Integral LED ILSLA001 Installation Instruction

Product Code
ILSLA001
Thank you for purchasing an INTEGRAL LED product. When installed correctly this unit will
provide years of service. For support or warranty information please see integral-led.com.
Important Details – Please read prior to installation
1. Installation must be completed by a qualified electrician in accordance with all recognised local and national
electrical regulations.
2. Disconnect the power on the column base or remotely. Ensure that power is OFF during installation and can
not be unexpectedly reconnected. Disconnecting the power only on the NEMA socket is unsafe.
3. This canopy street light fitting is designed to operate with 220V-240V~ 50/60Hz electricity supply. Do not use
the canopy light fitting if damaged or if the LED protective cover is missing or damaged. Do NOT open or
remove the driver on the base of the unit.
4. This canopy light fitting is rated IP66.
5. This is a Class I product – EARTH must be connected.
6. Failure to comply with the recommendations and instructions provided herein may cause damage to the light
fitting or present a risk of injury or death (e.g. short-circuit, fire, burns or electric shock). Any modifications
to the light fitting, incorrect installation or unsuitable positioning may be dangerous to users and may cause
the warranty to become void.
7. Images are for illustrative purposes only.

Installation Instructions

8. Ensure that the power is OFF during installation and that power cannot be unexpectedly reconnected.
9. Losen the Allen screw on the base – see Fig 1.
10. On a bench, pass the cable through the cable gland. Pass the cable through the internal strain relief. Leave
adequate cable length to reach the electrical terminals. Tighten the cable gland and the strain relief. Use
H05RN-F cable or superior. The total cable length must be enough to reach the column terminal plus 1 meter.
11. Connect the cable to the connector: L – Brown, N – Blue,
12. Hang the hook to the eyelet – see Fig 3.
13. Put the light fitting body to straight position and tighten the Allen screw (2 Nm).
14. Attach the canopy to the street light using the 3 fixings – see Fig 4. Once you fit it, please take care
when handle.
15. Losen the 6 Allen screws on the slip fitter and fix it to the pole top – see Fig 5.
16. Evenly tighten the 6 Allen screws on the pole fixing (17 Nm) – see Fig 6.
17. Turn on power supply. Test with a NEMA 3 shorting cap. Replace the shorting cap by the photocell, if needed.
INSTALLATION INSTRUCTION
CANOPY STREET LIGHT LED
5 Years Warranty
Wattage CCT Lumens Output
45 4000K
NEMA Socket
3200 NEMA 3
- Green/Yellow – see Fig 2.
Spigot Adaptor IP rating
76 mm IP66
EN
