User instructions
EN
CDPE 6320
CDPE 6320 S
DISHWASHER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CDPE 6320 S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Candy CDPE 6320 S

  • Page 1 User instructions CDPE 6320 CDPE 6320 S DISHWASHER...
  • Page 3 Congratulations! CUSTOMER SERVICE AND GUARANTEE Thank you for choosing a Candy Your new appliance is fully guaranteed appliance; quality dishwashers which by the manufacturer for 12 months guarantee high performance and against electrical/mechanical break- reliability. down excluding: Candy manufacture a vast range of domestic appliances: washing A.
  • Page 4: Table Of Contents

    CONTENTS Safety advice pag. Setting up, installation pag. Water softener unit pag. Loading the salt pag. Adjusting the upper basket pag. Loading the dishes pag. Information for test laboratories pag. Loading the detergent pag. Types of detergent pag. Loading the rinse aid pag.
  • Page 5 SAFETY INSTRUCTIONS The door should not be left in the open position since this could present a potential hazard ( es. tripping ). There are certain basic safety rules which are valid for any domestic Leaning or sitting on the open door of appliance.
  • Page 6 INSTALLATION (Technical notes) After unpacking, adjust the height of the dishwasher. For the dishwasher to work correctly it must be level. Adjust the feet so that the machine does not tilt by more than 2 degrees. If it you need to move the machine after removing the packaging, do not try to lift it by the bottom of the door.
  • Page 7 Water connection IMPORTANT The appliance must be connected to the water mains using new hose-sets. The old hose-sets should not be reused. The inlet and drain hoses can be directed to left or right. IMPORTANT The dishwasher can be connected to either cold or hot water, as long as it is no hotter than 60 °C.
  • Page 8 The hose can be hooked over the side of Connecting the outlet hose the sink, but it must not be immersed in water, in order to prevent water from being syphoned back to the machine The outlet hose should disharge into a when this is in operation (fig.
  • Page 9 INSTALLATION IN FITTED Underneath existing work top KITCHENS (when fitting beneath a work top) Fitting between existing cabinets In most modern fitted kitchens there is only one single work top under which cabinets and electrical appliances are The height of the dishwasher, 85 cm, has fitted.
  • Page 10: Water Softener Unit

    WATER SOFTENER UNIT * The water softener unit is set in the factory at level 3, as this is suitable for the majority of users. Depending on the source of the supply, water contains varying amounts of limestone and minerals which are deposited on the According to the degree of hardness of dishes leaving whitish stains and marks.
  • Page 11: Loading The Salt

    LOADING THE SALT IMPORTANT (Only for first start up) When the appliance is used for the On the bottom of the machine there is a first time, after completely filling the container for the salt for regenerating salt container, it is necessary to add the softener.
  • Page 12 ADJUSTMENT OF THE UPPER BASKET If 27 cm to 31 cm plates are normally used, load them onto the lower basket after the upper basket has been placed in its upper position and proceed as detailed below: 1. Turn the front stops “A” outwards; 2.
  • Page 13: Loading The Dishes

    LOADING DISHES A standard daily load is represented in figs. 1, 2 and 3. Using the upper basket Upper basket (fig. 1) A = soup plates B = dinner plates C = dessert plates The upper basket is provided with D = saucers mobile racks hooked to the sides of the E = cups...
  • Page 14 Upper basket (fig. 3) A standard daily load is represented in figs. 4 and 5. A = glasses B = saucers C = cups Lower basket (fig. 4) D = small bowl A = medium-sized saucepan E = medium bowl B = large saucepan F = large bowl C = frying pan...
  • Page 15: Information For Test Laboratories

    INFORMATION FOR THE TEST LABORATORIES Please ask information required for comparison testing and measuring noise levels, according to EN normative, to the following address: testinfo-dishwasher@candy.it In the request, please specify model name and number of the dishwasher (see rating plate).
  • Page 16: Loading The Detergent

    LOADING THE DETERGENT The detergent IMPORTANT It is essential to use a detergent that is specifically designed for dishwashers either in powder, liquid or tablet form. After pouring the detergent into the container, close the lid, firstly pushing (1) and then “FINISH”...
  • Page 17: Types Of Detergent

