ORSTEEL Light TULIPA Technical Manual

TECHNICAL SHEMATICS
INSTALLATION SHEMATICS
1
2
1
3
Not submerged
4 4
USE A IP68 CONNECTOR
IP67
Connecteur
IP68
IP67
3
3
All data are given for information purposes only. They do not constitute a contractual commitment on our part and are subject
to change at any time.
49 49
Two people are needed to install the
projector, one person wraps it around
the shaft, while the other holds the
3
projector head.
Never rewind
a projector
already
installed.
Connecteur
IP68
IP68
Parallel wiring 230VAC
TECHNICAL MANUAL
TULIPA
230VAC
52 52
A+
A
The very stylish Tulipa shaft mounted marker light fixed on a driver support is simple to
install by burying its protected driver support in the ground. The top of this LED marker
light's shaft is flexible, and the head can be accurately swivelLED towards the object
to be lit. Uses 3 powerful LEDs to illuminate driveways, pathways, stairs, landscaped
gardens, trees, plants... It has been designed in particular for landscape architects and
blends perfectly into any green spaces.
Electrical features
POWER
SUPPLY
POWER
SUPPLY
WIRING
Characteristics
lighting techniques
AVERAGE LIFE OF THE
LED
COLOUR EMISSION
BEAM
INITIAL OUTFLOW
1,9
NGR
IP68 IK10
A++
T° max 55°C
Mechanical characteristics
3x2.5W SIZE
230VAC WEIGHT
Included MATERIAL
Parallel
General characreristics
OPERATING
TEMPERATURE
PROTECTION RAITING
RESISTANCE INDEX
60 000 hours
Certificated L90 B10
ENERGY CLASS
2700°K - 3000°K
APPLICANCE CLASS
4000°K - 6000°K
6°-25°-40°-115°
WALKOVER FIXTURE
634lm at 3000k
DRIVE-OVER FIXTURE
POWER SUPPLY
CABLES
PHOTOBIOLOGICAL
SAFETY
3000x49mm
1.9kg
Brass - Bronze
- 20°c ~+ 60°
IP68
IK10
A / A+ / A++
CLASS II
NO
NO
Supply wire 2x1
mm2 en IP68
Risk group I
