AudioArts Engineering W-12 Technical Manual

Digital radio console
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
W - 12
D
R
C
IGITAL
ADIO
ONSOLE
T
M
ECHNICAL
ANUAL
September 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W-12 and is the answer not in the manual?

Questions and answers

Related Manuals for AudioArts Engineering W-12

Summary of Contents for AudioArts Engineering W-12

  • Page 1 W - 12 IGITAL ADIO ONSOLE ECHNICAL ANUAL September 2007...
  • Page 2 W-12 Digital Radio Console Technical Manual - 1st Edition W-12 Digital Radio Console Technical Manual - 1st Edition W-12 Digital Radio Console Technical Manual - 1st Edition W-12 Digital Radio Console Technical Manual - 1st Edition W-12 Digital Radio Console Technical Manual - 1st Edition ®...
  • Page 3 Wheatstone could void the user's authority to operate this equipment. R R R R R M M M M M ! ! ! ! ! W-12 / November 2007 E A D E A D E A D E A D...
  • Page 4 Place the ferrite on the console end of the cable that connects the W-12 console to the power supply.
  • Page 5 Wheatstone consoles are factory calibrated for 0dB or “unity gain” when the input channel fader is set to nominal (-12dB). The following is a stage by stage breakdown of the W-12 console’s gain stages: Analog Input (A-D Converter) Analog Input (A-D Converter)
  • Page 6 Since the W-12 console meters are true digital reading meters, they will always show the console's digital levels, and whether there are any "overs"...

  • Page 7: Table Of Contents

    Energizing ......................1-6 Audio and Control Wiring ............. 1-6 Digital Audio Connections ................... 1-6 Unbalanced Connections (analog audio) ............1-7 W-12 Console Rear Drawing ............1-8 Hook-Ups ..................1-9 Audio Connections ....................1-9 MPW-12 Mic Preamp Connections ..............1-9 ADC -W12 Analog Input Connections—DB-25 ..........1-10 SRC -W12 Digital Input Connections—DB-25 ...........
  • Page 8 C O N T E N T S Chapter 2 - Console Features Overview ..................2-2 W-12 Console Layout Drawing ..........2-3 Mic Preamp ................. 2-4 Line Level Inputs ................ 2-4 Outputs ..................2-5 Mute and Tally ................2-5 Console Programming Options ..........2-6 FADER 1 - 12 Dipswitches ..................
  • Page 9 Load Sheet ......................4-28 PHONS-12 Phone On/Off Switch Card Schematic ......................4-29 Load Sheet ......................4-30 SPS-100 Power Supply Schematic ......................4-31 Load Sheet ......................4-32 Appendix 1 Replacement Parts List ............. A-2 page Contents – 3 W-12 / Sep 2007...
  • Page 10 Energizing ......................1-6 Audio and Control Wiring ............. 1-6 Digital Audio Connections ..................1-6 Unbalanced Connections (analog audio) ............. 1-7 W-12 Console Rear Drawing ............1-8 Hook-Ups ..................1-9 Audio Connections ....................1-9 MPW-12 Mic Preamp Connections ..............1-9 ADC -W12 Analog Input Connections—DB-25 ..........1-10 SRC -W12 Digital Input Connections—DB-25 ..........

  • Page 11: Chapter 1 - Installation And Power

    I N S T A L L A T I O N a n d P O W E R Installation and Power Unpacking and Installing the Console The W-12 console, with its power supply, connecting cable, and technical manual, is shipped in one packing box. The console can be NOTE: This console...

  • Page 12: System Ground

    The first step is to ground the console. Note that as supplied from the factory, console rackmount power supply common, audio ground, and the W-12 mainframe are connected together at the console, but are NOT connected to electrical ground and the chassis of the power supply.

  • Page 13: Further Grounding Details

    10-32 screws and insulating washers between rails and faceplates. Once the system is properly grounded, proceed with the console power supply installation and connection (next section). page 1 – 4 W-12 / Sep 2007...

  • Page 14: Power Supply

    Rear view of the SPS-100 rackmount power supply The W-12 console is powered by an Audioarts Model SPS-100 rackmount power supply. This unit occupies two 19” wide rack spaces (total height 3-1/2”). Convection cooled, it requires ample ventilation space above and below it.

