- Page 1 Installation Manual Beverage Dispenser ™ Smartwell Countertop Beverage Dispenser with Remote Chiller Model - SW1806CR Read the instructions in this manual and retain for future reference. WARNING...
-
Page 2: Table Of Contents
Installation ......... 6 ELKAY Smartwell Documents..... . 2 What`s in the Box . -
Page 3: Disclaimer
Wear protective cut resistant gloves during by Elkay is used, you must be satisfied that it is safe for yourself and installation to protect against sharp edges others. You should also make sure that the product will not be damaged from sheet metal components. -
Page 4: Key Components
Switch Still water inlet Sparkling water inlet Smartwell power switch and circuit breaker reset Note: Sparkling water inlet is labeled as "CO port" on the back of the unit Elkay Manufacturing Company Countertop Installation Manual (2000000029 Rev. A - 04/21) -
Page 5: Installation Preparation
DO NOT allow the unit to freeze. DO NOT place the unit near a NOTICE 1. Elkay recommends a water pressure of 40 to 105 psi on our cooler source of heat. products. A pressure regulator provided in the install kit reduces the... -
Page 6: Installation
2. Unbox the Cabinet, inspect to ensure no shipping damage, then place upright on the floor in desired location for the Smartwell. Remote Chiller Lifting Hazard Use two people to carefully lift the Countertop dispenser unit. Elkay Manufacturing Company Countertop Installation Manual (2000000029 Rev. A - 04/21) - Page 7 2 screws available inside the Cabinet. Note: Tighten the 2 screws after hanging the filter head assembly. 3/8" water tubing Screw Filter Head Assembly Shut-off Valve Pressure Regulator Elkay Manufacturing Company Installation Manual (2000000029 Rev. A - 04/21) Countertop...
- Page 8 Cabinet. a. Place the CO tank inside the Cabinet in location shown. b. Use the sling to tighten the CO tank in position. Look inside the cabinet Elkay Manufacturing Company Countertop Installation Manual (2000000029 Rev. A - 04/21)
-
Page 9: Connecting The Filter And Remote Chiller
Remove the plug from the fi ll port of the ice bank. Insert the 3/8” water line from a water supply source into the ice bank Inlet connection. Shut-off valve Potable water source Remote Chiller Filter Pressure Regulator Elkay Manufacturing Company Installation Manual (2000000029 Rev. A - 04/21) Countertop... -
Page 10: Internet
3. Attach the power cord and plug directly into a wall Remote Chiller power outlet. Note: Sparkling water inlet is labeled as "CO port" on the back of the unit Elkay Manufacturing Company Countertop Installation Manual (2000000029 Rev. A - 04/21) -
Page 11: Startup Instructions
If Wi-Fi connection is selected, the Wi-Fi Netgear been fl ipped to ON, a loading screen followed by the screen will open. Please follow the manufacturers Welcome screen will appear. directions to set up. Elkay Manufacturing Company Installation Manual (2000000029 Rev. A - 04/21) Countertop... -
Page 12: Pouches
Save. — The right-hand screen will appear if the unit is connected to the Internet. Select the appropriate time zone settings, then press Save. Elkay Manufacturing Company Countertop Installation Manual (2000000029 Rev. A - 04/21) - Page 13 Select either the 5, 10, 15, 20 lb. tank capacity contamination. being installed. Enhancement Pouch Pump Manifold Elkay Manufacturing Company Installation Manual (2000000029 Rev. A - 04/21) Countertop...
-
Page 14: Set The Water Flow Parameters
Sign In screen. Enter 0101 and push the Sign In button. 10. The Elkay Smartwell customer portal should now be accessible if the unit is connected to the Internet. Login and confi rm the unit appears in the listing page. -
Page 15: Unit Diagnostics
Elkay smartwell touchless screen will appear. 4) Repeat this process for the Sparkling Water Accept the Terms and Conditions. Press submit. Flow entry. The sparkling water will dispense a greater volume in 10 seconds. 5) Press Done once complete. -
Page 16: Check For Updates
END OF DOCUMENT FOR PARTS, CONTACT YOUR LOCAL DISTRIBUTOR OR CALL 1.800.834.4816 REPAIR SERVICE INFORMATION TOLL FREE NUMBER 1.800.260.6640 ELKAY MANUFACTURING COMPANY • 1333 BUTTERFIELD ROAD SUITE 200 DOWNERS GROVE, IL 60515 • 630.574.8484 • www.elkay.com Elkay Manufacturing Company Countertop...
