WARNING:
Using power tools may result in overtourqing screws causing threads to strip. We
are not responsible for replacements on parts where power tools where used.
CARE & MAINTENANCE: To clean your product, use mild soap and water. For heavy soil build-ups use any non-abrasive household cleaners or ask your Sales Representative about
2
Sister Bay Furniture Cleaner. Please contact our Customer Service Department for assembly assistance, questions or replacement parts at (800) 505-7926 or email
support@sisterbayfurniture.com. Our Customer Service Department is available Monday-Friday 8:30 a.m. to 4:30 p.m. CST
HDPE
HARDWARE:
Allen Wrench
1x
17 Seat Asm
1x
2x
17-1-10 Frame
17 Rail F&B
Left Asm
Newport
Collection
48" Bench W/ Back.
MODEL No: 17-1-10
1x
24x
0-2993
PARTS:
1x
17-10 Back Asm
1x
17-1-10 Frame
17-1-10 Frame
Right Asm
Center Asm
1x
Advertisement
Table of Contents
Related Manuals for Sister Bay Newport 17-1-10
Summary of Contents for Sister Bay Newport 17-1-10
- Page 1 CARE & MAINTENANCE: To clean your product, use mild soap and water. For heavy soil build-ups use any non-abrasive household cleaners or ask your Sales Representative about Sister Bay Furniture Cleaner. Please contact our Customer Service Department for assembly assistance, questions or replacement parts at (800) 505-7926 or email support@sisterbayfurniture.com.
- Page 2 Newport Collection 48" Bench W/ Back. MODEL No: 17-1-10 DETAIL B DETAIL A Have [2x] Screws and Allen Wrench within reach for step 1B. Repeat Step 1 for 17-1-10 Frame Right Asm Put 17 Rail F&B into 17-1-10 Frame Left Asm Slots. Start fastening [2x] screws through frame into rail, leave loose.
- Page 3 Newport Collection 48" Bench W/ Back. MODEL No: 17-1-10 DETAIL E (Seat Slats Not Shown) DETAIL D DETAIL C Set 17 Seat Asm onto 17-1-10 Frame Center Asm & the slats should fit into the grooves on the left and right frame. Rotate 17-1-10 Frame Center Asm into center of rails, so the rails fit into the Fasten left &...
- Page 4 Newport Collection 48" Bench W/ Back. MODEL No: 17-1-10 DETAIL F DETAIL G (SLATS HIDDEN) Set 17-10 Back Asm into slot on center frame. Fasten into place with [6x] screws, 2 screws per frame (DETAIL F). Next fully tighten all screws from steps 1, 2, and 4.
- Page 5 Newport Collection 48" Bench W/ Back. MODEL No: 17-1-10 FINAL STEP: Sit down, rock side to side, and say "yep, that ain't going anywhere"...