  • Page 15: Energizing

    Audio and Control Wiring Audio I/O and control connections to the W-12 console are made via DB-25, and DB-9 connectors, and 6-pin and 3-pin plug terminals, located on the rear panel of the console. See the console’s rear drawing on page 1-8.

  • Page 16: Unbalanced Connections (Analog Audio)

    At the unbalanced source machine’s output, connect the black wire (LO) to the shield. ANALOG OUTPUTS — All of the W-12 console’s line level analog outputs are electronically balanced, low impedance, outputs, expecting a minimum load of 600 ohms. The outputs are balanced but are not floating.

  • Page 17: Console Rear Drawing

    W-12 Console Rear page 1 – 8 W-12 / Sep 2007...

  • Page 18: Hook-Ups

    Pin 4 – Mic 1 Out HI Pin 9 – Mic 1 Out LO Pin 8 – Mic 2 Out SH Pin 7 – Mic 2 Out HI Pin 3 – Mic 2 Out LO page 1 – 9 W-12 / Sep 2007...

  • Page 19: Adc -W12 Analog Input Connections-Db-25

    Pin 24 – CR LT OUT HI Pin 12 – CR LT OUT LO Pin 11 – CR RT OUT SH Pin 10 – CR RT OUT HI Pin 23 – CR RT OUT LO page 1 – 10 W-12 / Sep 2007...

  • Page 20: Program Analog Output & Caller Connections-Db-25

    Pin 16 – CALLER IN SH Pin 15 – CALLER IN HI Pin 3 – CALLER IN LO Pin 2 – CALLER OUT SH Pin 1 – CALLER OUT HI Pin 14 – CALLER OUT LO page 1 – 11 W-12 / Sep 2007...

  • Page 21: Program Digital Output & External Input Connections-Db-25

    Pin 23 – Port 2 TB to CR Pin 24 – Port 2 +5V Digital Pin 25 – Digital Ground The connections for logic ports 3-4 and 5-6 follow the same pattern. page 1 – 12 W-12 / Sep 2007...

  • Page 22: Tally-3-Pin Plug Terminal

    Pin 3 – Tally N.O. Logic Port Mapping The W-12 console has six logic “ports” for interconnection to remote machines or control panels. These logic ports are assignable to the input fader channels 1-12 and the phone channel via dipswitch assignments (covered in greater detail on page 2-7).

  • Page 23: Talkback To Control Room

    Digital (Pin 18 for logic ports 1, 3 & 5; Pin 21 for logic ports 2, 4 & 6) and the On Tally connection. In either case the current should not exceed 30 milliamps. page 1 – 14 W-12 / Sep 2007...

  • Page 24: Tally B

    The Tally B signal can be used to activate an external, user-provided relay to “steer” the logic interface between an A and a B machine, or to simply block logic interfacing when B (or A) input is selected. page 1 – 15 W-12 / Sep 2007...
  • Page 25 MIC 2 IN HI MIC 1 & MIC 2 OUTPUTS DB-9 MIC 1 OUT SH MIC 1 OUT LO MIC 1 OUT HI MIC 2 OUT SH MIC 2 OUT LO MIC 2 OUT HI page 1 – 16 W-12 / Sep 2007...
  • Page 26 LINE 2 B LT IN SH LINE 2 B LT IN LO LINE 2 B LT IN HI LINE 2 B RT IN SH LINE 2 B RT IN LO LINE 2 B RT IN HI page 1 – 17 W-12 / Sep 2007...
  • Page 27 AES 1 B IN HI AES 2 A IN SH AES 2 A IN LO AES 2 A IN HI AES 2 B IN SH AES 2 B IN LO AES 2 B IN HI page 1 – 18 W-12 / Sep 2007...
  • Page 28 CUE RT OUT LO CUE RT OUT HI HDPN LT OUT SH HDPN LT OUT LO HDPN LT OUT HI HDPN RT OUT SH HDPN RT OUT LO HDPN RT OUT HI page 1 – 19 W-12 / Sep 2007...
  • Page 29 PGM 3 RT OUT SH PGM 3 RT OUT LO PGM 3 RT OUT HI CALLER IN SH CALLER IN LO CALLER IN HI CALLER OUT SH CALLER OUT LO CALLER OUT HI page 1 – 20 W-12 / Sep 2007...
  • Page 30 PGM 3 AES OUT LO PGM 3 AES OUT HI EXT LT IN SH EXT LT IN LO EXT LT IN HI EXT RT IN SH EXT RT IN LO EXT RT IN HI page 1 – 21 W-12 / Sep 2007...
  • Page 31 PORT 5 TB TO CR PORT 5 STOP PORT 5 REMOTE OFF PORT 5 START PORT 5 ON TALLY PORT 5 READY PORT 5 REMOTE ON PORT 5 COUGH page 1 – 22 W-12 / Sep 2007 W-12 / Dec 2008...

