- Page 1 GEEK USER GUIDE...
- Page 2 Release weaver of claims C O NST RUCT I ON Rigging the twin tip Rigging the bindings Technical data RID IN G T HE GEEK Preparation Installation - top handle Installation - bindings Installation - fins Taking care of your equipment...
- Page 3 Never kite near people or obstacles, and always leave at least two line-lengths between you and the downwind line. It is extremely dangerous to kite near powerlines, roads, airports, cliffs, etc. For any questions regarding our equipment, please contact your local Gin Partner.
- Page 4 Improper use or misuse of Gin equipment greatly increases these risks to the user and to third parties. As a user of the Gin Kiteboar- ding product, you freely acknowledge and accept that you and third parties are exposed to known and unknown risks of injury.
- Page 5 RIGGING TWIN-TIP Set up the board and enjoy ! Screws M6 x 20 (20mm) Grab handle screws M6 x 12 (12mm) Fin holes Binding base inserts Base plate adjustment Handle Pads STANCE Fins 40mm W I D E NAR RO W...
- Page 6 Outside eyelet Stance settings Impact pads Base plate A set-up kit is included with the Geek 4. The bag contains the adjustable pads, the fins, the handle, and the screws. When disassembling the board for travel, this bag can be reused.
-
Page 7: Technical Data
TECHNICAL DATA SIZE 133 x 39 138 x 41 142 x 43 150 x 45 COLOR WEIGHT (KG) ROCKER MEDIUM MEDIUM MEDIUM MEDIUM... - Page 8 PREPARATION 4-POINT CHECK Is my personnal equipment correct and adapted ? (Helmet, harness, impact vest, wetsuit, ...) Is the board correctly set up and connected ? Does the weather allow for a safe ride ? Is the launch area clear and safe ?
-
Page 9: Installation
INSTALLATION TOP HANDLE Place the handle onto the board in the correct Using a screwdriver, insert two M6x20mm alignment, allowing the insert to be clearly visible screws through the handle mounting holes and through the handle screws tighten them. Do not over tighten the screws as this may cause damages. - Page 10 INSTALLATION BINDINGS Bindings should be placed on the board accor- To attach the foot straps to the base plate, start Make sure the bindings and board are clean and ding to their left and right positions. There are si- with the right base plate. One of the straps is la- free of dirt and sand.
- Page 11 Screws should be tightened until they are secure. Even when disassembled, the adjustable stance The Geek Pads are fully adjustable to fit a variety of foot sizes, shapes, and comfort levels, thanks to it mul- angle piece stays in place. Even in the boardbag, tiple velcros.
- Page 12 INSTALLATION FINS Place one M6x20 screw under the fin while hol- In the washer hole, insert one M6x 20 mm screw. ding it in place with a screwdriver. Line up the se- Allow the screw to appear through the bottom of On the underside of the board, align the fins with cond M6x 20 mm screw with the fin below using the board.
-
Page 13: Taking Care
Should you find any sign of wear, change the defect part without further delay. Most of our spare parts are available on the market. When not using your Geek board, store it in a board bag to prevent sun exposure, scratches, and other wear and tear. - Page 14 Blue Boardsports SA Route des Marais 10a - box 19 | 2074 La Tène | Switzerland contact@ginkites.com Geek User Guide English V1.0 WWW.GINKITES.COM...
