SHO-ME 09.201LED Instructions

Before using, place light in charger so the contacts on the light will match up with the contacts on the
charger. When the green LED light is glowing, the battery is fully charged. If the red light is glowing, the
battery is being charged. (Red and green LED lights are located on the rechargeable light on the left-hand
side of the handle.).
Your new SHO-ME LED Rechargeable has both "Flood" and "Spot" capabilities. By moving the two way
®
toggle switch to the right you activate the High Intensity 5 Watt LED for the Spot Function. This function is
used for shining long distances. When the two way switch is moved to the left the "Flood" function is
activated. This function is for working in a close area, when you need to light up a wide area.
The "Flood" function will run for an estimated time of 50 hrs, before requiring a recharge. The "Spot"
function will run for an estimated time of 5 hrs before needing to be recharged. Although your NEW LED
Rechargeable is capable of going for long periods of time without being recharged, it is recommended that
you leave it on the charger when not in use.
Your new SHO-ME rechargeable light is protected by a charging regulator, therefore it cannot
®
be overcharged. When not in use, leave light in the charger so it will always be charged.
The SHO-ME rechargeable light should be mounted and charged with the bulb pointed up
®
NOTE: The battery used in your new SHO-ME rechargeable light is lead-acid battery. This is not a
memory type battery and DOES NOT require being fully discharged. The battery can be recharged
hundreds of times, depending on the depth of discharge.
keep your rechargeable light in the charger and avoid running the light till the battery
is completely dead.
NUMBER
OF
CYCLES
Number of discharge cycles at various depths of discharge to reach 60% of original life.
PERCENT OF
CAPACITY
RETURNED
SHO-ME
MODEL NO. 09.201LED
Rechargeable Light W/Wall-Mount Charger
INSTRUCTIONS
1400
1200
1000
800
600
400
200
0
10% 30%
PERCENT OF DISCHARGE
110%
100%
90%
80%
70%
60%
50%
40%
30%
20%
10%
0%
0 1 2
®
®
For prolonged battery life, always
50%
70% 90%
110%
3 4 5 6 7 8 9
HOURS ON CHARGE
10 11 12
07-29-10
