Gas Analysis
Sample Gas Filter AGF-VA-350
Sample Gas Coalescing Filter K-AGF-VA-350
Installation and Operation Instructions
Original instructions
BE410013
Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen
06/2019
Tel. +49 (0) 21 02 / 49 89-0, Fax: +49 (0) 21 02 / 49 89-20
E-Mail: analyse@buehler-technologies.com
Internet: www.buehler-technologies.com
Advertisement
Table of Contents
Related Manuals for Bühler technologies AGF-VA-350
Summary of Contents for Bühler technologies AGF-VA-350
- Page 1 Gas Analysis Sample Gas Filter AGF-VA-350 Sample Gas Coalescing Filter K-AGF-VA-350 Installation and Operation Instructions Original instructions BE410013 Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen 06/2019 Tel. +49 (0) 21 02 / 49 89-0, Fax: +49 (0) 21 02 / 49 89-20 E-Mail: analyse@buehler-technologies.com...
- Page 2 Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen Tel. +49 (0) 21 02 / 49 89-0, Fax: +49 (0) 21 02 / 49 89-20 Internet: www.buehler-technologies.com E-Mail: analyse@buehler-technologies.com Read this instruction carefully prior to installation and/or use. Pay at- tention particularly to all advises and safety instructions to prevent in- juries.
-
Page 3: Table Of Contents
8.1.2 K-AGF-VA-350 ...................................... 12 9 Disposal ............................................ 13 10 Appendices ............................................. 14 10.1 Technical Data AGF-VA-350 / K-AGF-VA-350 ............................. 14 10.2 Dimensions AGF-VA-350 / K-AGF-VA-350 .............................. 14 10.3 List of chemical resistance .................................... 15 11 Attached documents ........................................ 16 BE410013 ◦ 06/2019... -
Page 4: Introduction
The filters may be used in a gas analysis system to filter sample gas. Filters AGF-VA-350 and K-AGF-VA-350 may further be used in explosive atmosphere areas zone 1 and 2, explosion class IIA, IIB and IIC. When used for this purpose, the information in chapter “Use in explosive atmosphere areas“ must be followed in addition to the other information in these operating instructions. -
Page 5: Safety Instructions
Sample Gas Coalescing Filter K-AGF- VA-350 2 Safety instructions 2.1 Important notices Operation of the device is only valid if: – the product is used under the conditions described in the installation- and operation instruction, the intended application according to the type plate and the intended use. In case of unauthorized modifications done by the user Bühler Technolo- gies GmbH can not be held responsible for any damage, –... - Page 6 Sample Gas Coalescing Filter K-AGF- VA-350 Maintenance, Repair Please note during maintenance and repairs: – Repairs to the unit must be performed by Bühler authorised personnel. – Only perform conversion-, maintenance or installation work described in these operating and installation instructions. –...
-
Page 7: Use In Explosive Atmosphere Areas
Intended Use Filters K-AGF-VA-350 and AGF-VA-350 may be used in explosive atmosphere areas zone 1 and 2. Explosion classes IIA, IIB and IIC are approved. The filter has no innate ignition source and does not fall under Directive 2014/34/EU and therefore does not bear the CE mark. - Page 8 Sample Gas Coalescing Filter K-AGF- VA-350 Service schedule When using the filters in ATEX areas, follow this maintenance schedule: Component Interval in operating hours Work to be performed Filter element Weekly, and depending on the contamination – Visually inspect for contamination. level of the filter element.
-
Page 9: Transport And Storage
Sample Gas Coalescing Filter K-AGF- VA-350 4 Transport and storage Only transport the product inside the original packaging or a suitable alternative. The equipment must be protected from moisture and heat when not in use. It must be stored in a covered, dry and dust-free room at a temperature of -20 °C to 60 °C (-4 °F to 140 °F). -
Page 10: Installation And Connection
The spacing for the mounting holes (for M6 screws) is 25 mm. The maximum permissible pressure is 270 bar abs. at temperatures up to 150 °C for models (K-) AGF-VA-350-T, or 200 bar abs. at temperatures up to 240 °C for model AGF-VA-350-P. -
Page 11: Operation And Control
Sample Gas Coalescing Filter K-AGF- VA-350 6 Operation and control NOTICE The device must not be operated beyond its specifications. BE410013 ◦ 06/2019 Bühler Technologies GmbH... -
Page 12: Maintenance
Sample Gas Coalescing Filter K-AGF- VA-350 7 Maintenance During maintenance, remember: – The equipment must be maintained by a professional familiar with the safety requirements and risks. – Only perform maintenance work described in these operating and installation instructions. – When performing maintenance of any type, observe the respective safety and operation regulations. –... -
Page 13: Service And Repair
Available spare parts: 8.1.1 AGF-VA-350 Filter Item no. Model Material 41 35 999 AGF-VA-350-T, empty housing 1.4404 (SS316L), Viton gasket, FEP shrouded 41 35 999 001 AGF-VA-350-P, empty housing 1.4404 (SS316L), FFKM gasket Attention: suitable for max. 200 bar, 240 °C 41 35 9993 Mounting bracket 1.4301 (SS 304) -
Page 14: K-Agf-Va-350
Sample Gas Coalescing Filter K-AGF- VA-350 8.1.2 K-AGF-VA-350 Filter Item No. Model Material 41 35 099 K-AGF-VA-350-T, empty housing 1.4404 (SS 316L), Viton gasket, FEP shrouded 41 35 9993 Mounting bracket 1.4301 (SS 304) 90 08 802 Plug NPT 1/4 1.4401 (SS 316) -
Page 15: Disposal
Sample Gas Coalescing Filter K-AGF- VA-350 9 Disposal The applicable national laws must be observed when disposing of the products. Disposal must not result in a danger to health and environment. The crossed out wheelie bin symbol on Bühler Technologies GmbH electrical and electronic products indicates special disposal notices within the European Union (EU). -
Page 16: Appendices
Sample Gas Coalescing Filter K-AGF- VA-350 10 Appendices 10.1 Technical Data AGF-VA-350 / K-AGF-VA-350 Filter Dead volume with filter element 18 ml Material - filter housing 1.4404 (SS 316L) Material - gasket Viton FEP shrouded Material - filter element see table Weight approx. -
Page 17: List Of Chemical Resistance
Sample Gas Coalescing Filter K-AGF- VA-350 10.3 List of chemical resistance Formula Substance Concentration Teflon® PVDF Viton® PTFE COCH Acetone Benzene Chlorine 10 % wet Chlorine 97 % Ethane Ethanol 50 % Ethene Ethylbenzene Hydrofluoric acid Carbon dioxide Carbon monoxide Methane technically pure Methanol... -
Page 18: Attached Documents
Sample Gas Coalescing Filter K-AGF- VA-350 11 Attached documents – Declaration of Conformity HX410011 – RMA - Decontamination Statement Bühler Technologies GmbH BE410013 ◦ 06/2019... - Page 21 RMA-Formular und Erklärung über Dekontaminierung RMA-Form and explanation for decontamination RMA-Nr./ RMA-No. Die RMA-Nr. bekommen Sie von Ihrem Ansprechpartner im Vertrieb oder Service. Bei Rücksendung eines Altgeräts zur Entsorgung tragen Sie bitte in das Feld der RMA-Nr. "WEEE" ein./ You may obtain the RMA number from your sales or ser- vice representative.
- Page 22 Dekontaminierungserklärung DE000011 Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen 12/2022 Tel. +49 (0) 21 02 / 49 89-0, Fax: +49 (0) 21 02 / 49 89-20 E-Mail: service@buehler-technologies.com Internet: www.buehler-technologies.com...
