TP-Link Aginet AXE11000 Quick Installation Manual

Quick Installation Guide
AXE11000 Tri-Band 10G Wi-Fi 6E Router
Connect the Hardware
If your internet comes from an Ethernet outlet, connect the router's WAN port to
it, then follow step 4 and 5 to complete the hardware connection.
Configure the Router
1. Connect your computer to the router (Wired or Wireless)
Wired
Turn off the Wi-Fi on your computer and connect it to the router via an Ethernet
cable.
Wireless
Connect your device to the router's Wi-Fi using the SSID (network name) and
Wireless Password printed on the label at the bottom of the router.
Power Adapter
2. Launch a web browser, and enter http://tplinkwifi.net or http://192.168.0.1 in the
address bar. Create a password to get started.
Note: If the login window does not appear, please refer to FAQ > Q1.
http://tplinkwifi.net
New Password
Confirm Password
Save
Turn off the modem, and remove the
backup battery if it has one.
Turn on the modem and then wait about
2 minutes for it to restart.
Router
Connect the modem to the router's
WAN port via an Ethernet cable.
Connect the power adapter to the router to turn
on the router.
Follow the LED indicators on the reverse side of this guide to verify that
the hardware is connected correctly.
3. Follow the step-by-step instructions of the Quick Setup to complete the initial
configuration.
