TR Comfortline II Operating Manual

Height adjustable & fixed height bathtubs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TR Comfortline II / TR Ecoline II
Height adjustable & fixed height
bathtubs
Operating manual
Version 2021-04-26
Always study this manual carefully before you
attempt to operate your bathing system. The
operator/user must always have access to the
operating manual.
This bathing system is intended for professional use
only where the patient will be under supervision of
trained personnel.
Operating instructions and recommended
maintenance procedures are explained in the
following pages.
Mandatory to read the manual before using the bathtub.
Registered at Medical Products Agency,
Sweden as an MDR Class 1 product
according to MDR 2017/745.
TR reserves the right to make design
changes and/or improvements without
notice.
If you have any questions regarding the operation or
maintenance of your bathing system and cannot find
the answer in this manual, please contact us.
The system is designed for years of trouble-free
operation, with proper use and maintenance.
Bathtub and shower water must be run at least every
three days.
1
Hygiene Equipment
Designed for People

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Comfortline II and is the answer not in the manual?

Questions and answers

Related Manuals for TR Comfortline II

Summary of Contents for TR Comfortline II

  • Page 1 Hygiene Equipment TR Comfortline II / TR Ecoline II Designed for People Height adjustable & fixed height bathtubs Operating manual Version 2021-04-26 Registered at Medical Products Agency, Sweden as an MDR Class 1 product according to MDR 2017/745. TR reserves the right to make design changes and/or improvements without notice.

  • Page 2: Table Of Contents

    Hygiene Equipment Designed for People Table of contents Manufacturer Page 3 Introduction Page 4 Unpacking Page 5 Installation Page 6 Initialization/Calibration Page 12 Intended use Page 13 Safety Instructions Page 14 Features and controls Page 16 Product description Page 17 Configurations Page 18 Technical specification...

  • Page 3: Manufacturer

    Hygiene Equipment Designed for People Manufacturer TR Equipment AB Rundelgatan 2 SE-573 35 Tranås Sweden www.trequipment.com info@trequipment.se Phone: +46 (0)140 38 50 60 Group subsidiaries: TR Group Inc. Phone: +1 (800) 7526900 United Kingdom: TR Equipment Ltd Phone: +44 (0) 84433558386...

  • Page 4: Introduction

    Introduction Dear Customer, Thank you for choosing one of our quality products. We hope you enjoy the TR Comfortline II height adjustable bathtub or your TR Ecoline II fixed height bathtub. This manual shall, in conjunction with staff training, ensure that the operator/user is always using and/or operating the Comfortline correctly.

  • Page 5: Unpacking

    Hygiene Equipment Designed for People Unpacking When you receive a bathtub from us it´s placed on a pallet surrounded by a cardboard crate. If the cardboard box is wrapped in plastic carefully cut and remove the plastic. Start unpacking the bathtub by removing the lower carton staples with a pliers. DO NOT use any sharp tools that may scratch the bathtub.

  • Page 6: Installation

    Designed for People Installation instructions The TR Comfortline II bathtub and TR Ecoline are delivered fully assembled, ready to be connected to water and power supply at the customer’s premises and must be installed according to local guidelines and regulations.
  • Page 7 Hygiene Equipment Designed for People Installation instructions 8. Carry out a Scalding safety function test: Start filling the tub with water, shut OFF the cold-water supply to the thermostatic mixer. Within 2 seconds the thermostatic mixer shall be shut OFF. If the thermostatic mixer continues to supply only HOT water the thermostatic mixer needs to be replaced.
  • Page 8 Hygiene Equipment Designed for People Installation instructions Height adjustable bathtub, TR Comfortline...
  • Page 9 Hygiene Equipment Designed for People Installation instructions Fixed height bathtub, TR Ecoline...
  • Page 10 Hygiene Equipment Designed for People Installation instructions Assembly of the cleaning system Valve: Assemble the valve stem (1) by screwing it into the left female threaded coupling No.1 on the bath tub. Screw on the protective sleeve (2) onto the valve stem (1). Push on the chromed ring (3) over the protective sleeve (2).
  • Page 11 Hygiene Equipment Designed for People Installation instructions Assembly of the cleaning system The cleaning hand shower holder: Assemble the 90° elbow (1) by screwing it into the right female threaded coupling No.2 on the bathtub. Seal with sealing tape. Mount the hand shower holder (2) over the 90° elbow (1) and fasten it with the supplied screw. Finally, screw the pipe interrupter (3) onto the 90°...

