Accedian Skylight LX Hardware Installation Manual

Skylight LX™
HARDWARE INSTALLATION GUIDE
423-044-00, Revision 5
Published: 2023-02-08
Compliance Statements
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the
interference at his own expense.
VCCI–A
この装置は、クラスA情報技術装置です。この装置を家庭環境で使用すると
電波妨害を引き起こすことがあります。この場合には使用者が適切な対策を
講ずるよう要求されることがあります。
KCC-A
사용자 안내문
이 기기는 업무용 환경에서 사용할 목적으로 적합성평가를 받은 기기로서
가정용 환경에서 사용하는 경우 전파간섭의 우려가 있습니다.
Conventions
Attention: This product, like all electronic products, uses semiconductors that
can be damaged by electrostatic discharge (ESD). Always observe appropriate
precautions when handling.
Warning: Potential for damage to equipment or personal injury.
Attention: This symbol indicates that the surface is hot and to use caution to avoid
touching it.
Protective grounding point
Special considerations
Package Contents
Basic Contents
– Skylight LX Performance (1)
– Rubber feet (4)
– This Hardware Installation Guide (1)
Note: Package can contain other ordering options. See ordering guide for more details.
Specifications
Power
Input Power Rating 20-57V , 3.0-1.1A
DC Max
Output Power Rating SFP+: 2.5W Per Port
Max
SFP: 2.0W Per Port
Max
Transceivers used in the ports must
stay within their specifications under all
operating conditions of the system.
Power Consumption 40W , 55W
Nom Max
(136 BTU/hr , 188 BTU/hr
Nom
Physical
Dimensions (W x H x D) 201 x 38 x 264mm (7.9 x 1.5 x 10.4")
Weight 1.7kg (3.7lb)
Environmental
Operating Temperature Commercial: 0°C to +50°C (32°F to 122°F)
Hardened: -40°C to 65°C (-40°F to 149°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Humidity 5% to 85% RH, Non Condensing
Storage Humidity 5% to 95% RH, Non Condensing
Maximum Altitude 2000 m (6600 ft), Above Sea Level
Regulation & Standard Compliance (Model: NODE2c)
Safety IEC 60950-1, IEC 62368-1, EN 62368-1, CSA/UL
62368-1, AS/NZS 62368.1, J62368-1, CEI EN 62368-1,
DS/EN 62368-1
EMC - Emission (Class A) CISPR 32, EN 55032, FCC 47 CFR Part 15 Subpart B,
ICES-003, AS/NZS CISPR 32, VCCI-CISPR 32, KN32
EMC - Immunity EN 55035, KN35
Telco NEBS Level-3: GR-63, GR-1089
Enviro RoHS: IEC 63000, EN IEC 63000
)
Max
