How to Replace Flavor & Enhancement Pouches
1.
Unlock and open the hood of the machine. Locate the pouches that need to be replaced.
Disconnect the pouch from the dispenser.
2.
A.
Unlock the silver
pump clamp by
gently sliding it up.
B.
Gently pull out
the white pump
and set aside.
3.
Dispose of empty pouch(es). Wash hands thoroughly with warm water and soap to
sanitize.
4.
Connect the pouch to the dispenser
A.
Hang the pouch in
the hanger slot.
Pro tip: Place the
Citric Acid and
Natural Sweetener
pouches in hanger
slots 4 & 5.
B.
Unlock the silver
pump clamp by
gently pushing it up.
C.
Pull out the nib from the
dispensing manifold.
D.
Lastly unhook
the pouch from
the hanger slot.
C.
Align the white pump
with the starburst
pattern and press firmly
into place. Release the
clamp, making sure it
slides over the top of
the pump starburst
completely so the pump
is securely fastened.
D. Push in the nib into the
dispensing manifold.
