. page 6 – 4 RD-12 / March 99...

  • Page 48: Amp C, D Connectors - Audio

    Pin 8 – Lt Ext 2 In LO Pin 10 – Rt Ext 2 In SH Pin 12 – Rt Ext 2 In HI Pin 11 – Rt Ext 2 In LO page 6 – 5 RD-12 / March 99...

  • Page 49: Chapter 7 - Meter Output Module

    M E T E R O U T P U T M O D U L E Meter Output Module (MOD-5) Chapter Contents Module Overview................ 7-2 Internal Programming Options ..........7-2 Hook-ups..................7-2 page 7 – 1 RD-12 / March 99...

  • Page 50: Module Overview

    Meter Output Module (MOD-5) Module Overview Each RD-12 console has one meter output module, which drives the console’s three pairs of left-right VU meters: PGM, AUD and UTL. Recessed front panel trim pots calibrate the three meter pairs. A VU TRIM cover strip (not shown) can be used to prevent trimpot access once calibration is set.
  • Page 51 C P U & D S P M O D U L E S CPU Central Processor (CPU-5 Module) DSP Digital Processor (DSP-5 Module) Chapter Contents Module Overview................8-2 AES Clock Sync......................8-2 CPU-5 Display ......................8-2 page 8 – 1 RD-12 / March 99...

  • Page 52: Module Overview

    Appendix). AES Clock Sync If you wish to sync your RD-12 console to an external clock source (or use the console master clock signal to control an external device) the AES Sync port is available on the DSP-5 module AMP A connector: Pin 1 –...
  • Page 53 Internal Programming Options - Piggyback PCB ....9-5 External In....................... 9-5 Cue Pre/Post ......................9-5 Gain Trimpots ......................9-5 Hook-ups..................9-6 AUDIO CONNECTIONS (AMP A, B)..............9-6 AUDIO and CONTROL CONNECTIONS (AMP C, D) ........... 9-6 page 9 – 1 RD-12 / March 99...

  • Page 54: Module Overview

    An easy source choice here would be DJ mic module’s INSERT OUT port. page 9 – 2 RD-12 / March 99 RD-12 / June 99...

  • Page 55: Automatic Features

    Generally used to to record phone segments in advance of actual airplay. Composite Minus Callers – This includes everything but the callers. Callers Only – No talent, no DJs, no music; just caller voices. page 9 – 3 RD-12 / March 99 RD-12 / June 99...

  • Page 56: Output Assign Switch Enable

    SW3 position 1 activates the on-air tally control line Remote tallies hooked-up to the console SW3 position 2 activates tally 2 at the Control Room mod- SW3 position 3 activates tally 3 ule (CRD-5) page 9 – 4 RD-12 / March 99...

  • Page 57: Cue Dropout

    CR7 – sets the module’s “composite” output level CR8 – sets the module’s “composite minus callers” (“talent”) output level CR5 – sets the module’s “callers only” output level page 9 – 5 RD-12 / March 99 RD-12 / Oct 99...

  • Page 58: Hook-Ups

    AMP C connector Pin 8 – Callers Only Out LO Pin 10 – To Hybrid 1 Out SH Pin 12 – To Hybrid 1 Out HI Pin 11 – To Hybrid 1 Out LO page 9 – 6 RD-12 / March 99...
  • Page 59 START/STOP COMMON connections are the emitters, while the START and STOP connections are the collectors, of the opto’s NPN transistors. Correct polarity must be observed when using these outputs. page 9 – 7 RD-12 / March 99...
  • Page 60 L I N E P R E S E L E C T O R M O D U L E Line Preselector Module- Analog (LSA-5; optional) Chapter Contents Overview .................... 10-2 Internal Programming Options ............10-2 Hook-ups.................... 10-3 Audio Inputs........................10-3 Outputs ..........................10-4 page 10 – 1 RD-12 / March 99...

  • Page 61: Overview

    All audio input and output signals are made via four 12-pin AMP connectors mounted in the bottom of the console’s mainframe, directly underneath this module. Internal Programming Options There are no internal programming options on the LSA-5 module. page 10 – 2 RD-12 / July 99 RD-12 / March 99...