  • Page 32: Input Daughter Card Installation

    Please note that the gain switches affect both A and B inputs (see page 3-3) of the channel, so it is best not to have a +4dBu source on an A input and a lower level source on the same channel’s B input. page 1 – 23 W-12 / Sep 2007...
  • Page 33 Figure 3. Motherboard With Plugged In Card • Tighten the daughter card down (Figure 4) with the supplied two Phillips panhead screws (included in the console’s connector kit). Panhead Screw Figure 4. Assembled Card page 1 – 24 W-12 / Sep 2007...

  • Page 34: Hand Crimp Tool Wiring Instructions

    (see next page). Note that metallized plastic hoods for each connector are also supplied with the console. (4) Final step: jaws fully closed; the insulation tabs have been crimped. page 1 – 25 W-12 / Sep 2007...

  • Page 35: Pin Extractor Instructions

    Then pull out the terminal pin from Housing. It should never be necessary to discard a con- nector due to a wiring error. (5) Place extractor tip over pin terminal to be removed. page 1 – 26 W-12 / Sep 2007...
  • Page 36 C O N S O L E F E A T U R E S Console Features Chapter Contents Overview ..................2-2 W-12 Console Layout Drawing ..........2-3 Mic Preamp ................. 2-4 Line Level Inputs ................ 2-4 Outputs ..................2-5 Mute and Tally ................

  • Page 37: Overview

    C O N S O L E F E A T U R E S Console Features Overview Each W-12 console has two Input panels and one Master panel. The Input panel consists of six faders with associated switches. The Master panel has a CALLER, MONITOR and METERS sections. Each section is described below.

  • Page 38: Console Layout Drawing

    PGM 3 PGM 3 PGM 3 PGM 3 PGM 3 PGM 3 CALLER ASSIGN SET-UP METERS PGM 1 PGM 2 PGM 2 PGM 3 PGM 3 CALLER CONTROL HEADPHONE STUDIO W-12 Console Layout page 2 – 3 W-12 / Sep 2007...

  • Page 39: Mic Preamp

    C O N S O L E F E A T U R E S Mic Preamp The W-12 console is provided with one dual channel microphone (mic) preamp card, designed to bring balanced microphone level signals (nominally -50dBu) up to a +4dBu balanced line level for routing into any fader channel provided with an analog daughter card.

  • Page 40: Outputs

    (+4dBu balanced) input dedicated to use as a telephone caller input. Outputs The outputs for all three of the W-12’s main stereo buses, PGM 1, PGM 2, and PGM 3, are available as both analog and digital outputs. Both analog and digital outputs from a bus may be used at the same time.

  • Page 41: Console Programming Options

    ON. This is done to prevent feedback from any live mics in the Control Room. page 2 – 6 W-12 / Sep 2007 W-12 / Oct 2009...

  • Page 42: Logic Assign

    C O N S O L E F E A T U R E S Logic Assign The W-12 console has six logic ports. Positions 1 through 6 of the FADER 1-12 dipswitches, when activated, assign the corresponding logic port to the input channel: Dipswitch pos.1 assigns the logic port 6...

  • Page 43: Logic Assign

    MONITOR 1 dipswitch pos. 7 and 8 turn phantom power on for the two microphone input ports. Dipswitch pos. 7 activates phantom power for microphone 1 Dipswitch pos. 8 activates phantom power for microphone 2 page 2 – 8 W-12 / Sep 2007 W-12 / Aug 2008...

  • Page 44: Efs - European Fader Start

    Then cue will interrupt both sides of the headphones. Talkback to Studio The W-12 console has an internal talkback (TB) bus that allows audio from any of the faders 1-4 to be used by the console operator to talk to talent in the studio.