  • Page 12: Initialization/Calibration

    Hygiene Equipment Designed for People Initialization/Calibration An initialization/Calibration should be carried out on the height adjustable TR Comfortline: The very first time the bath is started up After power failure If the power has been disconnected from the mains supply.

  • Page 13: Intended Use

    Intended use The TR Comfortline and TR Ecoline are intended for bathing and showering patients. The TR Comfortline and TR Ecoline is only intended to be used for short term use <60min when in contact with breached or compromised skin.

  • Page 14: Safety Instructions

    (Ground Fault Circuit Interrupter) including an easily accessible switch near the bathtub. Even if you have chosen TR Equipment AB or a TR Equipment distributor to install the bathtub, the Cold and Hot water supply and Electrical wiring is the responsibility of the buyer. All electrical wiring...
  • Page 15 Hygiene Equipment Designed for People Safety instructions Note: In case of a serious incident when using the TR Comfortline, this should be reported to the manufacturer and to the local authorities where you are established. TR Equipment AB Rundelgatan 2 SE-573 35 Tranås...

  • Page 16: Features And Controls

    Yellow cleaning hose Hand control, TR Comfortline Shower handle for cleaning hose Overflow drainage, control to open and close drain plug *Available for TR Comfortline height Drainage hose adjustable bathtub only **Available for both height adjustable and Ecoline fixed height bathtub.

  • Page 17: Product Description

    Designed for People Product description The TR Comfortline can be delivered as a height adjustable bathtub that can be raised and lowered to infinite positions within the height range, or as a fixed height bathtub with three optional fixed heights.

  • Page 18: Configurations

    10 years if the bathtub is serviced and maintained according to instructions in this manual. Possible equipment combinations TR Comfortline II height adjustable / TR Ecoline II fixed height TR9650 – Chair lift TR Comfortline II height adjustable / TR Ecoline II fixed height...

  • Page 19: Technical Specification

    Hygiene Equipment Designed for People Technical specification Comfortline II, height adjustable bathtub supplied with Grotherm 800 thermostatic mixer Input Voltage 1-Phase 230VAC/50Hz or 110VAC/60Hz, Control voltage 24V DC Service life Lifting columns 20.000 strokes / 10 years Maximum load Patient weight shall not exceed 150Kg Water volume 180L / 48 gallons excl.
  • Page 20 Hygiene Equipment Designed for People Technical specification Comfortline II, height adjustable bathtub supplied with Grotherm 800 thermostatic mixer Filling time up to overflow drainage. 10 minutes (at 5 bar pressure) Emptying time 4 ½ minutes Filling time Autofill (option): To Autofill level 1 (at 5bar pressure)
  • Page 21 Hygiene Equipment Designed for People Technical specification TR Ecoline II, fixed height bathtub supplied with Grotherm 800 thermostatic mixer Input Voltage, only if the tub is equipped 1-Phase 230VAC/50Hz or 110VAC/60Hz with options Control voltage 24V DC Maximum load Patient weight shall not exceed 150Kg Water volume 180L / 48 gallons excl.

  • Page 22: User Instructions

    Hygiene Equipment Designed for People User instructions Fill the bathtub with water: Turn the overflow valve to close the drain plug. Start filling the tub with water by turning the OPEN and CLOSE knob on the thermostatic mixer. Adjust the outlet water temperature by turning the temperature knob on the thermostatic mixer.

  • Page 23: How To Enter And Step Out Of The Bath

    Hygiene Equipment Designed for People User instructions Enter and leave the bath: If the patient enters the bath themselves with assistance from caregiver: Lower the tub to the lowest position with the hand control allowing the patient to enter the bath with assistance.

  • Page 24: Foot Support

    Hygiene Equipment Designed for People User instructions Foot support: The foot support can be placed in three different positions for best foot support. If the patient is placed on a stretcher lift or on a combi lift with side parts during the bath the foot support must be removed from the tub before the lift is lowered into the water.

  • Page 25: Showering

    Hygiene Equipment Designed for People User instructions Showering: The shower handle is used to shower the patient and to rinse equipment after cleaning. Hold the shower handle over the tub and pull the diverter knob on the thermostatic mixer to start the shower. Always check the water temperature by hand before using the shower on the patient to prevent patients from being scalded or shocked by cold/hot water.