  • Page 62: Hook-Ups

    Pin 8 – Line 6 Lt In LO Pin 10 – Line 6 Rt In SH Pin 12 – Line 6 Rt In HI Pin 11 – Line 6 Rt In LO page 10 – 3 RD-12 / March 99...

  • Page 63: Outputs

    Pin 8 – Line Lt Out LO AMP D connector 11 10 Pin 10 – Line Rt Out SH Pin 12 – Line Rt Out HI Pin 11 – Line Rt Out LO page 10 – 4 RD-12 / March 99...
  • Page 64 Power Connections ......................11-4 Hook-ups – LSR-500 ................. 11-4 Analog Audio Inputs ......................11-4 Digital Audio Inputs ......................11-5 Analog Outputs ......................... 11-6 Digital Outputs ........................11-6 DB Connector Pinout Drawing (LSR-500) ........11-7 page 11 – 1 RD-12 / March 99...

  • Page 65: Overview

    1 1 1 1 input is dipswitch-selectable for either analog or digital) and outputs both an analog and digital stereo signal, which may be wired back to RD-12 2 2 2 2 console input ports. Wiring between the console’s LSD-5 preselector module and the rackmount switcher is via two factory supplied pin-for-pin DB-25 connector cables: the module’s upper DB is used for control;...

  • Page 66: Hook-Ups - Lsd-5

    Pin 9 - Line 3 (LSR-500 DB-25 Pin 15) Pin 10 - Digital Ground (LSR-500 DB-25 Pin 2) Pin 11 - Line 2 (LSR-500 DB-25 Pin 14) Pin 12 - Line 1 (LSR-500 DB-25 Pin 1) page 11 – 3 RD-12 / March 99...

  • Page 67: Power Connections

    Pin 6 – Line 3 Lt In LO Typical DB-25 Pin 5 – Line 3 Rt In SH connector Pin 4 – Line 3 Rt In HI Pin 17 – Line 3 Rt In LO page 11 – 4 RD-12 / March 99...

  • Page 68: Digital Audio Inputs

    Pin 19 – AES 5 In SH Pin 18 – AES 5 In HI Pin 6 – AES 5 In LO Pin 5 – AES 6 In SH page 11 – 5 RD-12 / March 99 RD-12 / Oct 99...

  • Page 69: Analog Outputs

    Pin 6 – Line Rt Out LO Typical DB-9 connector DIGITAL OUTPUTS (DB-9): Pin 2 – AES Out SH Pin 1 – AES Out HI Pin 6 – AES Out LO page 11 – 6 RD-12 / March 99 RD-12 / Oct 99...
  • Page 70 AES 7 IN HI AES 8 IN SH AES 8 IN LO AES OUT SH AES OUT LO AES 8 IN HI AES OUT HI DIGITAL INPUTS (DB-25) page 11 – 7 RD-12 / Oct 99 RD-12 / March 99...
  • Page 71 Hook-ups ................... 12-4 AMP B Connector — AUDIO ................12-4 AMP A, B Connectors — CONTROL ..............12-4 AMP D Connector — AUDIO ................12-5 AMP C, D Connectors — CONTROL ..............12-5 page 12 – 1 RD-12 / March 99...

  • Page 72: Overview

    AMP type connectors mounted directly beneath the module on the console mainframe’s bottom pan. There are four connectors: AMP A and B (towards the console meterbridge) handle inputs; AMP C and D connector (near the console armrest) outputs. page 12 – 2 RD-12 / March 99...

  • Page 73: Internal Programming Options

    3 - Ext -V position 4 - Ext +D Station Select Each ICM in daisy-chain hookup has own address, which is programed with “stations” slide switches SW2-SW9. Each ICM has only one slide switch “ON”. page 12 – 3 RD-12 / March 99...

  • Page 74: Hook-Ups

    Pin 6 - Station call line 1 Pin 5 - Station call line 2 Pin 3 - Station call line 3 AMP B connector Pin 2 - Station call line 4 Pins 1, 4 - Audio Common page 12 – 4 RD-12 / March 99...
  • Page 75 Pin 5 - Station call line 2 Pin 3 - Station call line 3 AMP D connector Pin 2 - Station call line 4 Pins 1, 4 - Audio Common page 12 – 5 RD-12 / March 99 RD-12 / Aug 00...
  • Page 76 T A P E R E M O T E M O D U L E Tape Remote Module (TRD-5; optional) Chapter Contents Module Overview ................13-2 Hook-ups .................... 13-3 START/STOP Function Control I/O .................. 13-3 Full-Function Control I/O ....................13-5 page 13 – 1 RD-12 / June 00...
  • Page 77 A A A A R R R R W W W W M M M M M M M M T T T T S S S S T T T T page 13 – 2 RD-12 / June 00...

