Life Gets Better With
USE AND CARE GUIDE
E02GF143
h
Questions, problems, missing parts? Before returning to the store,
please contact our Customer Service
service@alphamarts.com
THANK YOU
We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality
products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
Thank you for choosing PHI VILLA!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E02GF143 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for PHI VILLA E02GF143

Summary of Contents for PHI VILLA E02GF143

  • Page 1 THANK YOU We appreciate the trust and con dence you have placed in PHI VILLA through the purchase of our product. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Pre-assembly Safety Information Assembly Warranty Care And Maintenance What is Covered What is Not Covered Safety Information • Do not completely tighten screws until all screws are started.Tighten each bolt rmly and properly. • Some parts may contain sharp edges. Wear protective gloves as necessary. •...

  • Page 3: Pre-Assembly

    Pre-assembly (continued) Assemble the item on a soft, non-abrasive surface, such as carpet or cardboard to avoid damaging the item. Seek assistance to assemble bulky or heavy items. Identify all parts packed in the carton against the parts list. NOTE: Remove all the protective material carefully and DO NOT use a knife to prevent scratching the furniture.
  • Page 4 Pre-assembly (continued) Assemble the item on a soft, non-abrasive surface, such as carpet or cardboard to avoid damaging the item. Seek assistance to assemble bulky or heavy items. Identify all parts packed in the carton against the parts list. NOTE: Remove all the protective material carefully and DO NOT use a knife to prevent scratching the furniture.

  • Page 5: Assembly

    Assembly...
  • Page 6 Assembly...
  • Page 7 Assembly...
  • Page 8 Cleaning and Maintenance Clean the furniture with damp cloth, rinse thoroughly. Dry frame parts completely. Do not use bleach, acid or ● other solvents on the textile or metal parts. We recommend the use of furniture covers to protect the product when not in use. ●...
  • Page 9 ASSEMBLY INSTRUCTIONS USER’S MANUAL Before starting assembly:  Read all instructions throughly. Open and check boxes for parts list.  If any parts are broken or missing call or email customer service.  Keep all packaging until you are satisfied with your product. ...
  • Page 10 Assembly Instructions 28 Inch Gas Fire Pit Table · DANGER FLAMMABLE GAS UNDER PRESSURE. LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED CAUSING SERIOUS BODILY INJURY OR DEATH. CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS CYLINDER OR UNUSED LP-GAS.
  • Page 11 Table of Contents Table of Contents ............2 Operating Instructions .........1 Safety Information............2-4 Maintenance............Pre-Assembly...……………………...……………………. 5 Care and Cleaning ..........14 ..………………...……………………. 6 Troubleshooting ............ Package Contents Assembly..……………………………… ………..…8-1 Safety Information Read the instruction before use. This appliance must be installed in accordance with such regulations as are enforced.

  • Page 12: Safety Information

    Safety Information (continued) WARNING: You must provide propane gas and propane cylinder. Use a standard 20 lb. propane cylinder only. Use this heater only with a propane vapor withdrawal supply system. See Chapter 5 of the Standard for Storage and Handling of Liquefied Petroleum Gas, ANS/NFPA 58.
  • Page 13 Safety Information (continued) WARNING: Solid fuels shall not be burned in this appliance. The installation must conform with local codes or, in the absence of local codes, ANSIZ223. 1/NFPA54, NFPA58 Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2. This appliace must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).

  • Page 14: Pre-Assembly

    Pre-Assembly PLANNING ASSEMBLY Carefully remove all pieces from the carton and make sure that you have all parts (refer to the hardware and package contents list). If you are missing parts, please contact 855-600-9294 for further assistance. YOUR OWNER’S MANUAL Keep and store this Owner’s Manual for future reference.

  • Page 15: Package Contents

    Package Contents...
  • Page 16 Package Contents Front Leg Back Leg Front Leg Fire Glass Table Top With Burner Door Side Panel Side Panel With Window Gas Tank Support Handle AAA Battery...
  • Page 17 Assembly Step 1: Connect all four Legs (A,B,C,) to the Table Top with Burner (G) by using four M6 x10 Bolts (AA). NOTE: PLACE TABLE TOP TO NON-ABRASIVE SURFACE. PLEASE DON’T TIGHTEN THE HARDWARE AT THIS TIME. Don’t tighten the hardware. Step 2: Connect Side Panel (I) to Back Leg (B) by using four M6 x 10 Bolts (AA).
  • Page 18 Assembly (continued) Step 4: Connect Gas Tank Support (K) to the semi-assembled body by using four M6x10 bolts(AA) . Please tighten all the screws for step 1-4. Step 5: Step 5: Slide the hinge of Door (H) to Front Leg (C).
  • Page 19 Assembly (continued) Step 7: Put the cylinder into the Gas Tank Support (K), and secure the cylinder by tightening the screw in the gas tank support. Connect the hose and regulator to cylinder The propane cylinder is sold separately . Use a standard 20 lbs propane cylinder only.
  • Page 20 Operating WARNING: Never use this appliance for other than the intended use. DO NOT use this appliance to prepare food. Initial Lighting: When lit for the first time, the appliance emits a slight odor. This is a normal temporary condition caused by the “burn-in ”...

  • Page 21: Operating Instructions

    Operating (continued) LEAK TESTING OPERATION WARNING: A leak test must be performed annually or if a part of the gas system is replaced. WARNING: Never use an open flame to check for gas leaks. Be certain no sparks or open flames are in the area while you check for leaks.
  • Page 22 Operating (continued) LIGHTING CAUTION: Keep the outdoor gas appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids. CAUTION: Do NOT obstruct the flow of combustion and ventilation air. CAUTION: Check and clean burner/venturi tubes for insects and insect nests. A clogged tube can lead to a fire.

  • Page 23: Maintenance

    Maintenance Storage between uses: □ Turn the control knob to “OFF” position. □ Disconnect LP source. □ Store heater upright in an area sheltered from direct contact with inclement weather (such as rain, sleet, hail, snow, dust and debris). □ If desired, cover heater to protect exterior surfaces and to help prevent build up in air passages. NOTE: Wait until heater is cool before covering.

  • Page 24: Troubleshooting

    Troubleshooting PROBLEM PROBLEM CAUSE SOLUTION The flame and heat are The propane lighting Ensure lighting procedure is followed carefully. The valve low when the valve is procedure was not followed must be in the off position when the tank valve is turned on. turned to high.
