This product can expose you to chemicals including gasoline engine exhaust, which is known to the State of
California to cause cancer, and carbon monoxide, which is known to the State of California to cause birth defects or other reproductive
harm. For more information go to
Brute is a registered trademark of Briggs & Stratton
Corporation used under license.
Advertisement
Related Manuals for Brute BSG1221SB
Summary of Contents for Brute BSG1221SB
- Page 1 California to cause cancer, and carbon monoxide, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to Brute is a registered trademark of Briggs & Stratton Corporation used under license.
-
Page 2: Customer Service
Thank you for purchasing this superior quality lawn mower from Brute . When operating and ® maintaining this product as instructed in this manual, your lawn mower will give you many years of reliable service. The emissions control system for this lawn mower is compliant with all standards set by the U.S. Agency. - Page 3 Description of Product Parts………………………………………………………………………………………………3 Safety Information…………………………………..……………………………………………………………………... Assembly……………………………………………..…………………………………………………………………….. Adjustment …………………………………………..……………………………………………………………………..1 Operation……………………………………………..……………………………………………………………………..1 Storing and Maintenance…………………………..……………………………………………………………………...1 Troubleshooting ……………………………………..……………………………………………………………………...
- Page 4 Drive lever (clutch lever) Height adjusting handle Soft grip Rear wheel Upper handle Engine oil cap Brake lever /stop lever Side discharge cover Handle knob with square neck bolt Side discharge chute Lower handle Deck Grass bag Spark plug boot Fuel tank cap Pull start Primer...
- Page 5 Carefully remove the machine from its packaging and check that the following parts are complete: A. Main mower deck (with upper handle and lower handle) 1pc B. Cable clip 1pc C. Grass bag assembly D. Side discharge chute 1pc E. Manual 1pc F.
- Page 6 Please read these instructions fully before assembling and operating. Symbols are used in this manual to attract your attention to possible risks. The safety symbols and the explications which accompany them must be perfectly understood. The warning themselves do not prevent the risks and cannot be a substitute for proper methods of avoiding accidents.
- Page 7 protection, eye protection when operating. Hot surfaces will burn fingers or palms Warning! The lawnmower exhaust gas contains toxic substances . Do not run the engine in closed or poorly venti ated areas. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist.
- Page 8 1. Read the instructions carefully. Be familiar with the controls and the proper use of the equipment. 2. Never allow children or people unfamiliar with these instructions to use the lawnmower. Local regulations can restrict the age of the operator. 3.
- Page 9 11. Never operate the lawnmower with defective guards, or without safety devices, for example deflectors and/or grass catchers, in place. 12. Do not change the engine governor settings or over speed the engine. 13. Disengage all blade and drive clutches before starting the engine. 14.
- Page 10 Fig 3 As shown in Fig 3&4 Washer Bolt Knobs Fasten the lower handle to The device by using two b s and two small knobs on each side . Fig 4 Unfold the upper handle and fix it to lower handle By using the big knobs and the bo ts on each side NOTE! Bolt...
- Page 11 Fig 6 As shown in Fig 6 1. Pull the rope through the hook. 2. Insert the hook through the pre-drilled hole on the frame. 3. Secure the hook with the nut. As shown in Fig 7 Fig 7 1. Lift the rear discharge cover with one hand and hook in the grass bag .
- Page 12 As shown in Fig CAUTION! The cutting height is adjusted with a single lever. Different cutting heights can be selected. Pull the adjusting handle out and select the desired cutting height. The handle snaps into the desired position. From position 1 to position 7. CAUTION! For rear bagging ×...
- Page 13 WARNING! WARNING! NOTE! As shown in Fig . r e t l l t r a t S / v e l handle with one hand and place the other hand on the pull start. 2. Pull the pull start out approx. 4-6 inches until you feel a res t s i and then start the engine with a sharp pull.
- Page 14 r a t r e t the rope guide. As shown in Fig 12 Stopping The Engine As shown in Fig 13 Release the engine start/stop lever, it will return to its initial position, the engine will automatically switch off. To Clean A Flooded Engine NOTE! 1.
- Page 15 WARNING! WARNING! 1. Select your required setting. 2. Start the engine and allow it run, and set it to required speed. See “to start the engine”. 3. Keep a firm grip on the upper handle with engine stop/start lever and walk along with it to start mowing. NOTE! To take off the grass bag, use one hand to lift up ejector flap and the other to grab onto the carry handle.
- Page 16 WARNING! The lawn mower should be cleaned thoroughly every time after it has been used. Always clean your lawnmower immediately after use. Do not allow grass cuttings and other debris to become dry and hard on any of the mower surfaces. Dried grass remnants and dirt may impair the mowing operation.
- Page 17 For safety reasons you should have your blade sharpened, balanced and mounted by an authori ed service workshop. For optimum results it is recommended that the blade should be inspected once a year. WARNING! WARNING! NOTE! WARNING! WARNING! WARNING! NOTE! For safety reasons we recommend that the blade only be changed by someone qualified and authorized to do so.
- Page 18 The lawnmower can be stored for short periods of time (less than 15 days) without performing any storage maintenance. Before placing the lawnmower into storage always carry out the following: 1. Allow the engine to fully cool. 2. Ensure the grass bag is empty. 3.
- Page 19 Performing routine maintenance correctly on your lawnmower will ensure you get years of trouble free use. Please keep this manual safe for future reference. It is recommended that the following maintenance schedule is adhered to. This will ensure the lawnmower operated correctly and is safe to use.
- Page 20 WARNING! CAUTION! Faults which cannot be rectified with the aid of following table may be rectified by a specialist company only (customer service center) 1-866-591-8921. Please be aware that any improper repairs will also invalidate the warranty and additional costs may be incurred. Use only genuine spare parts.