  • Page 78: Amp C, D Connectors - Control

    Pin 2 – SW6 (STOP) N.O. Pin 3 – SW6 (STOP) LED- AMP C connector Pin 4 – SW6 (STOP) LED+ Pin 5 – SW5 (START) COM Pin 6 – SW5 (START) N.O. page 13 – 3 RD-12 / June 00...
  • Page 79 Pin 7 – SW2 (STOP) LED- Pin 8 – SW2 (STOP) LED+ Pin 9 – SW1 (START) COM Pin 10 – SW1 (START) N.O. Pin 11 – SW1 (START) LED- Pin 12 – SW1 (START) LED+ page 13 – 4 RD-12 / June 00...

  • Page 80: Full-Function Control I/O

    T T T T Pin 8 – SW5 (REC) LED+ Pin 9 – SW4 (PLAY) COM Pin 10 – SW4 (PLAY) N.O. Pin 11 – SW4 (PLAY) LED- Pin 12 – SW4 (PLAY) LED+ page 13 – 5 RD-12 / June 00...
  • Page 81 Pin 8 – SW2 (FF) LED+ Pin 9 – SW1 (RTZ) COM Pin 10 – SW1 (RTZ) N.O. 11 10 Pin 11 – SW1 (RTZ) LED- Pin 12 – SW1 (RTZ) LED+ page 13 – 6 RD-12 / June 00...
  • Page 82 M E T E R B R I D G E a n d C L O C K Meterbridge and Clock Chapter Contents Overview ..................14-2 Replacement Parts ..............14-2 Clock .................... 14-2 Controls ........................14-2 Setting the Time ....................... 14-3 Battery Backup ......................14-3 Operational Modes ....................14-3 page 14 – 1 RD-12 / March 00...

  • Page 83: Overview

    A minor readjustment of the trimmer will compensate for this effect. page 14 – 2 RD-12 / March 00...

  • Page 84: Setting The Time

    It can also be programmed to count in either 12 hour or 24 hour modes, and the internal counters can be slaved from another clock or other sources of 1 Hz timing signals (TTL levels). Contact factory technical support for further information. page 14 – 3 RD-12 / March 00...
  • Page 85 Digital Superphone I/O Card Schematic (SPND-500) ........... 15-13 Analog Superphone I/O Card Schematic (SPNA-600)........... 15-14 Digital/Audio Line Select Rackmount Schematic (LSR-500) ........ 15-15 Tape Remote Module Schematic (TRD-500)............15-17 Intercom Module Schematic (ICMD-500) ............... 15-18 page 15 – 1 RD-12 / Aug 2000...
  • Page 86 74ABT244 IC PINOUT VIEWED FROM ABOVE (COMPONENT SIDE) BD[0:7] BD[1] ACCESFORME I/O1 I/O18 REGFADER MBOARD I/O2 I/O19 R121 XTBTOCRA CLKXA TOEPLD1 I/O3/GCK1 I/O20/GTS1 10.0K 4.99K XTBTOCRB R180 BD[3] XDCSA6 I/O4 I/O21 DBTYPE0 BD[0] XONA 10.0K BXDDS TOEPLD0 I/O5/GCK2 I/O22/GTS2 4148 DBTYPE1 BD[1] XONB...
  • Page 87 -10dBu C115 10uF MICAINHI UDB/24 100uF -50dBu SSM2017 10uF MIC"A" MICAINLO 330pF UDB/12 R100 R163 R164 R130 R131 4053 40.2K UDB/25 C5V1 C5V1 AGND C116 C117 4.99K 4.99K 5.1V 5.1V 10.0K 10.0K MIC"A" 0.001uF 0.001uF -2dBu AGND GAIN AGND TRIM -2dBu C4 10uF C30 100uF...
  • Page 88 36 PIN EDGE CONNECTOR UPPER UPPER DB-25 DB-25 CT10 AGND AGND 36/1 36/2 MICAINLO MICAINHI 36/3 36/4 AGND MICBINLO 36/5 36/6 MICBINHI AGND 36/7 36/8 36BUSPIN9 36BUSPIN10 36/9 36/10 AGND 36BUSPIN12 36/11 36/12 36BUSPIN13 AGND 36/13 36/14 36BUSPIN15 36BUSPIN16 36/15 36/16 AGND 36BUSPIN18...

