Samsung SM-N950U Complete Manual

page of 119

/ 119
Bookmarks

Quick Links

Download this manual

Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

Mobile Device

SM-N950U/W/U1

Common

CONTENTS

1. Safety Precautions

2. Specification

3. Product Function

4. Exploded View and Parts list

5. MAIN Electrical Parts List

6. Level 1 Repair

7. Level 2 Repair

8. Level 3 Repair

9. Reference data

Notice: All functionality, features, specifications,

and other product information provided in this

document, including but not limited to, benefits,

design, pricing, components, performance,

availability, and capabiliti-es of the product are

subject to change without notice. Samsung

reserves the right to alter this doc-ument or the

product described herein at anytime, without

obligation to provide notification of such

changes.

Need help?

Do you have a question about the SM-N950U and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung SM-N950U

Page 1 Samsung reserves the right to alter this doc-ument or the product described herein at anytime, without obligation to provide notification of such changes.
Page 2 This Service Manual is a property of Samsung Electronics Co.,Ltd. ⓒ Samsung Electronics Co.,Ltd Any unauthorized use of Manual can be punished under applicable International and/or domestic law. 2017. 08. Rev 1.0 Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 3 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 4 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 5 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 6 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 7 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 8 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 9 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 10 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 11 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 12 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 13 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 14 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 15 Level 1 Repair . S/W Do ownload -1. Prepa are for S /W Down nloading  In din3 v3.12 .10.exe) nstallation p program: Do ownloader P Program  M Mobile Phon  D Data Cable  M Mobile devic ce specific S S/W: Binary files ※...
Page 16 Level 1 Repair -2. S/W In nstallatio on Progra am (Down nloader pr rogram) "Odin3 v3. " 12.10.exe"  O Open up the e S/W Insta llation Prog gram by exe ecuting the Confidential a and proprietary y-the contents i n this service g guide subject to o change witho...
Page 17 Level 1 Repair 1. E Enable the c check mark by click on the followin ng options, - Ch heck Auto Reboot, F. Reset Tim e, Nand Era - Ch heck PIT - Ch heck BOOT TLOADER, P PDA, PHON NE, CSC an nd USERDA ATA Files...
Page 18 Level 1 Repair 2. E Enter into Do ownload Mo - En nter into Dow wnload Mod de by press sing Volume e Down butt ton, Intellige ence button n and ON/O OFF Button imultaneous sly followed d by pressin ng Volume u up button as s a direction...
Page 19 Level 1 Repair 3. C Connect the device to P PC via Data a Cable. ke sure that t the one of communica ation ports [ID:COM] b box is highlig ghted in blue. The d device is no ow connecte ed with the PC and rea ady to down...
Page 20 Level 1 Repair 4. S Start downlo oading the b binary files i nto the dev vice by click king Start bu utton on the reen. The gr reen colore d "PASS!" s sign will app pear on the e upper-left box if the ary files hav ve been suc...
Page 21 Level 1 Repair 2. IMEI w writing 2-1. Prepa aration - Ne ew IMEI wri ting Progra m has been n released. - Su upported Mo odel : Mode els which CA AB files are e uploaded o on HHPsvc INI File tegory, inst tead of ini fi...
Page 22 Level 1 Repair 2-2. IMEI writing P Process Run DASE UL_SVC_L Launcher_v3 3.0.12.exe Select Serv vice Mode Click and Select folder wher re the Laun cher exists Model name Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice...
Page 23 Level 1 Repair Select Mod Model name Check IME EI and click S System Set tting ※O Once you se etup the set ting, you do on t have to o do it again n, unless the ere is chang om second MEI progra am, check IM...
Page 24 Level 1 Repair Check IME I Write / IM EI Check a nd click IME EI SVC & R Repair Optio Check ‘SVC C , User Tic cket No’ and d click OK Confidential a and proprietary y-the contents i n this service g guide subject to o change witho...
Page 25 Level 1 Repair 8. C Click ‘Hardw ware Config g’ 9. C Click ‘Port S Setting’ Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf fringement of any y content or data a from this docum...
Page 26 Level 1 Repair Select Por rt Number a and SAVE Click OK to o proceed Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf fringement of any y content or data a from this docum...
Page 27 Level 1 Repair Click Mode el Info and O OK when po op-up show Click OK Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf fringement of any y content or data a from this docum...
Page 28 Level 1 Repair Input SKU_ _CODE and d BUYER, t then click S Save button. ※ Refer to HH HPsvc→IME EI Review t o check SK KU Code an d buyer M-N950U] N950USQU U1AQH5 N950USQU U1AQH5 Model SK Input IMEI Number an nd click App Confidential a...
