- Page 1 PostMount 8-A with ECO-Rail Code-Compliant Planning and Installation Guide V 3.0 Complying with AS/NZS 1170.2: 2021 Last Updated - Mar. 2023...
-
Page 2: Table Of Contents
Installation Guide / PostMount 8-A with ECO-Rail Introduction Clenergy PVezRack® PostMount 8-A is a ground mounting system suitable for large scale commercial List of contents and utility scale installations. PVezRack® PostMount 8-A has been developed to fit any PV module in Introduction the outdoors and uneven ground areas. -
Page 3: Tools & Components
Installation Guide / PostMount 8-A with ECO-Rail Tools and Components Tools Allen Key 6 mm Spanner Torque Wrench 5m Tape String & Marker Pen Components Anchoring Kit Mixing Nozzles ER-R-ECO/XXXX ER-RT-100/2900 ER-RT-70/2600 ER-P-152/3000 ER-SC-PM6/PM8 ECO-Rail x 6 PM6-A Rectangular PM6-A&PM8-A... -
Page 4: System Overview
8. ECO-Rail Side view drawing of PVezRack® PostMount 8-A is shown below. The panels tilt angle and embedment depth below are for reference only. Please refer to Certificate Letter to obatin the certified max panels tilt angle and min embedment depth for different wind regions and different soil types. - Page 5 Installation Guide / PostMount 8-A with ECO-Rail 2. Precautionary Measures for Stainless-Steel Fastener Installation Improper operation may lead to the deadlock of bolts and nuts. Follow the steps below to reduce this risk. Reduce the friction coefficient (1) Ensure that the thread surface is clean (no dirt or contaminant).
- Page 6 Avoid damaging the anodized or galvanized surfaces. 3. Installation Dimensions All drawings and dimensions in this installation guide are for generic reference. The PVezRack® PostMount 8-A is to be optimized to suit specific conditions for each project and documented in engineering drawings. As a result, major components of the PVezRack®...
-
Page 7: Installation Instruction
Installation Guide / PostMount 8-A with ECO-Rail Installation Instruction 1. Pipe Installation Dig a hole with the diameter of 300mm . Place the pole into the middle of the hole and fill it with concrete (min 25 MPa strength). Maintain the position of the post. - Page 8 Installation Guide / PostMount 8-A with ECO-Rail 3. PM8-A Rectangular Tube-Master Installation 1) Fix the Rectangular Tube-Master at Steel Cap Assembly with M20*160 hex bolt, M20 nut, plain washer 20, and spring washer 20. See the mark (1). 2) Fix the Adjustable Tube at Rectangular Tube-Master with M20*160 hex bolt, plain washer 20, and spring washer 20, M20 nut.
- Page 9 Installation Guide / PostMount 8-A with ECO-Rail 4. Rectangular Tube-Landscape Installation Fix the 3pcs PM8-A Rectangular Tube-Landscapes at Rectangular Tube-Master on pre-welded L profile angle bracket with 2pcs M12*100 hex bolts, 2pcs M12 nuts , 2pcs plain washers 12 and 2pcs spring washers 12. Do not fasten the Nut until 3 Rectangular Tube-Landscapes aligned.
- Page 10 Installation Guide / PostMount 8-A with ECO-Rail 6. PV Module Installation Fix the PV panel to Rail, via Inter Clamps and End Clamps step by step until all the panels complete. Recommended torque for M8 bolts is 18~20 N·m End Clamp...
-
Page 11: Certification
Installation Guide / PostMount 8-A with ECO-Rail Certification - Certification - Code-Compliant Planning and Installation Guide V 3.0 - Complying with AS/NZS 1170.2: 2021... - Page 12 Installation Guide / PostMount 8-A with ECO-Rail - Certification - Code-Compliant Planning and Installation Guide V 3.0 - Complying with AS/NZS 1170.2: 2021...
- Page 13 Installation Guide / PostMount 8-A with ECO-Rail - Certification - Code-Compliant Planning and Installation Guide V 3.0 - Complying with AS/NZS 1170.2: 2021...
- Page 14 Installation Guide / PostMount 8-A with ECO-Rail - Certification - Code-Compliant Planning and Installation Guide V 3.0 - Complying with AS/NZS 1170.2: 2021...
- Page 15 Installation Guide / PostMount 8-A with ECO-Rail - Certification - Code-Compliant Planning and Installation Guide V 3.0 - Complying with AS/NZS 1170.2: 2021...
- Page 16 Installation Guide / PostMount 8-A with ECO-Rail - Certification - Code-Compliant Planning and Installation Guide V 3.0 - Complying with AS/NZS 1170.2: 2021...
- Page 17 Clenergy 1/10 Duerdin St Phone: +61 3 9239 8088 Clayton VIC 2168 Email: sales@clenergy.com.au Australia Web: www.clenergy.com.au @ClenergyGlobal / @ClenergyClub / ClenergyAUS @Clenergy @ClenergyClub @Clenergy_global @Clenergy A Clenergy Technologies Company...