  • Page 45: Console Sample Rate

    C O N S O L E F E A T U R E S Console Sample Rate The W-12 console is set at the factory to operate at a sample rate of 44.1 KHz. Slide SW 2 on the motherboard is provided to change the sample rate to 48 KHz if desired.
  • Page 46 Studio EXT Switch ..................... 3-9 Studio Level Control ..................3-9 TB Button ......................3-9 TB Level Control ....................3-9 Meters (VU-W12) ....................3-10 VU Meter Pairs ....................3-10 Meters Select Buttons ..................3-10 page 3 – 1 W-12 / Sep 2007...

  • Page 47: Input Panel (Ip-W12)

    C O N T R O L S A N D F U N C T I O N S Controls and Functions Input Panel (IP-W12) The Input panel of the W-12 console has six identical strips representing six input channels. page 3 – 2...

  • Page 48: Source Select

    The OFF switch’s LED can be controlled by an external source machine to act as a “ready” indicator. External machine interfacing is only available on faders that have been assigned to a logic port. page 3 – 3 W-12 / Sep 2007...

  • Page 49: Master Panel (Mst-W12)

    C O N T R O L S A N D F U N C T I O N S Master Panel (MST-W12) The Master panel includes the Caller Input, Control Room monitor, Studio monitor, and Meters sections. page 3 – 4 W-12 / Sep 2007...

  • Page 50: Caller Input

    PROGRAM ASSIGN buttons or the position of the fader. If the phone channel is OFF its signal will still be present in the cue output if it has been assigned to cue. page 3 – 5 W-12 / Sep 2007...

  • Page 51: Caller Set-Ups

    The DJ microphone input channel can also be assigned via dipswitch to the console’s talkback (TB) bus. Any audio on the TB bus is heard by a caller when the caller COM button is pressed. page 3 – 6 W-12 / Sep 2007 W-12 / Oct 2009...

  • Page 52: Monitor Section

    Speakers may be provided in the Studio to allow the talent to listen to the console bus outputs at times that they are not actually on air. These speakers are fed from the console’s stereo Studio output. page 3 – 7 W-12 / Sep 2007...

  • Page 53: Control Room Program Select

    NOTE: If cue is muted and you turn the level control all the way up, then remove the condition that has the cue muted, the sound in the cue speaker will suddenly be VERY LOUD! page 3 – 8 W-12 / Sep 2007...

  • Page 54: Headphone Level Control

    (see page 2-9) will interrupt the regular monitor signal being sent to the studio output. TB Level Control The TB master level control sets the level of the talkback interrupt signal. page 3 – 9 W-12 / Sep 2007...

  • Page 55: Meters (Vu-W12)

    While the CUE indicator is lit, the selected switched meter source switch light goes off. Meters Select Buttons The METERS buttons select the source for the switched meter pair, as indicated above. page 3 – 10 W-12 / Sep 2007...

  • Page 56: W-12 Flow Diagrams

    ONS-6 On/Off Switch Card Schematic ........................ 4-27 Load Sheet ....................... 4-28 PHONS-12 Phone On/Off Switch Card Schematic ........................ 4-29 Load Sheet ....................... 4-30 SPS-100 Power Supply Schematic ........................ 4-31 Load Sheet ....................... 4-32 page 4 – 1 W-12 / Sep 2007...

  • Page 57: Inputs, Caller Feed, And Channel Logic

    DIGITAL AUDIO DATA FADER TRIM ANALOG TO DIGITAL FROM CALLER CONVERTER (ADC) DIGITAL TO ANALOG TO CALLER FROM DSP CONVERTER (DAC) W-12 Signal Flow Diagram - Inputs, Caller Feed, and Channel Logic page 4 - 2 W-12 / Sep 2007...

  • Page 58: Monitors

    (DAC) PGM 2 PGM 3 DIGITAL TO ANALOG CR OUT CONVERTER (DAC) ANALOG TO DIGITAL CONVERTER DIGITAL TO (ADC) ANALOG ST OUT CONVERTER (DAC) TB MONITOR W-12 Signal Flow Diagram - Monitors page 4 - 3 W-12 / Sep 2007...