  • Page 89: Stereo Line Input Module Schematic (Sld-500)

    40.2K 40.2K 40.2K 40.2K XDSPPGM PHONEPGM XDSPAUD XDSPAUX 74AC14 74AC14 XDSPUTL LDBSEQIN XSEQIN LDBSEQOUT PHONEAUD Phone Energize DIPSW: 74AC14 74AC14 DIPSW POS 1- PGM R124 DIPSW POS 2- AUD 0.1uF 4.99K DIPSW POS 3- AUX DIPSW POS 4- UTL OPTO1 OPTO1 LDBSEQIN LDBSEQOUT...
  • Page 90 36 PIN EDGE CONNECTOR 120 PIN EDGE CONNECTOR UPPER UPPER LOWER LOWER DB-25 DB-25 DB-25 DB-25 CT12 CT13 AGND XSHALT LDBONB LDBSTOPB 36/1 36/2 120/1 120/2 XLOALT XHIALT LDBOFFB LDBS/SB 36/3 36/4 120/3 120/4 XSHART XLOART LDBOFFB LDBS/SA 36/5 36/6 120/5 120/6 XHIART...
  • Page 91 INSTALL UPPER FOR 75 OHM DB-25 4.99K 0.1uF DBAESPA 4.99K VERF DBAESNB OUTA OUTB OUTC SDATA 0.01uF OUTD FSYNC FILT 74ACT02 INSTALL C0/E0 AM26C32A FOR 75 OHM Ca/E1 4.99K Cb/E2 Cc/F0 74ACT157 0.1uF Cd/F1 DBAESPB 4.99K Ce/F2 AGND DGND CS8412 DBAESNA 4.99K 0.01uF...
  • Page 92 NOTE: PHASE SYMBOLS DENOTE SIGNAL POLARITY AGND IN PHASE OUT OF PHASE VCCadc VCCadc -2dBu LINE LT TRIM LINE1LTHI 4.99K 4.99K +4dBu BAL 22uF C49 SSM2143 100uF C18 LINE1LTLO 0V DC +2.5V DC 74ACT08 VHC4053 AGND AGND SS14 0.001uF 0.001uF 40.2K SS14 AGND...
  • Page 93 OMD-500 CONTRACT NO. APPROVALS DATE DRAWN 6-19-00 600 Industrial Drive CHECKED New Bern, NC 28562 ISSUED SIZE FSCM NO. DWG. NO. 14S0029 W# 700226 SCALE OMD-500H PCB SHEET 2 OF 4 OMD-500 Output Module Schematic - Sheet 2 of 4 D-500/Jun 2000 Page 5-5...

  • Page 94: Output Module Schematic (Omd-500)

