Summary of Contents for Vaisala TempCast FMP102
- Page 1 M212844EN-A Setup Guide Vaisala TempCast FMP102, FMP103...
- Page 3 Vaisala TempCast Vaisala TempCast is a wireless and self-powered sensor, with di erent variants to measure air temperature, relative humidity, and surface temperature. FMP102 FMP103 Temperature and relative humidity Temperature and relative humidity sensor sensor Surface temperature sensor Installation site requirements Max Ø...
-
Page 4: Setting Up Device
Setting up device To set up the device: 1. Activate the device at the installation location using the Vaisala Cast™ Connect mobile application. 2. Install the device at the installation location. 3. Align the surface temperature sensor (only for FMP103). -
Page 5: Activating Device
Follow the onscreen measurements to the connection is instructions. cloud. established. Establishing the cloud connection may take several minutes. To relocate device or change activation information Connect to the device with Vaisala Cast Connect, and deactivate and activate the device again. -
Page 6: Installing Device
2. Installing device Tilt angle Tilt angle 10° 60° Desired 2 ... 5 m measurement (6 ... 16 ft) point Select the installation For the surface temperature measurement, select the height. installation height so that you can aim the sensor at The recommended the desired measurement point (max. - Page 7 3. Aligning surface temperature sensor (FMP103 only) Loosen the finger Attach the Look through the screws to adjust the alignment tool on the alignment tool to aim sensor angles. The sensor. The tool can be the sensor at the sensor rotates 180° and positioned on either measurement point.
- Page 8 At the end of its 3-year lifetime the device needs to be replaced. Use the telescopic rod to install the new device to the existing bracket. Activate the new device using the Vaisala Cast Connect mobile application. Included in the product •...
- Page 9 Copy the surface the device from the temperature sensor angles bracket. to the new device. device Open Vaisala Cast Follow the onscreen Lift the new device to Connect and select instructions to activate the bracket. Connect to device.
-
Page 10: Removing Batteries
WARNING! Make sure that the battery is not subjected to an extremely low air pressure. Extremely low air pressure can result in an explosion or the leakage of flammable liquid or gas. WARNING! Only use batteries delivered with the sensor by Vaisala. Loosen 3 screws and Detach the power Remove the remove the cover. - Page 11 Locking key Polyamide Plastic waste Alignment tool Stainless steel, polyoxymethylene Metal waste, plastic waste Telescopic rod Aluminum, plastic Metal waste, plastic waste If needed, you can send the device to Vaisala for recycling. Contact Vaisala technical support for instructions.
- Page 12 WARNING! Failure to comply with these precautions or with specific warnings elsewhere in these instructions violates safety standards of design, manufacture, and intended use of the product. Vaisala assumes no liability for the customer’s failure to comply with these requirements.