  • Page 59: Master Outputs

    PGM 2 LT SWITCHED DATA PROGRAM 2 PGM 2 RT PGM 2 PGM 3 LT PROGRAM 3 PGM 3 RT PGM 3 CUE LT CUE RT W-12 Signal Flow Diagram - Master Outputs page 4 - 4 W-12 /Sep 2007...
  • Page 60 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF ISSUED SIZE FSCM NO. DWG. NO. 16S2001-1 W# 700916 INS-6A PCB 1 OF 3 SCALE SHEET page 4 - 5 W-12 / Sep 2007...
  • Page 61 600 Industrial Drive LOGIC ASSIGN 6 4148 New Bern, NC 28562 R13 1.00K CHECKED MY_ADDR_1A 4148 R14 1.00K ISSUED SIZE FSCM NO. DWG. NO. 16S2001-2 W# 700916 INS-6A PCB 3 OF 3 SCALE SHEET page 4 - 6 W-12 / Sep 2007...
  • Page 62 INS-6 Input Panel Switch Board Load Sheet page 4 – 7 W-12 / Sep 2007...
  • Page 63 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF ISSUED SIZE FSCM NO. DWG. NO. 16S2003-1 W# 700918 MNS-12A PCB 1 OF 2 SCALE SHEET page 4 - 8 W-12 / Oct 2007...
  • Page 64 MNS-12 Master Panel Switch Board Load Sheet page 4 – 9 W-12 / Sep 2007...
  • Page 65 5.6V 10.0K 0.22uF APPROVALS DATE DRAWN 9-4-07 600 Industrial Drive AGND New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2004-1 W# 700919 MNW-12 PCB 1 OF 3 SCALE SHEET page 4 - 10 W-12 / Sep 2007...
  • Page 66 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 9-4-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2004-2 W# 700919 MNW-12 PCB 2 OF 3 SCALE SHEET page 4 - 11 W-12 / Sep 2007...
  • Page 67 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 9-4-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2004-3 W# 700919 MNW-12 PCB 3 OF 3 SCALE SHEET page 4 - 12 W-12 / Sep 2007...
  • Page 68 MNW-12 Monitor Board Load Sheet page 4 – 13 W-12 / Sep 2007...
  • Page 69 13.3K MIC1OUTHI C13 33pF 4.99K MIC 1 -2dBu -10dBu NOTE: PHASE SYMBOLS DENOTE SIGNAL POLARITY +4dBu BAL C11 10uF C7 33pF MIC1INHI IN PHASE OUT OF PHASE 22uF -50dBu BAL 4.99K AGND SSM2017 -2dBu MIC 1 C3 10uF MIC1INLO 330pF 4.99K 5532 MIC1OUTLO...

  • Page 70: Load Sheet

    S C H E M A T I C D R A W I N G S MPW-12 Mic Preamps Load Sheet page 4 – 2 page 4 – 15 W-12 / Sep 2007...
  • Page 71 LINE 1 LT GAIN R34 1.30K 15 R29 4.99K 220pF C48 2.32K R32 BAT54 VA1+ -2dBu 33pF BAT54 220pF C47 VA1+ AGND AGND AGND A1_IN_LT_HI 10.0K 0.001uF 22uF C1 22uF 4.99K +4dBu BAL 5532 AGND BAT54 4.99K BAT54 A1_IN_LT_LO 10.0K 51 R33 4.7uF .1uF...
  • Page 72 LINE 2 LT GAIN 750 R85 1.30K 15 R77 4.99K 220pF C108 2.32K R79 BAT54 VA2+ -2dBu 33pF BAT54 220pF C107 VA2+ AGND AGND AGND A2_IN_LT_HI 10.0K 0.001uF 22uF C58 C104 22uF 4.99K +4dBu BAL 5532 AGND BAT54 4.99K BAT54 A2_IN_LT_LO 10.0K 51 R81...

  • Page 73: Load Sheet

    S C H E M A T I C D R A W I N G S ADCW-12 2 A/B Analog Inputs Load Sheet page 4 – 3 page 4 – 18 W-12 / Sep 2007...
  • Page 74 EDGE CONNECTOR FOR 75 OHM 0.1uF B1_IN_HI 4.99K MDL_ID[1] MDL_ID[0] B1_IN_LO LR_I 1.00K VERF MCLK_I SCLK_I TDM_I VDD_IO SDATA2_I SDATA1_I SDATA SDATA_I SDATA_O FOR 75 OHM 0.01uF SCLK_I SCLK_O 0.1uF A1_IN_HI R14 1.00K FSYNC LRCLK_I LRCLK_O FILT A1_IN_LO SMODE_I_0 C0/E0 1.0K SMODE_I_1 AGND...