    OMD-500 CONTRACT NO. APPROVALS DATE DRAWN 6-19-00 600 Industrial Drive CHECKED New Bern, NC 28562 SIZE FSCM NO. DWG. NO. ISSUED 14S0030 W# 700226 OMD-500H PCB 4 OF 4 SCALE SHEET OMD-500 Output Module Schematic - Sheet 4 of 4 D-500/Jun 2000 Page...
  • Page 95 NOTE: PHASE SYMBOLS DENOTE SIGNAL POLARITY PGMLTMONITOR -2dBu 120/19 IN PHASE OUT OF PHASE C114 22uF 100uF -2dBu 4053 -2dBu 22uF PGMRTMONITOR 120/21 100uF C48 100uF C115 22uF NE5532 -14dBu CROUTLTLO -2dBu 36/15 UDB/6 5532 +4dBu BAL 4053 AGND SSM2142 CROUTLTHI AUDLTMONITOR 4053...
  • Page 96 CRTOCR 74ACT00 CRON 4.99K 4.99K 4.99K 4.99K 4.99K 1.00K 74ACT32 XDCUELOGIC CUE TO LT CR 120/39 0.1uF 0.1uF 0.1uF CUE TO RT CR MCUETOCRRT CRON 74AC14 74AC14 74ACT32 74ACT02 CUE TO LT HDPN 74ACT32 CUE TO RT HDPN 74ACT32 74LS74 MCUETOCRLT MMBTA05 CRMUTE...
  • Page 97 36 PIN EDGE CONNECTOR 120 PIN EDGE CONNECTOR UPPER UPPER LOWER LOWER DB-25 DB-25 DB-25 DB-25 CT10 AGND AGND 120BUSPIN1 120BUSPIN2 36/1 36/2 120/1 120/2 CUEOUTLTLO CUEOUTLTHI AGND EXT1LTLO CUELTMONITOR 36/3 36/4 120/3 120/4 AGND CUEOUTRTLO EXT1LTHI AGND 120/5 120/6 CUERTMONITOR 36/5 36/6...
  • Page 98 CUELTMONITOR CUERTMONITOR AGND 22uF CUELTMONITOR EXTCUEIN AGND -2dBu V-in -2dBu V+in 22uF EXTCUEIN 100uF AGND -2dBu 5532 TBACN 40.2K 22uF 100uF C20 CUEOUTLT AGND 5532 AGND AGND -14dBu AGND AGND -2dBu TBMONITOR AGND AGND V+in V-in CUEMONORT CUEMONOLT -2dBu CUEOUTMONO CUEOUTRT LEVEL 100uF C21...
  • Page 99 SC1PRELT PGMLTMONITOR 120/19 -2dBu 22uF 4053 PGMRTMONITOR 120/21 100uF 100uF -2dBu C100 22uF -14dBu 100uF C33 5532 4053 AUDLTMONITOR 4053 40.2K 40.2K 120/23 22uF C101 22uF SC1OUTLTLO AGND 36/15 UDB/6 AGND AGND NE5532 +4dBu BAL 4053 4053 AGND SSM2142 SC1OUTLTHI AUDRTMONITOR 4053 36/16...
  • Page 100 -2dBu 4.99K XDST1MUTE SC1MUTE 120/49 SC1PREOUTLTHI SC1PRELT 36/35 LDB/21 +4dBu BAL 74AC14 SSM2142 SC1PREOUTLTLO 36/34 LDB/9 4.99K 36/33 LDB/22 AGND TBTOSC1 NOTE: PHASE SYMBOLS DENOTE SIGNAL POLARITY AGND IN PHASE OUT OF PHASE 68pF 68pF ST1 TB MUTE ST 1 AGND AGND TBMUTE...
  • Page 101 36 PIN EDGE CONNECTOR 120 PIN EDGE CONNECTOR UPPER UPPER LOWER LOWER DB-25 DB-25 DB-25 DB-25 AGND AGND SC1PREOUTRTLO SC1PREOUTRTHI 36/1 36/2 120/1 120/2 TBOUTLO TBOUTHI AGND EXT1LTLO 36/3 36/4 120/3 120/4 AGND SPARELO EXT1LTHI AGND 36/5 36/6 120/5 120/6 SPAREHI AGND EXT1RTLO...
  • Page 102 S P N D-500 CONTRACT NO. APPROVALS DATE DRAWN 6-20-00 600 Industrial Drive CHECKED New Bern, NC 28562 ISSUED SIZE FSCM NO. DWG. NO. 14S0061 W# 700222 SCALE SPND-500E PCB SHEET 2 OF 4 SPND-500 Supe r Phone Module Schematic - Sheet 2 of 4 D-500/Jun 2000 Page 5-5a...
  • Page 103 CONTRACT NO. S P N D-500 APPROVALS DATE DRAWN 600 Industrial Drive 6-20-00 New Bern, NC 28562 CHECKED SIZE FSCM NO. DWG. NO. 14S0062 ISSUED W# 700222 SPND-500E PCB 3 OF 3 SCALE SHEET SPND-500 Supe r Phone Module Schematic - Sheet 3 of 4 D-500/Jun 2000 Page 5-5 b...
