  • Page 1 Span Assembly Guide ACCESS TOWER SYSTEM...
  • Page 2 3T (Through the Trap) Safety Standard. Before assembly please read the safety notes carefully. Span 400 is a mobile access tower system complying with EN 1004 and WAHR, with vertical ladder access, designed for Class 3 loading. ASSEMBLY COMPONENTS...
  • Page 3 4. BUILD PROCESS Insert castors and Attach diagonal braces in Fit Guardrails (horizontal Continue diagonal bracing Fit trapdoor platform to adjustable legs into the 5 opposing directions from braces) to the 4 rung in a zig-zag pattern by the 7 rung of the tower.
