Page 2: What's In The Box
INTRODUCTION: Thank you on Your purchase of ONIDA FIRE TV. Your TV comes with the latest technology to enhance your TV experience. Your ONIDA FIRE TV can control all Alexa Enabled Devices. The latest eco-friendly power saving technology will ensure the TV will go into sleep mode within 30 minutes, if the TV is idle and no input is connected to the TV. - Page 3 3. When TV is ON, by pressing & holding this key for few seconds to put the TV into Standby *This function work in selected onida model only Note: The location and names of the function buttons and power button on the TV may vary according to TV model.
- Page 4 Turns TV power ON or OFF, when your TV is OFF the LED indicator on the Stand By front of the Tv will light up Hold down to turn on the ALEXA- enable microphone and start voice Alexa input. Release the button to end voice input. with ALEXA, you can use your voice to search for content control playback, and much more.
- Page 5 Initial Setup for Onida Fire TV With Unboxing Setting up language When the TV is switched on for the first time, the desired language selection menu is shown. Follow the below instructions to select the menu language: Fig.1 1.) Press the navigation button (4) on the Remote control to highlight the desired language then press the select button (3) on the remote control to confirm the selection Refer following image for language setup.
- Page 6 TV screen for paired remote control manually, pressing the “HOME’’ (9) button on the remote for 10 second. refer fig.4 Fig.4 When remote paired with Onida Fire TV following POP UP massage shown, it means now TV is connected to Fire TV. refer fig.5 Fig.5...
- Page 7 Set Up a Wireless or Wired Connection Fire TV supports wireless or wired Internet connections. Connect your Fire TV device to the Internet to access movies, TV shows, games, and apps. Wired Network Connection :(with initial setup ) a. Connect one end of an Ethernet cable (not included) to the back of your Fire TV, and then connect the other end to your router.
- Page 8 Wireless Network Connection: a. From the Home screen, select Settings > Network > Wi-Fi.Your Amazon Fire TV device automatically detects nearby Wi-Fi networks that broadcast their network name. Some networks are open for everyone to join, while others require a password to connect. b.
- Page 9 3.) WPS button (Wi-Fi Protected Setup) d. A code will appear on the screen. Enter this code into the router. It may take up to two minutes to connect. Refer fig. 10 and fig.11 for WPS Fig.10 Fig.11 Signing-in to Amazon account refer fig.12,fig.13,and fig.14 In order to use your Amazon Fire TV device, register it to your Amazon account.Refer fig.12 To register your device, connect it to the Internet.
- Page 10 Signing-in to Amazon account Note: If you do not have an Amazon account, press the navigation key (4) and select "l am new to Amazon and follow the instruction on screen to register. Refer fig.12 Once selected, you will be prompted to visit a web link to complete registration on the handheld device such as mobile phone or tablet If you purchased your Amazon Fire TV device online from Amazon using your Amazon account, it should already be registered to you.
- Page 11 Signing-in to Amazon account Enter your email id registered with Amazon account along with the password. FoIIow on screen instructions to enter an alphanumeric code to link your Amazon ID to TV set. refer fig.15 3.) Enter the email address that you use for your Amazon account, then select NEXT and press the select button (3) to confirm Fig.15 4.) Enter your Amazon account password, then select SIGN IN and press the select button...
- Page 12 5.) Select CONTINUE then press the select button (3) to confirm. 6.) If you would like to save your WI Fl password to your amazon account, select YES then press the select button (3) to confirm . If you do not want to save your WI Fl password to your account, select NO then press the select button (3) refer fig.18 7.) If you want to enable the parental controls you can do it at this point or you can do it later, Select "Enable Parental Controls"...
- Page 13 6.) Select the app(s) that you would like to download from the 'Original Show Services' section using the navigation button (4) and press the select button (3) to confirm 7.) Press the play/pause button (12), once you have chosen all the apps you'd like to download. A list of selected apps will appear.
- Page 14 DTH Connection with “EQUIPMENT SELECTION” Following Step Refer for DTH Connection with “EQUIPMENT CONTROL” page14...
-
Page 15: Optical Audio Out
Plug for connecting to external modem or network access equipment. connect an ethernet cable to this jack. Please refer page no. 18 On some TVs the headphone jack and audio out jack are Combined into one jack. see page no. 20 Connect HEAD PHONE headphones, a sound bar, analog speaker system, or a home theater system to this jack to listen to TV audio... - Page 16 Note: This manual is for common use. Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance. And for some models, certain options are not available. You can select all the features fromHome page 1.
- Page 17 • If the antenna is not installed correctly, contact qualified service personnel to correct the problem. • If the signal level for a channel is weak, the picture may be distorted. Adjust the antenna or use a highly directional outdoor or set top Antenna with a built in amplifier. •...