  • Page 104 NOTE 1: PHASE SYMBOLS DENOTE SIGNAL POLARITY TELMONITOR -2dBu IN PHASE OUT OF PHASE TEL1234IN AGND -2dBu 74AC14 AGND VCCadc COMPOUTLO LDB12 5532 +4dBu BAL EXT IN SLIDESW SSM2142 COMPOUTHI COMPOSITE AGND AGND LDB24 EXT1PRE 100uF VCCadc 4148 AGND 5532 AGND LDB25 -2dBu...
  • Page 105 CS5390 IC PINOUT VIEWED FROM ABOVE (COMPONENT SIDE) ALINE[1:8]ON AGND VREF+ ALINE[1:8]L,ALINE[1:8]R VREF- 100uF C107 NOTE: PHASE SYMBOLS DENOTE SIGNAL POLARITY AINL+ AINR+ -2dBu -2dBu IN PHASE OUT OF PHASE AINL- AINR- ACAL ALINE1LTINHI ALINE5LTINHI IA1DB24 IA2DB24 LGND +4dBu BAL 22uF C15 +4dBu BAL 22uF C13...
  • Page 106 VAd+ 0.1uF DLINE1INHI IDDB24 LM2940 DIG LINE SS14 +REGin +Diode +DIGrack R153 DLINE1INLO VIN OUT IDDB12 1 IN POLYSW 4.99K 4.99K 4.99K D5XRESET PQ05 C129 C131 1.0A C117 C128 C130 C115 C132 0.1uF 0.1uF OUTDATA 0.1uF 0.1uF 330uF 330uF 1N4002 IDDB25 D5XRESET SDATA...
  • Page 107 TO UPPER DB-25 TO LOWER DB-25 DIGITAL ANALOG ANALOG DIGITAL ANALOG CONSOLE CONSOLE OUTPUT INPUTS 1-8 OUTPUT INPUTS 5-8 INPUTS 1-4 CONNECTOR CONNECTOR DB-25 DB-25 DB-25 DB-9 DB-9 CONNECTOR CONNECTOR CONNECTOR CONNECTOR CONNECTOR LINE1out +DIGrack DOUTHI DLINE8INHI AOUTRTHI ALINE8RTINHI ALINE4RTINHI UDB1 LDB1 ODDB1...
  • Page 108 36 PIN EDGE CONNECTOR UPPER UPPER DB-25 DB-25 36BUSPIN1 SW8a 36/1 36/2 SW8a SW8aLED 36/3 36/4 SW8aLED SW7a 36/5 36/6 SW7a SW7aLED 36/7 36/8 SW7aLED SW6a 36/9 36/10 SW6a SW6aLED 36/11 36/12 SW6aLED SW5a 36/13 36/14 SW5a SW5aLED 36/15 36/16 SW5aLED SW4a 36/17...
  • Page 109 UPPER 36 PIN DB-25 EDGE CONN -2dBu CT5 21 C28 100uF SSM2143 CT5 22 -2dBu CT5 20 AGND LINE LOWER 120 PIN -2dBu IN/OUT AGND DB-25 EDGE CONN 100uF 100uF C17 100uF 5532 CT6 10 100uF 5532 CT6 11 VHC4053 0.001uF 50pF 40.2K...
  • Page 110 UPPER DB-25 CONN -2dBu -2dBu 4148 4.99K CT3 3 CT3 28 +4dBu C30 100uF +4dBu C42 100uF -2dBu SSM2143 SSM2143 CT3 4 CT3 29 C1 100uF CT1 4 LINE1 VHC4053 VHC4053 5532 CT3 2 CT3 27 AGND AGND 74HC14 74HC14 CT1 1 100uF 1.00K...

  • Page 111: Replacement Parts List

    Replacement Parts List ............... A-2 For the most part there are no user-replaceable parts in the RD-12 console. Exceptions are those controls and components that in the course of normal use may need maintenance (i.e., faders, pots, ON/OFF switches, indicator lamps, etc.). A complete list of available components is shown on the next page.
  • Page 112 A P P E N D I X REPLACEMENT PARTS — RD-12 AUDIO CONSOLE COMPONENT DESCRIPTION WS P/N SLD-5 ADC MODULE COMPLETE ANALOG STEREO LINE INPUT MODULE "002601" SLD-5SRC MODULE COMPLETE DIGITAL STEREO INPUT MODULE WITH SAMPLE RATE CONVERTER "002600"...
