SHO-ME 12.5063 Manual

General Information:

The Luminator LED Trio Light is equipped with an internal flasher. It comes from the factory in a random flash mode.

Wiring Instructions:

When wiring, Always connect ground wire first and power wire last.

Flash Pattern Selection:

To change flash patterns, momentarily apply +12v to the Yellow "Sync-Mode" Wire for less than 5 seconds.
To reset to factory default pattern, apply +12v to the Yellow "Sync-Mode" Wire for more than 5 seconds.*
When changing flash patterns, you may have to re-start before patterns will sychronize.
Do Not ground YELLOW Wire.*
1.
2.
3.
4.
5.

Synchronization:

Connect all yellow wires together to synchronize. When wired as shown, the Luminator LED Trio Lights will be
synchronized.

Group Selection:

The White "Group Selection" Wire will determine which lights flash at the same time when you have 2 or more lights.
For Group 1, connect White "Group Selection" wire with Red Power wire.
For Group 2, DO NOT connect White "Group Selection" wire to anything.
Group 1 & Group 2 will alternate.
*Do Not use White wire if using only one light.*

Product Specifications:

Optimum Operation Voltage:
Operating Current:
Recommended Fuse:
Luminator LED Trio Light Kit
Model 12.5063
Flash Patterns
Single Flash - 134 FPM
Double Flash - 268 FPM
Quad Flash - 536 FPM
Super Flash - 1070 FPM
Single-On - 134 FPM
+13.8 VDC
.75-1.5 amps
5 amp
Quad-On 536 FPM
6.
7. Triple Flash - 401 FPM
Hyper Flash - 1873 FPM
8.
9. Steady
10. Random 1-8 (Default)
09-10-08