  • Page 75: Load Sheet

    S C H E M A T I C D R A W I N G S SRCW-12 2 A/B Digital Inputs Load Sheet page 4 – 4 page 4 – 20 W-12 / Sep 2007...
  • Page 76 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 10-15-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2006-3 W# 700921 MBW-12A PCB 3 OF 7 SCALE SHEET page 4 - 21 W-12 / Oct 2007...
  • Page 77 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 10-15-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2006-4 W# 700921 MBW-12A PCB 4 OF 7 SCALE SHEET page 4 - 22 W-12 / Oct 2007...
  • Page 78 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 10-15-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2006-5 W# 700921 MBW-12A PCB 5 OF 7 SCALE SHEET page 4 - 23 W-12 / Oct 2007...
  • Page 79 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 10-15-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2006-6 W# 700921 MBW-12A PCB 6 OF 7 SCALE SHEET page 4 - 24 W-12 / Oct 2007...
  • Page 80 AGND AGND AGND AGND AGND AGND DRAWN 10-15-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2006-7 W# 700921 MBW-12A PCB 7 OF 7 SCALE SHEET page 4 - 25 W-12 / Oct 2007...
  • Page 81 MBW-12 Mother Board Load Sheet page 4 – 26 W-12 / Sep 2007...
  • Page 82 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 3-21-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 16S2001 W# 700917 ONS-6 PCB 1 of 1 SCALE SHEET page 4 - 27 W-12 / Sep 2007...

  • Page 83: Load Sheet

    S C H E M A T I C D R A W I N G S Bottom ONS-6 On/Off Switch Card Load Sheet page 4 – 5 page 4 – 28 W-12 / Sep 2007...
  • Page 84 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 600 Industrial Drive 3-21-07 New Bern, NC 28562 CHECKED SIZE FSCM NO. DWG. NO. 16S2005 ISSUED W#700920 SCALE PHONS-12 PCB SHEET 1 OF 1 page 4 - 29 W-12 / Sep 2007...

  • Page 85: Load Sheet

    S C H E M A T I C D R A W I N G S Bottom PHONS-12 Phone On/Off Switch Card Load Sheet page 4 – 6 page 4 – 30 W-12 / Sep 2007...
  • Page 86 - SA UR US - Sergey Averin - APPROVALS DATE DRAWN 8-10-07 600 Industrial Drive New Bern, NC 28562 CHECKED ISSUED SIZE FSCM NO. DWG. NO. 00S0041 W# 700915 SPS-100A PCB 1 OF 1 SCALE SHEET page 4 - 31 W-12 / Sep 2007...
  • Page 87 SPS-100 Power Supply Load Sheet page 4 – 32 W-12 / Sep 2007...
  • Page 88 Replacement Parts List ............... A-2 For the most part there are no user-replaceable parts in the W-12 console. Exceptions are those controls and components that in the course of normal use may need maintenance (i.e., faders, pots, ON/OFF switches, etc.). A complete list of available components follows. Contact Wheatstone technical support for further information.
  • Page 89 A P P E N D I X REPLACEMENT PARTS — W-12 CONSOLE COMPONENT DESCRIPTION WS P/N IP-W12 MODULE COMPLETE INPUT MODULE "009702" MST-W12 MODULE COMPLETE MASTER MODULE "009703" INS-W12 LOADED CARD ASSY INPUT PANEL LOADED CARD ASSEMBLY "009751" MST-W12 LOADED CARD ASSY MASTER PANEL LOADED CARD ASSEMBLY "009755"...
  • Page 90 A P P E N D I X REPLACEMENT PARTS — W-12 CONSOLE COMPONENT DESCRIPTION WS P/N POWER CONNECTOR 8 POSITION RECEPTACLE HOUSING "200121" POWER CONNECTOR PIN 40 AMP RIGHT ANGLE PCB MOUNT PLUG LONG "200117" "250044" HEADER 26 PIN PC MOUNT STRAIGHT HEADER ROHS COMPLIANT...