  • Page 26: Option, Cleaning System

    Hygiene Equipment Designed for People User instructions Cleaning system (only available for TR Comfortline, height adjustable bathtub): The cleaning system is automatically mixed with cold water in a pre-set concentration of approximately 2% to minimize inhalation. Use only liquid, non-abrasive, non-scouring, commercially available detergents to clean the bathtub, controls and foot support.
  • Page 27 Hygiene Equipment Designed for People User instructions Air-Spa (only available for TR Comfortline, height adjustable bathtub): Air Spa system – Genesis (Option) From 2018-02-23 and forward. Serial no: 1802-204609. Note: The operating time is restricted for safety reasons. The Air spa system switches OFF automatically after 30 minutes.
  • Page 28 Designed for People User instructions Cleaning the Air Spa system The Genesis Air Spa system on the TR Comfortline Utilizes a blower that generates air bubbles through Small air jets in the bottom of the bathtub. The air jet has a integrated backflow prevention (stainless-steel ball).

  • Page 29: Option, Led Light

    Hygiene Equipment Designed for People User instructions LED light (Available for bot TR Comfortline, height adjustable bathtub and TR Ecoline, fixed height bathtub). LED Color Light System (option), from 2018-02-23 and forward. Serial no: 1802-204580 Use: The light system touch control is located either at the head end (on the side of the tub covers) or at the foot end (on the edge of the tub, depending on bathtub model).

  • Page 30: Option, Music System

    Hygiene Equipment Designed for People User instructions Music system (only available for TR Comfortline, height adjustable bathtub): From 2017-09-01 and forward, serial no: 1709-203870. Operating instructions Bluetooth: Press the ON/OFF button. Press the MODE button to choose Bluetooth. (Bluetooth indicator will be flashing) Turn on the Bluetooth on your music device.

  • Page 31: Option, Autofill

    Hygiene Equipment Designed for People User instructions Autofill (Available for bot TR Comfortline, height adjustable bathtub and TR Ecoline, fixed height bathtub). Autofill (option) From 2018-02-23 and forward. Serial no. 1802-204609. The Autofill allow staff to pick up and prepare the patient for bathing while the tub is being pre-filled.

  • Page 32: System Components

    Only company engineers and/or trained staff are authorized to carry out any work on the drive system (lifting columns and control box). Do not attempt work on the lifting columns without consulting TR Equipment as this will void the warranty. Thermostatic mixer See separate operating manual, supplied at delivery.

  • Page 33: Labels And Symbols

    Hygiene Equipment Designed for People Labels and symbols Product label TR Equipment logotype Medical equipment according to MDR 2017/745 CE marking Manufacturing date Factory address Part number Serial number Mandatory to read the operating manual before...
  • Page 34 Hygiene Equipment Designed for People Labels and symbols Maximum water pressure. Cold water. Maximum pressure and temperature. Hot water. Disinfection shower hose Disinfectant filling. Patient weight shall not exceed 150kg Alternate current 220-240V – 50/60Hz Protective earth Class I Alternate current 110-120V – 50/60Hz Protective earth Class I Applied part B...

  • Page 35: Routine Maintenance

    Clean the strainers on the shower handle by rubbing it with your thumb. If your Comfortline II is equipped with a cleaning system: Make sure there is cleaning liquid in the cleaning container. Clean the strainers on the cleaning shower handle by rubbing it with your thumb.
  • Page 36 Warning Scalding risk when flushing with hot water! Warning Shower hoses on the TR Comfortline bathtub manage 60°C /140°F for 10 minutes. Warning Maintenance and/or repairs may only be carried out by the manufacturer or qualified staff authorized by the manufacturer. Otherwise warranty expires immediately.
  • Page 37 Initialize/calibrate the lifting columns according to the instructions described in the Operating manual. See Initializing in the table of content. If your Comfortline II is equipped with cleaning system check the OPEN/CLOSE valve to see if it open and close the valve properly. Replace valve stem if necessary.
  • Page 38 Otherwise warranty expires immediately. If the thermostatic mixer is supplied by TR Equipment, it´s covered by warranty but problems related to the quality of the water is not covered by the warranty from TR Equipment.

  • Page 39: Cleaning Instructions

    Hygiene Equipment Designed for People Cleaning instructions Please note: The user/operator is responsible selecting the correct cleaning liquid/detergent and additives according to local regulations and safety standards. Please read the cleaning liquid/detergent supplier´s instruction manual and find out whether the product is suitable for use with this product. General guidelines for cleaning liquid/detergent: •...
  • Page 40 Hygiene Equipment Designed for People Training record Date: Participants: Signed by:...

  • Page 41: Maintenance Record

    Hygiene Equipment Designed for People Maintenance record Date: Comment: Signed by:...