- Page 18 2. Connect an AV cable (not provided) to the AV jacks on your TV and to the AV out jacks on the DVD or Blue ray player. IMPORTANT : When you connect the audio using the AV jacks, the signals are analog 3.
- Page 19 5.)If you need to change the digital audio format, go to the Home menu, select Settings, then select Display & Sounds, then Select Audio Output, then select Digital Audio Format and change the setting to PCM or Dolby Digital. 6.)If you want to turn off your TV speakers, go the Home menu, select Settings, then select Display &...
- Page 20 Connecting Power : 1.) If your power cord is not permanently connected to your TV, connect it to the power connector on your TV. 2.) Connect the power cord to a power outlet. CAUTION: • Your TV should only be operated from the power source indicated on the label. •...
- Page 21 1) Inputs : On HOME page> setting > above window visible(Refer above image) When you select Inputs, the following options are available: a. HDMI 1 (ARC enabled) b. HDMI 2 c. HDMI 3 d. Antenna e. Composite f. Media player (USB) a.
- Page 22 2) Notification When you get into the notification window, it will give information about the following things, (a) system update (b) error codes (c) app updates, etc. You can press the option button to turn on or hide all application notification pop-ups. You can also turn on or off notifications from individual applications.
- Page 23 • Colour: Adjust color from :( - 50 - 0 - +50) • Tint: Adjust color from : (-50- 0 - +50) • Sharpness: Adjust sharpness from :(-25 - 0- +25) • Advance Settings: Explore more picture setting features such as White Balance, Dynamic Contrast, Dynamic Back light, Dynamic Noise Reduction etc..
- Page 24 9) Application A) App store: Allow apps. to update automatically, control in-app purchases, and manage how to open external market links. B) Manage installed applications: View and manage the installed applications, including force top, uninstall, clear data and clear cache. 10) Alexa The Alexa app helps you get more out of your Alexa Voice experience like setup music services, view to-do and shopping list on the go, and the history Of the requests.
- Page 25 accessibility 1.) subtitle: show subtitles for videos when available. 2.) voice view: manage voice guidance settings, including turning voice view on and off, Reading speed, and volume. 3.) text banner: display text related to the focussed item in a box with customizable font Size, colours &...
- Page 26 KY-ROCK KY-ROCK 32HIF3 32HIZ-R3 43FIF3 43FIZ-R3 ≤0.5 ≤0.5 HEAD PHONE /OPTICAL 32HIF3 32HIZ-R3 43FIF3 43FIZ-R3 L - 72.59 L - 72.59 L - 96.40 L - 96.40 W - 8.17 W - 111.7 W - 8.60 W - 12.10 D - 42.70 D - 42.70 D - 56.20 D - 56.20...
- Page 27 Installation of stand and wall mount for 32" LED TV page:27...
- Page 28 Installation of stand and wall mount for 32" ROCK LED TV Installation of stand and wall mount for 43" ROCK LED TV page:28...
- Page 29 SAFETY : PROPER TELEVISION PLACEMENT MATTERS • We are committed to making home entertainment safe and enjoyable. • As you enjoy your television, please note that all televisions - new and old - must be supported on proper stands or installed according to the manufacturer's recommendations. Televisions that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, carts, etc., may fall over, resulting in injury.
-
Page 30: Important Safeguards
The lightning flash with arrow head Symbol within an IMPORTANT SAFE GUARDS equilateral triangle is intended to alert the user to the Presence of un insulated "hazardous Voltage" within the product's Enclosure, which may be of sufficient Magnitude to induce a risk of electric Shock to persons. The exclamation point within an Equilateral triangle is intended to alert the user to the presence of Important operating and Maintenance (servicing) instructions in the literature... - Page 31 Warning Electric shock hazard To reduce the risk of fire or electric shock, do not remove any cover or expose the device to rain or moisture. No User-serviceable parts are inside. Refer servicing to qualified service technicians. Lightning For added protection for your TV during a Lightning storm, or when it is left unattended and Un-used for long periods of time, unplug it from the Power outlet and disconnect any antenna or cable System.
- Page 32 CAUTION Damage requiring service Unplug this TV from the power outlet and refer servicing to qualified service personnel under the following conditions: • When the power supply cord or plug is damaged or frayed • If liquid has been spilled or objects have fallen into your TV. •...
- Page 33 Terms And Conditions Of The Warranty • The Onida LCD /LED TV set is guaranteed against manufacturing defects Of parts & components for a period Of one year from the date Of purchase • In the event Of any manufacturing defect during the warranty period, the defective part Will be replaced/repaired by the Company free Of cost •...
- Page 34 Basic Troubleshooting for Fire TV Try these troubleshooting steps for resolving issues like a frozen screen, app errors, or problems with content such as movies, TV shows, games, and apps. Take Action: Many issues with your Fire TV can be solved by simply restarting your device.
- Page 35 page:35...
- Page 36 page:36...
