ORSTEEL Light PYRO Technical Manual

TECHNICAL SHEMATICS

70 70

INSTALLATION SHEMATICS

1
Version to be
screw
3
Version to be planted
All data are given for information purposes only. They do not constitute a contractual commitment on our part and are subject
to change at any time.
34 34
32 32
69 69
18 18
2
USE A IP68 CONNECTOR
Connecteur
IP68
Not submerged
Serial wiring 350-700mA
TECHNICAL MANUAL
PYRO
350mA-700mA
0,08
T° max 55°C
IP68 IK08
A+ NGR
A A++
The Pyro moving head floodlight provides high quality occasional lighting and is very
effective for highlighting small architectural details. With its discreet designer look,
this floodlight blends into your landscapes in a choice of natural colours, such as
Corten steel. It adapts to all surfaces and offers adjustable lighting to 180 degrees.
Electrical features
POWER 2,5W
SUPPLY 350mA-700mA
POWER Not included
SUPPLY
WIRING Serial
Characteristics
lighting techniques
60 000 hours
AVERAGE LIFE OF THE
LED Certificated L90 B10
COLOUR EMISSION 2700K - 3000K -
4000K - 6000K
RED - GREEN
BLUE - AMBER
BEAM 6°-25°-40-115°
237lm at 3000k
INITIAL OUTFLOW
Mechanical characteristics
SIZE Ø32 x 70mm
WEIGHT 0,08 kg
MATERIAL Solid aluminium
General characreristics
OPERATING - 20°c ~+ 60°
TEMPERATURE
PROTECTION RAITING IP68
RESISTANCE INDEX IK08
A / A+ / A++
ENERGY CLASS
APPLICANCE CLASS CLASS III
WALKOVER FIXTURE NO
DRIVE-OVER FIXTURE NO
POWER SUPPLY Supply wire 2x0.5mm²
CABLES in IP68
PHOTOBIOLOGICAL Risk group I
SAFETY