    TYPES OF DETERGENT the effectiveness of detergents containing the built in water softener/salt depends on the hardness of your water supply. Detergent tablets Check that the hardness of your water supply is within the effective range given Detergent tablets of different manufacturers on the detergent packaging.
  • Page 18: Loading The Rinse Aid

    LOADING THE RINSE AID The rinse aid The rinse aid, which is automatically released during the last rinsing cycle, helps the dishes to dry quickly and prevents spots and stains forming. Filling the rinse aid container The rinse aid container can be found to the left of the detergent container (fig.
  • Page 19: Cleaning The Filters

    CLEANING THE FILTERS The filter system (fig.A “4”) consists of: a central container that traps the larger particles; a flat gauze that continuously filters the wash water; a micro filter, located beneath the gauze, that traps the tiniest particles ensuring a perfect rinse.
  • Page 20 PRATICAL HINTS How to make savings How to get really good wash If you want the dishwasher to give a complete wash, place the dishes in the results dishwasher at the end of each meal and if necessary turn on the COLD RINSE Before placing the dishes in the cycle to soften the food remains and dishwasher, remove any remaining...
  • Page 21 CLEANING AND MAINTENANCE To clean the dishwasher outside, do not use solvents (degreasing action) neither abrasives, but only a cloth soaked with water. The dishwasher does not require special maintenance, because the tank is self-cleaning. Regularly wipe the door gasket with a damp cloth to remove any food remains or rinse aid.
  • Page 22: Description Of The Control Panel

    DESCRIPTION OF THE CONTROL PANEL "ON/OFF" button "PROGRAMME SELECTION" lights "PROGRAMME SELECTION" button "SALT EMPTY" light "DELAY START" button "PROGRAMME STATUS" lights/ "DELAY START" time lights "START"/"RESET" button (start/cancelling programme) "EXPRESS" light "EXPRESS" button Programme guide DIMENSIONS: without working top with working top Height Depth...
  • Page 23: Programme Selection And Special Functions

    PROGRAMME SELECTION If you wish, press the "EXPRESS" button. AND SPECIAL FUNCTIONS (Use in conjunction with programme guide) Press the "START" button (the selected IMPORTANT programme indicator light will stop The dishwasher has two very practical flashing and remain on. functions: the "recommended"...
  • Page 24 "DELAY START" button Changing a running programme The dishwasher start time can be set with Proceed as follows to change or cancel a this button, delaying the start by 3, 6 or 9 running program: hours. Proceed as follows to set a delayed start: Hold the "RESET"...
  • Page 25 Alarm mute for the PROGRAMME Fault signals If malfunctions or faults occur when a The alarm for the programme end may be programme is running the indicator light muted as follows: that corresponds to the selected cycle will flash rapidly and the alarm sounds. IMPORTANT In this event, turn the dishwasher off by The dishwasher must be ALWAYS off...
  • Page 26: Programme Guide

    PROGRAMME GUIDE Programme Description Once a day - for heavily soiled pans and any other Intensive 75°C items that have been left all day for washing. Intended for rapid washing of very dirty dishes. Strong & Fast 65°C (“RECOMMENDED” PROGRAMME) Universal 60°C Once a day - for normal soiled pans and any other items that have been left all day for washing.
  • Page 27 Special function Avarage Check list Programme contents duration in buttons minutes available • • • • • 75°C • • • • • 65°C • • • • 60°C • • • • 55°C • • • • • 45°C •...
  • Page 28: Identifying Minor Faults

    IDENTIFYING MINOR FAULTS Should the dishwasher fail to operate, before contacting the Service Centre, make the following checks: FAULT CAUSE REMEDY Plug is not connected to wall Connect electric plug socket O/I button has not been pressed Press button 1 - Machine completely dead Door is open Close door No electricity...
  • Page 29 FAULT CAUSE REMEDY See causes for no. 5 Check Bottom of saucepans have not Burnt on food remains must been washed well be soaked before putting pans in dishwasher Edge of saucepans have not Reposition saucepans been washed well Spray arms are partially blocked Remove spray arms by unscrewing ring nuts clockwise and wash under running water...
  • Page 31 The manufacturer declines all responsibility in the event of any printing mistakes in this booklet. The manufacturer also reserves the right to make appropriate modifications to its products without changing the essential characteristics.
  • Page 32 This appliance is marked according to the European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE). By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this pro- duct.