Page 29 Level 1 Repair Start → ②In → ③Input T ① Click S rd & OTP → nput IMEI w writing ID an nd Passwor Ticket No Model n Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra...
Page 30 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 31 RF Calibra ation Progra - DA ASEUL_La auncher_v4 4.0.0.exe - DA ASEUL_CA AL_ALL_R Runtime_3 .1.316.0_r0 00537.CAB odel File (S SM-N950U U_OPEN_C CALIBRAT TION_Ver_ _3.1.315.4. .CAB) ※ I t is requir red to use e the latest t program  ...
Page 32 Level 1 Repair  S Setting Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf fringement of any y content or data a from this docum ment without Sam msung’s written a authorization is s...
Page 33 Level 1 Repair -2. RF Cal libration P Program 1. R Run the RF Calibration Program La auncher, DASEUL_La auncher_vx .x.xx.exe'. 2. C Check the Calibration' menu, and select 'Extr ract & Run'. Confidential a and proprietary y-the contents i n this service g guide subject to o change witho...
Page 34 Level 1 Repair 3. C Check the CAL' and op pen the file, then n select 'Sta art' button. Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf fringement of any y content or data...
Page 35 Level 1 Repair 4. C Change the Line Type t 'Block Ce ell' and disa able 'Smart C Cloud Cell'. Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf fringement of any...
Page 36 Level 1 Repair 5. S Set the GPIB B address o of MSTS(CM MW500) an d Power Su upply(E3632 2A) to enter Hardware C Config' 'Save'. (Ch eck the GP PIB address of equipme ents in adva ance) ① ④ ②...
Page 37 Level 1 Repair 6. P Press 'OK' o start RF C Calibration a after comple eting all set ttings. ① Model n name Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf...
Page 38 Level 2 Repair . Compo nents on the Rear r Case HRM , Fla ash LED Confidential and proprietary y-the contents in this service guide subject to change with hout prior notice Distribution, tra ansmission, or in nfringement of an ny content or data a from this docu ment without Sa...
Page 39 Level 2 Repair 2. Pre-req uisite Tweezers s / Disass'y y Stick / S Screw Driv Anti-stat tic Gloves Anti-s static Mat Plate CTA Disass sembly Up OCTA Disa assembly H Holder Ethyl l Alcohol Cotton n Swab Confidential and proprietary y-the contents in this service guide subject...
Page 40 Level 2 Repair 3. Parts w which mu ust be ch hanged a after repa OM descrip ption & par rt code KIT COD mage Remarks /S-SVC TA PE BG WP P OUTER Common) [GH8 81-15036A] Replace fo ck Glass re pair A/S-SVC T TAPE BG IN...
Page 41 Level 2 Repair 4. Disasse embly Deta ch the Back G Glass. And F Finger sensor Put the de evice in the e chamber a lowing below heating condi tion 1) De etach the left s side of Back g glass 2) De etach the Fing...
Page 42 Level 2 Repair Final ly Disassemb le Rear of bot tom side. Unscrew w PBA 1points (Use disassemble hole right sid de of Rear to deta ach it) ※ C Caution Be care of sc cratch ※ Ca aution Be care of Re ear and conne ector damage 1) Be...
Page 43 Level 2 Repair Deta ch other comp ponents. crew SUB PB BA 4points ※ C Caution ※ Ca aution Be care of se everal kinds of f damage 1) Be e careful not to o damage the SUB PBA Deta ach Ear Jack Deta ch SUB PBA...
Page 44 Level 2 Repair 5. Assemb Screw 4point in SUB B PBA. Attac ch SUB PBA a and Ear jack o on Front. ※ Caution ※ Ca aution 1) B Be care of chip p damage nea arby screw poi Be care of co oaxial cable da amage Attach...
Page 45 Level 2 Repair Attach h 2 coaxial cab ble, Battery co onnect and the Attach h Front CAM a and Iris CAM on PBA. other c connectors. (9 9 Point) ※ Caution ※ C Caution 1) B Be care of pre ess power/time 1) Be e care of FPC...
Page 46 Level 2 Repair Attach the finger sen nsor on the RE EAR and Screw 16 Point and d disassemble S SIM Tray from Assem ble the finger sensor on the e PBA device Caution ※ Ca aution ※ 1) Be e care of scrat tch and tilt.
Page 47 Level 2 Repair Attach h the back gla ss outside tap pe on the rear Attac ch the back gla ass on the RE EAR side. case ※ C Caution ※ C Caution 1) B Be care of scr ratch and tilt. 1) Be e care of scrat tch and tilt.
Page 48 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 49 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 50 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 51 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 52 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 53 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 54 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 55 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 56 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 57 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 58 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 59 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 60 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 61 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 62 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 63 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 64 Level 3 Repair . Compo nents Lay yout Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf fringement of any y content or data a from this docum ment without Sam msung’s written a...
Page 65 Level 3 Repair Confidential a and proprietary y-the contents i n this service g guide subject to o change witho out prior notice Distribution, tra ansmission, or inf fringement of any y content or data a from this docum ment without Sam msung’s written a authorization is s trictly prohibited.
Page 66 SM-N950U_NA_w/ LTE-U(LAA) Confidential 2017.08.07 RFFE #2 WTR5975 QET4100 TX_FBRX_LEG_P CPL_OUT TX_FBRX_LEG_M GND path : route side by side with FBRx input PRx_B5/8/12/13/17/18/19/20/26/28_BC0/10_GSM850/900 PRx LB_AB LB LFEM(HFQRX4WJB-361 ) 4.0 x 3.0 RFFE #2(PA&ASM) DRX_B5/8/12/13/17/18/19/20/26/28/29_BC0/10_GSM850/900 DRx LB_AB SUB ANT 1 RFFE #3(LNA), 38.4MHz (LB/MB) LB LPAMiD (SKY78160-11)
Page 67 V3001 L3029 L2042 R3008 TP3006 TP3005 TP3010 TP3011 R5047 U4012 TP3016 TP3009 TP3021 R3019 C2000 TP3015 TP3023 TP3017 C3099 R3020 C4049 L3021 R3003 TP3012 TP3024 R5011 C2002 L2043 C8080 L3020 C8047 C8079 R3004 C2082 L2023 TP3002 TP3008 U3004 TP3014 TP3013 C3011 R3011 C3024...
Page 68 L2051 ZD2001 L2025 C2083 V2000 L2002 C2043 F2001 C2022 F2002 L2030 L2012 L2007 L2017 C2057 U2011 L2032 L2004 C2059 C2048 L2022 ANT2024 L2044 L2026 V4004 U2008 ANT3003 L2020 C2049 L2034 ANT8002 ANT8003 L2013 L2039 V2024 C2053 L2003 C2050 TP7996 V8001 L8004 V8000 L8016...
Page 69 Level 3 Repair 3. Flow ch hart of Tro oublesho ooting. Oscill loscope Digital Mu ultimeter Power r Supply + dr river, ESD Safe Twee ezer 960 & Spec ctrum Analy yzer Solderin ng iron Confidential a and proprietary y-the contents i n this service g guide subject to o change witho...
Page 70 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 71 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 72 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 73 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 74 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 75 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 76 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 77 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 78 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 79 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 80 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 81 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 82 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 83 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 84 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 85 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 86 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 87 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 88 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 89 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 90 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 91 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 92 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 93 Level 3 Repair 4-23. GPS GPS is n not working nable GPS F Function in th he setting. Check GPS S function ON Resolder or r Replace Check the An ntenna conne ANT2001, A ANT2005 ANT2005 , ANT2004 Replace RE esolder or ch hange the wr rong elemen...
Page 94 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 95 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 96 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 97 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 98 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 99 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 100 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 101 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 102 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 103 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 104 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 105 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 106 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 107 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 108 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 109 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 110 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 111 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 112 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 113 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 114 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 115 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 116 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 117 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 118 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.
Page 119 Confidential and proprietary-the contents in this service guide subject to change without prior notice Distribution, transmission, or infringement of any content or data from this document without Samsung’s written authorization is strictly prohibited. Please purchase PDF Split-Merge on www.verypdf.com to remove this watermark.

This manual is also suitable for:

Sm-n950w Sm-n950u1
